Lightforce LFDLH User manual

1
USER INSTRUCTIONS
MODIFICATION OF 12V WIRING
HARNESS TO SUIT THE
LED215SD AND LED180SD.

2USER INSTRUCTIONS LIGHTFORCE.COM
INSTALLATION STEPS
1. Take the crimp terminals provided with the LFDLH harness (gure 1, item A)
2. Fit crimp terminals to the red and black cable of the adaptor (gure 2, item B)
3. Fit the yellow insulators (gure 1, item B) over the crimp terminals
4. Fit the connectors supplied with your harness (gure 1, item C) over the terminals (gure 1, item A)
ensuring white goes to red and black goes to black
5. Slide the yellow insulators down the wires and into the connectors.
A.
C.
White: Positive
Black: Negative
Therefore: White on the harness goes
to red on the adaptor. Black on the
harness goes to black on the adaptor.
(gure 2)
MODIFICATION OF 12V WIRING HARNESS (LFDLH)
TO SUIT THE LED215SD AND LED180SD.
Figure 1.
B.

3
ADAPTOR WIRE COLOUR IDENTIFICATION
1. Red: Positive - connect to positive wire on harness
2. Black: Negative - connect to negative (earth) wire on harness
3. Yellow: Positive - LED positioning lights, connect to positive low beam light circuit
4. Blue: Not used.
Blue
Yellow
Red
Black
ADAPTOR Figure 2.
B.

4USER INSTRUCTIONS LIGHTFORCE.COM
For warranty information and to register your product for
warranty purposes, visit lightforce.com/warranty
LIGHTFORCE AUSTRALIA PTY LTD
11 Manton Street, Hindmarsh SA 5007 Australia
www.lightforce.com • Email: [email protected]
Australia Telephone: [phone] | Fax: [phone]
International Telephone: [phone] | Fax: [phone]
All logos and images are subject to relevant trademark and copyright protection. Copyright © Lightforce
Australia Pty Ltd 2019. Data and specications may be subject to change without notice. Lightforce Australia
Pty Ltd shall not be liable for damage, malfunction, failure resulting from accident, misuse, misapplication,
unauthorised repair, neglect, modication, unauthorised or non standard replacement parts, accessories,
bulbs, batteries or voltage or operation of the product beyond its technical and or environmental specication.
190521-1-LFDLH-Modication-UserInstructions
