Lighthouse Lightning Bolt User manual

Lightning Bolt
Rechargeable Multi Function Torch
with Swivel Action Head
IMPORTANT
It is essential that you read the
instructions contained in this manual
before using the torch for the first
time.
Failure to follow these instructions
could result in damage to the torch,
property damage or personal injury.
This manual should be stored safely
for future reference.
Product code: L/H BOLT
Instruction
Manual
Running Times
The operating times of this torch may vary
depending on the working conditions and the
amount of charge in the battery at the time of use.
The approximate running times for the four
functions of this torch when fully charged are as
follows:
Halogen Spotlight 55 Minutes
8 LED Floodlight 15 Hours
21 LED Worklight 10 Hours
7 LED Red Safety Light 20 Hours
To achieve the best performance of your
‘Lightning Bolt’ always switch the torch off when
the battery power begins to run low, and
recharged immediately.
Care and Maintenance
Storage
Store the ‘Lightning Bolt’ multi function torch and
charging adaptors in a clean and dry area. Be
sure to keep the charging adapters supplied with
this product stored separately from similar items as
only charging adapters included with this torch are
compatible. Using a non- compatible charger could
cause damage to the torch or personal injury.
The torch may also be stored in a vehicle for use in
roadside emergencies. If kept in a vehicle, it is
recommended that battery be re-charged every
30-45 days to ensure maximum performance in an
emergency. To prevent the torch and any of the
accessories being damaged, please ensure that it
is properly secure and in a safe place inside the
vehicle.
Bulb Replacement
To replace the Halogen spotlight bulb, first check
that the main switch is OFF. Pull off the rubber ring
front cover, then remove the two retaining screw on
the black plastic lens holder. Carefully remove lens
holder along with the glass lens. Lift out the
reflector and disconnect the white lead from the
bulb from the Red lead connecting it to the battery.
Press together the bulb retaining spring arms to
release the bulb and remove. Fit the replacement
bulb and clip in to place. Always use a tissue or
clean cloth when handling a new bulb to avoid
contamination that may cause the premature failure
of the bulb. Reconnect the white bulb lead and
reassembly the torch.
Replacement Bulb
Part No: L/H BOLTB
2 x Halogen 4V Bulb, 15 Watts
Cleaning
All exterior surfaces of the ‘Lightning Bolt’ can
be wiped clean with a soft cloth dampened with a
soap and water solution. Do not immerse or
submerge any part of torch in water or any other
solvent. Never use solvents or cleaning agents
containing petroleum (petrol, kerosene, oil), paint
thinner, turpentine, alcohol, or ammonia. Harsh
materials like these can damage surfaces.
Maintenance
All repairs other than replacement of the
combination spotlight bulb should only be carried
out by qualified service personnel. Do not open
exterior casing of the spotlight, as there are no
user serviceable parts inside. Opening or visible
attempts to open or repair a combination spotlight
may void any guarantee and/or cause damage to
the product or personal injury.
LED bulbs will never wear out under normal
conditions and do not need to be replaced.
Failure to recharge the spotlight battery every
three months may permanently damage or reduce
the performance of the spotlight.
Never attempt to open the battery pack,
under abusive conditions liquid may be
ejected from the battery, if accidental
contact occurs flush the effected area
with water. If the liquid comes into
contact with the eyes flush with water
and seek medical help. Liquid ejected
from batteries may cause irritation or
burns.
This product contains an internal Lead
Acid battery pack formulated from
environmentally sensitive materials. This
product must be disposed of properly with
due care for the environment. Please
return this product to your local dealer or to
your local recycling station where batteries
will be recycled or disposed of properly.
Never attempt to incinerate batteries as
they may leak or explode.
One-Year Home Use Limited
Guarantee
Lighthouse guarantees this product to the original
purchaser for a period of ONE YEAR against any
defects in material or workmanship but shall not
cover damage caused by misuse, abuse,
alteration, or accident. This product is intended
for home use only and the guarantee will not
cover products used for commercial purposes.
Ni-MH

The Multi Function Rechargeable Torch
Your new cordless, LlGHTHOUSE rechargeable multi function torch is perfect for use in and
around the home and garage, providing a safe and portable source of light for use just
where and when you need it. Great for use during power failures, while camping, fishing or
working on the car and many other uses including roadside emergencies.
Adjustable
Handle
Charging the LlGHTHOUSE Torch
The ‘Lightning Bolt’ must be fully charged before
being used for the first time. This will ensure that
the battery gives its best performance now and on
future re-charging cycles. TheAC and DC
charging adapters are for re-charging the battery
only. They cannot be used to directly power the
torch. Always ensure the torch is switched off
whilst charging.
Using the AC Charging Adapter
1) Plug the adapters jack plug into the recharge
socket (Fig 3).
2) Plug the adapter into a 240V socket and
switch the socket on (if applicable).
3) The charging indicator lamp will glow RED
while charging is in progress.
4) The battery will be fully charged after
approximately 12 hours, Disconnect the jack
plug from the torch, remove the adapter from
the wall socket or switch off.
Safety Precautions
Use 240v AC charging adapter indoors in a dry
location only. Exposure to damp or wet
conditions could cause electrocution or damage
to adapter.
Do not use the charger in the vicinity of
flammable liquids or materials.
Do not use the charging adapter in combination
with any extension cord, electrical generators, or
step-up transformers.
Always plug the adapter directly into a 240v
outlet in a suitable location.
Store in dry location and do not allow the
charging adapter to come in contact with water,
rain or snow. If the charging adapter comes into
contact with water, place in a dry location at
room temperature, on a soft absorbent towel
and allow too dry thoroughly.
Do not operate the unit until it is completely free
of moisture.
If the adaptor becomes submerged in water,
discontinue use immediately and contact your
local LIGHTHOUSE retailer for a replacement
charger unit.
Do not store charging adapter where
temperatures may exceed 122°F (50°C).
Use only the AC charging adapter supplied with
the torch. Do not attempt to charge the torch
with an adapter that is not compatible as this
could result in a fire, damage to the torch or
personal injury.
240V AC Mains
Charging Adaptor 12V DC Car
Charging Adaptor
The ‘Lightning Bolt’ has four
light outputs and functions.
SPOTLIGHT-FLOODLIGHT MODE:
Press the switch on the handle once to turn the
spotlight on. This function uses the 15W halogen
quartz high power beam. Depress again to turn
the spotlight off and the floodlight on. This function
uses the 8 LED Floodlight function. Depress again
to turn the torch off.
SWIVEL ACTION HEAD FUNCTION
The torch comes with a swivel action head on one
end. Press the two release buttons on either side
of the head near the on/off button. The head can
then be angled to suit your needs.
WORKLIGHT-SAFETY LIGHT MODE:
Press the switch on the otherside of the handle
once to turn the worklight on. This function uses
the 21 LED super bright beam. Depress again to
turn the worklight off and the safety light on. This
function uses the 7 Red flashing LED safety light.
Depress again to turn the torch off. The swivel
action head works on these two functions only.
Additional Features
The torch has an adjustable handle and can be fitted
with the shoulder nylon detachable strap (supplied).
Torch Specifications:
Battery Pack: 4V/3Ah Internal Sealed Lead
Acid Rechargeable Battery
Bulb Type: 1x 4V/15W Halogen Bulb
29 x White LED (Light-Emitting Diode)
7 x Red LED (Flashing)
LED Bulb Life: 100,000 Hours
Charger Specifications:
Model No: YH-BS350600300D
Voltage: 230~240V AC 50Hz
Secondary: 6V DC 300mA
Swivel
head
release
button
Using the DC Charging Adapter
1) Plug the adapters jack plug into the recharge
socket (Fig 3).
2) Plug the adapter into the vehicles 12v DC
cigarette lighter or accessory power socket.
3) The charging indicator lamp will glow RED
while charging is in progress.
4) Disconnect the jack plug from the torch, and
remove the DC adapter from the outlet socket.
5) The battery will be fully charged after
approximately 12 hours, Disconnect the jack
plug from the torch, remove the DC adapter
from the outlet socket.
To prevent overheating do not charge for more
than 15 hours.
Safety Precautions
The DC charging adapter can be used in most
vehicles by plugging into the 12v DC cigarette
lighter or accessory power socket.
Consult your vehicle owner's manual for further
information on operating 12v DC accessories.
Do not drive the vehicle while charging, as an
unsecured torch may be a hazard during certain
driving manoeuvres.
Store in dry location and do not allow the
charging adapter to come in contact with water,
rain or snow.
If the charging adapter comes into contact with
water, place in a dry location at room
temperature, on a soft absorbent towel and
allow too dry thoroughly. Do not operate the unit
until it is completely free of moisture.
If the adaptor becomes submerged in water,
discontinue use immediately and contact your
local LIGHTHOUSE retailer for a replacement
charging adapter.
Do not store charging adapter where
temperatures may exceed 122°F (50°C).
Use only the DC charging adapter supplied with
the torch. Do not attempt to charge the torch
with an adapter that is not compatible as this
could result in a fire, damage to the torch or
personal injury.
Fig.3
Charging
Port
Detachable
Strap
On/Off
Switches
