Light Emotion DERBY4 Operator's manual

www.lightemotion.com.au
DERBY4
4-in-1 Entertainment Lighting Effect.
User’s instruction manual
This manual contains important information about the safe installation and use of this product
Please read this instruction manual carefully before installing or operating
Please keep these instructions in a safe place for future reference
V1.01

1
Contents
1. Safety Instructions 2
2. Installation 3
3. Features 3
4. Menu Operation 3
5. IR Remote Control 6
6. DMX Control 8
7. DMX Connections 9
8. DMX Address Setting 9
9. DMX Terminator 10
10. Cleaning and Maintenance 10
11. Technical Data 11
12. Warranty 11

2
Introduction
Thank you for the purchase of your DERBY4 4-in-1 Lighting Effect by Light Emotion. We are confident you will
be satisfied with your purchase and enjoy many years of use from this Professional Light Emotion product. Please
read these instructions carefully to ensure the product is well look after and used correctly to avoid any potential
problems.
Please note that as part of our ongoing commitment to continuous improvement and product development, the
specifications in this manual are subject to change without notice. Whilst every care has been taken in the
preparation of this manual we reserve the right to change specifications in the course of product improvement.
What is in the box:
- 1 x DERBY4 fixture
- Power cable
- Laser safety switch key
- IR remote control
- This user manual
1. Safety Instructions:
Please read these instructions carefully. It includes important information about the installation usage and
maintenance of this product.
- Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also
receive this instruction booklet.
- Always make sure that you are connecting to the proper voltage and that the line voltage you are connecting to is
not higher than that stated on the sticker of the fixture.
- This product is intended for indoor use only. To prevent risk of fire or shock, do not expose fixture to rain or
moisture.
- Make sure there are no flammable materials close to the unit while operating.
- The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent surface. Be sure that
no ventilation slots are blocked.
- Always disconnect from power source before servicing.
- Secure fixture to stands, trussing and the like using a safety chain.
- Maximum ambient temperature is 40˚C. Do not operate fixture at temperatures higher than this.
- In the event of serious operating problem, stop using the unit immediately. Never try to repair the unit by yourself.
Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the nearest authorized
technical assistance centre.
- Make sure power cord is never crimped or damaged.
- Never disconnect power cord by pulling or tugging on the cord.
- Never carry the fixture directly from the cord. Carry by holding the unit directly or via the hanging bracket.

3
- Avoid direct eye exposure to the light source while it is on.
2. Installation:
Caution: For safe mounting of this product, please read the following carefully.
- Use a suitable clamp to attach to lighting stand, trussing or bar, together with safety chain.
- When mounting the product, do not stand directly underneath the product
- Always use a safety chain when mounting the product on stands, trussing or bars. Make sure the breaking strain
rating of the chain is at least 10 times the weight of the product.
- Make sure there is adequate ventilation around the product.
- Never look directly into the LED light or laser sources of the product.
- For indoor use only – do not use outdoors.
- To avoid electrical shock, keep away from rain and moisture.
3. Features
This product is designed as entertainment effect lighting fixture and is only intended to be used as an effect for
entertainment and production applications. Due to our ongoing commitment to constantly reviewing and improving
products, features and specifications are subject to change without prior notice.
- Derby LED: 8 x 3W RGBY LED, 2 of each colour
- UV LED: 8 x 3W UV LED
- White LED: 2 x 3W cool white LED
- Laser: Red 80mW/650nm + green 30mW/532nm
- Control: Sound activated, auto, DMX, master/slave, IR remote control
- DMX channels: 2 / 10ch selectable profile
- Power input: 100-240VAC, 50/60Hz.
- Power consumption: 55W
- DMX connections: 3 pin male and female XLR
- Dimensions: 240 x 220 x 250mm
- Weight: 2kg
4. Operation
Because this light features a laser, there is the mandatory key operated laser safety switch on the rear of the unit.
This is independent of the power on/off switch. The laser will not operate until the safety switch is placed into the
on position using the included key. All other functions of the product will work regardless, when the power switch
is on.
The four button LED menu control on the rear of the product allows you to access all features of the product
including how it is to be controlled.

4
LED Four Digit Display:
Menu Up Down Enter
Using the four button LED menu control, press the menu button repeatedly until you reach your desired mode. You
can also scroll though the modes using the up and down buttons. Press enter to access being able to vary the settings
for that mode or feature. Using the up and down buttons, adjust to the desired setting, then press enter again to save
your setting.
The following table shows each of the modes and the settings able to be varied in each mode:
MENU UP/DOWN DEFAULT
VALUE
FUNCTION
1 Addr 1-512 1 Set DMX address
2 ChMd 10Ch 10Ch 10CH mode
2Ch 2CH mode
3 ShNd
Sh 1
Sh 4
Show 1
Sh 2 Show 2
Sh 3 Show 3
Sh 4 Show 4 (by random)
4 SPEE 0-100 90 Sh 1-Sh4 speed
5 SLMD MASt MASt Master mode
SLAV Slave mode
6 SoUn ON/OFF ON Sound ON/OFF
7 SoSE 1-100 90 Set Sensitivity
8 DNST
MASt MASt When no DMX, run master /slave
mode
BLNd When no DMX, stand by
LAST When no DMX, keep the last scene
9 LED ON/OFF ON LED display back light ON/OFF
10 Test Test light function
11 DISP LED display reverse
12 Fhrs Total working time
13 Ver
V10
Software version
14 Rset Light reset

5
Explanation of Menu items.
Addr – DMX address
ChMd – DMX profile 2 or 10 channel mode
ShNd – Built in show
SPEE – Speed setting for shows 1-4 if not sound activated
SLMD – Chose between master or slave mode
SoUn – Sound activation on or off
SoSe – Sets sound sensitivity
DNST – Sets what the light does if there is loss of DMX signal
LED – LED display on or off – When you chose off, the LED display will turn itself off after 10
seconds of not being used. Pressing mode turns on the LED dispay.
TEST – Test mode
DISP – Turns the LED display upside down
Fhrs – shows the number of hours the light has been used for
Ver – shows the software version of the light
Rset – Resets the light.
Notes:
- DMX takes priority over all other mode settings. If there is a DMX lead connected and a DMX
signal received, the light will immediately be controlled by DMX.
- After using the LED menu, hold down the menu button for 2 seconds for the light to resume
normal operation. Otherwise normal operation will resume after 10 seconds (as in light effects
output).

6
5. Infra Red remote control.
1
2
3
4
6
5
8
7
9
10
11
12

7
NO BUTTON FUNCTION
1 Stand By Standby mode – no light output
2 DMX No function
3 Show 1-Show 8 Show 1-Show 4(available) Show 5-Show8(no function)
4 LED Color LED colour choose – press repeatedly to cycle colours
5 LED Random LED colour random
6 Laser Color Laser colour choose
7 Laser Random Laser colour random
8 Sound ON Sound control ON
9
Sound OFF
Sound control O
FF
10 Speed - Decrease Show speed
11 Speed Set Show’s speed at middle speed
12 Speed+ Increase Show speed

8
6. DMX Control
Using DMX you can control each of the four effects built into this light individually. You can also
use DMX to call upon built in programs and shows. This fixture has 2 DMX profiles – 2 and 10
channels modes. The 10 channel mode allows individual control of all the effects while the 2
channel mode is a simpler way to control the light ny DMX simply calling upon built in programs
and features.
10 Channel DMX chart:
DMX value Function
CH1
Control mode
0-9 No function
10-69 Show 1: Gobo Derby Show
70-129 Show 2: White LED and UV show
130-179 Show 3: Laser show
180-255 Show 4: Random combination
CH2
LED Gobo Derby
Control
0-9 Gobo Derby off (no LED)
10-198 Colour selection (15 options, 13 DMX
values for each option)
199-225 Colour flowing 1 (single colour) slow to
fast
226-255 Colour flowing 2 (several colours) slow
to fast
CH3
Gobos LED strobe
control
0-9 Gobo Derby LED strobe OFF
10-244 Gobo Derby strobe speed (slow to fast)
245-255 Gobo Derby strobe with sound control
CH4 Gobos LED control 0-127 Gobo Derby position
128-255 Gobo Derby scanning (slow to fast)
CH5 White LED dimmer 0-255 White LED dimmer (0-100%)
CH6 White LED strobe 0-244 White LED strobe speed (slow to fast)
245-255 White LED strobe with sound control
CH7 UV LED dimmer 0-255 UV LED dimmer
CH8 UV LED strobe 0-244 UV LED strobe speed (slow to fast)
245-255 UV LED strobe with sound control
CH9 Laser colour
0-9 Laser closed
10-63 Red
64-127 Green
128-255 Red+Green
CH10 Laser motor control
0-9 No function
10-127 Motor clockwise rotation
128-255 Motor anti-clockwise rotation

9
2 channel DMX Chart:
7. DMX-512 Control Connection
Using a 3 pin XLR cable, you can connect the product to a DMX controller and then to other fixtures
with 3 pin XLR inputs and outputs. When not using DMX, multiple fixtures can be connected together
and operate under master/slave control. The signal cable should have two core with shielded cable, the
signal connectors are XLR input and output connectors. Please refer to the below diagram:
8. DMX Address Setting
When being used in conjunction with a DMX controller, each fixture must be set a specific starting
address. When receiving signal, fixture will receive channel control signals of this address from the
DMX controller.
For simplicity, the user can use the same address for multiple fixtures but this will result in each fixture
providing exactly the same output and fixtures with the same DMX address cannot be individually
controlled.
To control each fixture individually via DMX, each fixture must have its own unique DMX address. If
this fixture is in 10 channel DMX mode then each address must be 10 channels apart. For example, if
the first unit is on DMX channel 1, the 2
nd
must be on DMX channel 11, the 3
rd
on channel 21 and so on.
DMX value Function
CH1
Control mode
0-9 No function
10-69 Show 1: Gobo Derby LED show
70-129 Show 2: White LED + UV show
130-179 Show 3: Laser show
180-255 Show 4: Random effects
CH2
Show speed/sound
control
0-247 Show 1-Show 4 Speed from slow to fast
248-255 Show 1-Show 4 sound control

10
Similarly, for 2 channel DMX mode, the DMX channels would be 1,3,5,7 and so on.
Some DMX controllers may group fixtures in lots of 16 channels – so in that case, fixture 1 on channel 1,
fixture 2 on channel 17, 3 on 33, and so on. Refer to your DMX controllers’ instruction manual on how
best to manage your DMX channel allocation.
DMX Out
1
st
addr 001 2
nd
addr 011 3
rd
addr 021
9. DMX-512 connection with DMX terminator
A DMX terminator helps to reduce ‘noise’ on the DMX chain, and makes the light respond to control
more accurately. It should be plugged in to the last fixture in any chain. For Terminator connections
please see below:
10. Cleaning and Maintenance
From time to time it is recommended the product is cleaned to ensure maximum light output and
performance. Use a wet cloth to clean the housing as well as the lenses. Please note that alcohol based
cleaners and solvents cannot be used as they will cause damage to the product.
When used in a fixed long term installation such as a venue or club, the unit should be periodically taken
down from the installation and professionally cleaned. Dust build-up within the unit can cause damage
and ultimately failure of components.

11
11. Technical Data
- Derby LED: 8 x 3W RGBY LED, 2 of each colour
- UV LED: 8 x 3W UV LED
- White LED: 2 x 3W cool white LED
- Laser: Red 80mW/650nm + green 30mW/532nm
- Control: Sound activated, auto, DMX, master/slave, IR remote control
- DMX channels: 2 / 10ch selectable profile
- Power input: 100-240VAC, 50/60Hz.
- Power consumption: 55W
- DMX connections: 3 pin male and female XLR
- Dimensions: 240 x 220 x 250mm
- Weight: 2kg
- Fuse BGDP 5x20mm 250VAC T2A
- working temperature 10-40 degrees C
12. Warranty
This product is warranted for 2 years from your purchase date. We are confident that this product will
give many years of trouble-free operation but should an unlikely problem arise, warranty claims must be
via the original place of purchase, together with the original purchase receipt. Please keep both your
original purchase receipt and this instruction manual together and in a safe place for future reference.
Should the product be sold within the warranty period, be sure to pass on both to the new purchaser so
they are able to claim warranty should they need to. We recommend you register your warranty online at
www.industrygear.com.au.
Purchased from:_________________________________________
Contact Details:_________________________________________
Date Purchased:_________________________________________
Invoice/Receipt Number:__________________________________
Copyright Light Emotion 2017. E&OE
Exclusively imported by LSW Imports and Distribution
PO Box 887, Kingsgrove, NSW, 2208
[email protected]
www.lightemotion.com.au
1800 643 111 (within Australia)
[phone] (outside of Australia)
