Yakima LOCKN'LOAD User manual

80-13-037-Rev2 1/4
• Please read instructions carefully before installation.
• Check the contents of kit. Contact your YAKIMA dealer if any parts appear missing or damaged.
• Clean your Platform prior to fitting the LOCKN’LOAD Platform Inboard Light Bracket Kit.
• Place these instructions in the vehicle’s glove box after installation is complete.
FIRST TIME INSTALLATION
KIT CONTENTS
ITEM COMPONENT QTY
1. Inboard Light Bar
Bracket Right Bend
x1
2. Inboard Light Bar
Bracket Left Bend
x1
3. Nyloc Nut x4
4. Washer x4
5. T Bolt x4
®
PLATFORM AND LIGHT BAR SOLD SEPARATELY
MAX LOAD RATING: 8KG
LOCKN’LOAD
TM
PLATFORM INBOARD LIGHT BRACKET KIT
2
3
4
1
5
• Allen Key
• 10mm Socket Wrench/Spanner
TOOLS REQUIRED:

80-13-037-Rev2 2/4
LIGHT BAR INSTALLATION
1CONFIGURATIONS
The Light Bar Brackets can be mounted to the Platform in two different orientations to suit
side or top mounted light bars as shown.
REMOVE DEFLECTOR OR RUBBER INFILL
If mounting to the front of the Platform, remove the deflector.
If mounting to the rear of the Platform remove the rubber infill.
This is done by simply peeling the part out of the slot, starting at one
end and working across the length of the strip.
Installation is the reverse and should be confirmed by hearing an
audible ‘CLICK’ when it is fully installed.
2
LOOSELY ATTACH BRACKETS TO LIGHT BAR
Using the hardware supplied with your light bar, loosely attach brackets to each end of the
light bar in the applicable orientation. If mounting light bar via the side, four mounting holes
are available to suit your size and style of light bar.
Finger tighten screws to allow the light bar to be rotated once mounted.
3
NOTE - Screws, washers, nuts
supplied within your light bar kit.

80-13-037-Rev2 3/4
LOOSELY ASSEMBLE BRACKETS
Loosely assemble the T Bolts, Washers and Nuts to the brackets as shown.
4
POSITION LIGHT BAR
INTO PLATFORM
Position light bar and
bracket assembly into
the underside channel
of Platform as shown.
5
Once in position, use an
Allen Key to ensure the
T Bolts are turned all the
way to the locked position.

80-13-037-Rev2 4/4
CENTRE LIGHT BAR
Centre light bar and bracket assembly on Platform by ensuring there is an equal distance from the
Platform corners as shown.
6
SECURE LIGHT BAR TO PLATFORM
Secure light bar and bracket assembly to
the Platform by tightenting each Nyloc Nut
to 4Nm using a 10mm Socket Wrench or
Spanner.
7
NOTE - Ensure that position of light bar, or multiple light bars, complies with relevant state legislation.
ADJUST LIGHT BAR AND TIGHTEN SCREWS
8
Adjust light bar to preferred angle then
tighten light bar hardware installed in Step 3
according to the manufacturer’s instructions.
Installation is now complete.
Ensure all screws are regularly checked
and tightened to ensure minimal bounce
and maximum safety.
Ensure all wiring is retained according
to Light Bar manufacturer instructions.
