lighting PLUS IP-1940B User manual

User manual
IP-1940B
Please read the instructions carefully before use

2
TABLE OF CONTENTS
1. Safety Instructions……………………………………………………………………………3
Technical Specifications…………………………………………………………………………4
Control Menu ……………………………………………………………………………………5
DMX Channels …………………………………………………………………………………6-10
Dimension …………………………………………………………………………………………11
Trouble Shooting…………………………………………………………………………………12
Fixture Cleaning………………………………………………………… ………………………12
STATEMENT
The product has well capability and intact packing when leave factory. All of the user should
comply with warning item and manual, any misuse cause of the damages are not included in our
guarantee, and also can not be responsible for any malfunction & problem owing to ignore the
manual.

3
1.Safety Instructions
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction booklet.
•Unpack and check carefully there is no transportation damage before using the unit.
•Before operating, ensure that the voltage and frequency of power supply match the power
requirements of the unit.
•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
•The unit is for indoor use only. Use only in a dry location.
•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces. Be sure that no ventilation slots are blocked.
•Disconnect main power before replacement or servicing.
•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.
•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always
by taking its base.
•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher
than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand
during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before
replacing or serving.
•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit
by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always use the same type spare parts.
•DO NOT touch any wire during operation as high voltage might be causing electric shock.
Warning:
•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
Caution:
•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any
repairs yourself. In the unlikely event your unit may require service, please contact your nearest
dealer.
Installation:

4
•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also
always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.
•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the
touch of people.
2.Technical Specifications
Voltage: AC100V～240V 50-60HZ
Rated Power: 760W
LED Source: 19*40W RGBW 4-in-1 LED
Zoom angle: 4°-57°
Wash+beam+bee eye 3in1 efect
Strobe: 0-25Hz
Control: DMX512/Auto Run/Master-Slave/Music
DMX Channels: 22/36/79/112 channel
Dimmer: 0-100% linear dimmer
Pan: 540°+16 bit fine
Tilt: 270°+16 bit fine
Display: LCD colorful display
IP: IP66
Dimension: 388*240*490mm
NW; 27.5KGS

5
3.Control Menu
MENU
Dmx Address
001 - 512
Fixture
Ch Mode
22CH /36CH/79CH/98CH/93CH
Run Mode
DMX / Auto X
Pan Invert
Close/ Open
Tilt Invert
Close/ Open
Fan Control
Norma/Low/Quiet/High
Dim Curve
Line/Curv/S-Cur
Dim Fast Close
Close/ Open
No DMX State
Clear/ Keep
Manual
Red
000 - 255
Red Fine
000 - 255
Green
000 - 255
Green Fine
000 - 255
……
……
Information
TimeInfo
Current Time
Total Time
Power Count
SenSor
Pan
Tilt
Zoom
Zoom Rot
Temp
Soft Ver
Panel
Motor
Dimmer
Network
Factory
Password
000 - 255
Pan
000 - 255
Tilt
000 - 255
ZoomRot
000 - 255
Zoom
000 - 255
Red
000 - 255
……
……
……
……
FixReset
All Reset
Cance/Run
Factory
Cance/Run
Display
Language
CH / EN
Display Flip
Normal/Reverse
Display Mode
60s / Show
Net Setting
Protocol
ArtNet/Sacn
K1ingNet
Disable/Enable
Universe
000 - 255
Ip Address
000.000.000.000
Subet Mask
000.000.000.000

6
4.DMX Channels
23CH
CH
Function
DMX Value
Details
1
Red
0-255
Red dimmer
2
Red Fine
0-255
Red fine control
3
Green
0-255
Green dimmer
4
Green Fine
0-255
Green fine control
5
Blue
0-255
Blue dimmer
6
Blue Fine
0-255
Blue fine control
7
White
0-255
White dimmer
8
White Fine
0-255
White fine control
9
CTO
0-255
Color temperature linear control
10
Macro color
0-255
Marco color control
11
strobe
0-3
Light off
4-103
Strobe with the same step from slow to fast
104-107
Light on
108-207
Divide strobe from slow to fast
208-212
Light on
213-225
Random strobe in low speed
226-238
Random strobe in middle speed
239-251
Random strobe in high speed
252-255
Light on
12
Dimmer
0-255
0-100 linear dimmer from dark to bright
13
Dimmer Fine
0-255
Dimmer fine control
14
Pan
0-255
Pan movement control
15
Pan Fine
0-255
Pan fine control
16
Tilt
0-255
Tilt movement control
17
Tilt Fine
0-255
Pan fine control
18
Function
0-255
19
Reset
0-250
No function
251-255
Reset with 5 seconds
20
Zoom
0-255
21
Zoom Rotation
0-127
0 to 60 degree
128-191
Unlimited clockwise rotation from fast to slow
192-255
Unlimited anticlockwise rotation from fast to slow
22
Frequency
0 - 255
36CH
CH
Function
DMX
Details
1
Red
0-255
Red dimmer
2
Red Fine
0-255
Red fine control
3
Green
0-255
Green dimmer
4
Green Fine
0-255
Green fine control

7
5
Blue
0-255
Blue dimmer
6
Blue Fine
0-255
Blue fine control
7
White
0-255
White dimmer
8
White Fine
0-255
White fine control
9
CTO
0-255
Color temperature linear control
10
Macro colour
0-255
Marco color control
11
strobe
0-3
Light up
4-103
Strobe with the same step from slow to fast
104-107
Light on
108-207
Divide strobe from slow-fast
208-212
Light on
213-255
Random strobe from slow-fast
12
Dimmer
0-255
0-100 linear dimmer from dark to bright
13
Dimmer Fine
0-255
Dimmer fine control
14
Pan
0-255
Pan movement control
15
Pan Fine
0-255
Pan fine control
16
Tilt
0-255
Tilt movement control
17
Tilt Fine
0-255
Pan fine control
18
Function
0-255
19
Reset
0-250
No function
251-255
Reset with 5 seconds
20
Zoom
0-255
21
Zoom Rotation
0-127
0 to 60 degree
128-191
Unlimited clockwise rotation from fast to slow
192-255
Unlimited anticlockwise rotation from fast to slow
22
Shape Selection
0-255
Selecting shape
23
Shape Speed
0-255
Shape speed control
24
Shape Fade
0-255
Shape fade
25
Shape R
0-255
Shape in Red color
26
Shape G
0-255
Shape in Green color
27
Shape B
0-255
Shape in Blue color
28
Shape W
0-255
Shape in White color
29
Shape Dimmer
0-255
Shape dimmer 0-100%
30
Background Dimmer
0-255
Background dimmer 0-100%
31
Shape Transition
0-255
Shape change
32
Shape Offset
0-255
Shape offset
33
Foreground strobe
0-255
Foreground strobe control
34
Background strobe
0-255
Background strobe control
35
Background select
0-255
Background selection
36
Frequency
0 - 255
79CH
CH
Function
DMX Value
Details
1
Red
0-255
Red dimmer

8
2
Red Fine
0-255
Red fine control
3
Green
0-255
Green dimmer
4
Green Fine
0-255
Green fine control
5
Blue
0-255
Blue dimmer
6
Blue Fine
0-255
Blue fine control
7
White
0-255
White dimmer
8
White Fine
0-255
White fine control
9
CTO
0-255
Color temperature linear control
10
Macro color
0-255
Marco color control
11
strobe
0-3
Light off
4-103
Strobe with the same step from slow to fast
104-107
Light on
108-207
Divide strobe from slow to fast
208-212
Light on
213-225
Random strobe in low speed
226-238
Random strobe in middle speed
239-251
Random strobe in high speed
252-255
Light on
12
Dimmer
0-255
0-100 linear dimmer from dark to bright
13
Dimmer Fine
0-255
Dimmer fine control
14
Pan
0-255
Pan movement control
15
Pan Fine
0-255
Pan fine control
16
Tilt
0-255
Tilt movement control
17
Tilt Fine
0-255
Pan fine control
18
Function
0-255
19
Reset
0-250
No function
251-255
Reset with 5 seconds
20
Zoom
0-255
21
Zoom Rotation
0-127
0 to 60 degree
128-191
Unlimited clockwise rotation from fast to slow
192-255
Unlimited anticlockwise rotation from fast to slow
22
Frequency
0 - 255
23
Red dimmer 1
0-255
LED 1 red dimmer
24
Green dimmer 1
0-255
LED 1 green dimmer
25
Blue dimmer 1
0-255
LED 1 blue dimmer
26
Red dimmer 2
0-255
LED 2 red dimmer
27
Green dimmer 2
0-255
LED 2 green dimmer
28
Blue dimmer 2
0-255
LED 2 blue dimmer
……
………
………
………
…
………
………
………
77
Red dimmer 19
0-255
LED 19 red dimmer
78
Green dimmer
0-255
LED 19 green dimmer
79
Blue dimmer 19
0-255
LED 19 blue dimmer

9
112CH
CH
Function
DMX
Details
1
Red
0-255
Red dimmer
2
Red Fine
0-255
Red fine control
3
Green
0-255
Green dimmer
4
Green Fine
0-255
Green fine control
5
Blue
0-255
Blue dimmer
6
Blue Fine
0-255
Blue fine control
7
White
0-255
White dimmer
8
White Fine
0-255
White fine control
9
CTO
0-255
Color temperature linear control
10
Macro colour
0-255
Marco color control
11
strobe
0-3
Light up
4-103
Strobe with the same step from slow to fast
104-107
Light on
108-207
Divide strobe from slow-fast
208-212
Light on
213-255
Random strobe from slow-fast
12
Dimmer
0-255
0-100 linear dimmer from dark to bright
13
Dimmer Fine
0-255
Dimmer fine control
14
Pan
0-255
Pan movement control
15
Pan Fine
0-255
Pan fine control
16
Tilt
0-255
Tilt movement control
17
Tilt Fine
0-255
Pan fine control
18
Function
0-255
19
Reset
0-250
No function
251-255
Reset with 5 seconds
20
Zoom
0-255
21
Zoom Rotation
0-127
0 to 60 degree
128-191
Unlimited clockwise rotation from fast to slow
192-255
Unlimited anticlockwise rotation from fast to slow
22
Shape Selection
0-255
Selecting shape
23
Shape Speed
0-255
Shape speed control
24
Shape Fade
0-255
Shape fade
25
Shape R
0-255
Shape in Red color
26
Shape G
0-255
Shape in Green color
27
Shape B
0-255
Shape in Blue color
28
Shape W
0-255
Shape in White color
29
Shape Dimmer
0-255
Shape dimmer 0-100%
30
Background Dimmer
0-255
Background dimmer 0-100%
31
Shape Transition
0-255
Shape change
32
Shape Offset
0-255
Shape offset
33
Foreground strobe
0-255
Foreground strobe control

10
34
Background strobe
0-255
Background strobe control
35
Background select
0-255
Background selection
36
Frequency
0 - 255
37
Red dimmer 1
0-255
LED 1 red dimmer
38
Green dimmer 1
0-255
LED 1 green dimmer
39
Blue dimmer 1
0-255
LED 1 blue dimmer
40
White dimmer 1
0-255
41
Red dimmer 2
0-255
LED 2 red dimmer
42
Green dimmer 2
0-255
LED 2 green dimmer
43
Blue dimmer 2
0-255
LED 2 blue dimmer
44
White dimmer 2
0-255
…
………
………
………
…
………
………
………
108
Red dimmer 19
0-255
LED 19 red dimmer
109
Green dimmer 19
0-255
LED 19 green dimmer
111
Blue dimmer 19
0-255
LED 19 blue dimmer
112
White dimmer 19
0-255

11
5.Dimension

12
6.Trouble Shooting
F ollo w ing a r e a few c o mm on p r oble m s th a t m a y occu r d uring ope r a tion . He r e a r e s o m e s ug g es tion s fo r
ea s y tr ou b leshooting :
A. The un it does no t work , no li ght a n d t he f a n d o es no t w o r k
1. Check th e c on nect ion of p owe r a nd m a in fu s e .
2. M eas ure th e m a ins volt a ge on th e m a i n co nn e ct o r .
3. Check th e pow er on LED .
B. N o t responding t o D MX c on t ro ll er
1. D M X LED s h ou ld b e on. If no t, che ck D M X co n nectors, ca b l es to s ee if link p r ope r ly .
2. If th e D M X LE D i s on a nd no r espons e t o th e c h a nn el, che ck th e a dd r ess s etti ng s a nd D M X p ol a r ity .
3. If y ou h a ve i nter m ittent D M X s ig n a l p r oble m s , che ck th e p ins on c onn ecto r s or on
PCB of th e u nit or the p r ev iou s on e.
4. Tr y to us e a no th er D M X co ntroller .
5. Check if th e D M X ca b le s r un ne a r or run a lon g s id e t o h ig h volta ge c a b les th a t m a y c a us e d a m a ge or
in terfer ence to D M X inter face circui t.
C . One of the cha nn el s is no t w o r k ing w el l
1. Th e s tep p er moto r m ig h t b e dam a g ed or the c a b le c on nect ed to th e PCB is b r oken.
2. Th e m oto r ’ s d r ive IC on th e PCB m ig h t b e o ut of co ndition
7.Fixture Cleaning
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,
smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
