lighting PLUS IP-B906 User manual

User manual
IP-B906
Please read the instructions carefully before use

2
TABLE OF CONTENTS
1. Safety Instructions……………………………………………………………………………3-4
Technical Specifications…………………………………………………………………………4
Control Menu ………………………………………………………………………………………5-8
DMX Channels ……………………………………………………………………………………9-10
Trouble Shooting……………………………………………………………………………………11
Fixture Cleaning………………………………………………………… …………………………11
STATEMENT
The product has well capability and intact packing when leave factory. All of the user should
comply with warning item and manual, any misuse cause of the damages are not included in our
guarantee, and also can not be responsible for any malfunction & problem owing to ignore the
manual.

3
1.Safety Instructions
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction booklet.
•Unpack and check carefully there is no transportation damage before using the unit.
•Before operating, ensure that the voltage and frequency of power supply match the power
requirements of the unit.
•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
•The unit is for indoor use only. Use only in a dry location.
•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces. Be sure that no ventilation slots are blocked.
•Disconnect main power before replacement or servicing.
•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.
•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always
by taking its base.
•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher
than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand
during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before
replacing or serving.
•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit
by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always use the same type spare parts.
•DO NOT touch any wire during operation as high voltage might be causing electric shock.
Warning:
•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
Caution:
•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any
repairs yourself. In the unlikely event your unit may require service, please contact your nearest
dealer.
Installation:
•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly

4
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also
always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.
•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the
touch of people.
2.Technical Specifications
Power supply: AC110V-250V
Frequency: 50-60Hz
Battery: imported 18650 lithium battery
Charging and discharging can reach more than 500 times
Charging time: full charge in 6 hours
Power consumption :162W.
Light source: 9pcs 18W high brightness 6 in 1 leds
Lamp life: 6-10 ten thousand hrs
LED angle: 15/25/45 degree option
Color: 16.7 million kinds of color change
Control channels: 6/8/10 CH
Waterproof: IP65
Built in 2.4G receiver/ transmitter for wireless DMX operations.
Control mode :wireless dmx 512,DMX512, master/slave, auto, sound active, WIFI, IR.
Automatic model:Color change,strobe,dimmer,gradual change, jump change.
Operation menu: touch screen display.
The battery can last for 2-3 hours when all LEDs on after full charge , and can last for more than 5-6
hours on auto running mode. single color working can last about 15 hours.
Suggested to charge the battery for at least 4 hours, which will extend the life span of the battery.
UHF (64KHZ) dimming technology, no flicker
Dimension: 505*140*200mm
N.W: 5.45kg

5
3.Control Menu
Display the main interface:
A001
Console
or
auxiliary
machine
mode
1. Auto Color
Color jumping
Adjust speed after
confirmed (1-99)
1. Sound Mode1
Sound controlled
jumping
Sensitivity after
confirmed (1-100)
1. Custom Color
Manual dimming
R:0-255 G:0-255
B:0-255 W:0-255
Y:0-255 U:0-255
S:0-255
1. Dmx channel
Channel mode
6/8/10CH
Name:
6 Color
2. Auto Fade
Color gradient
Adjust speed after
confirmed (1-99)
2. Sound Mode2
Sound controlled
mutation
Sensitivity after
confirmed (1-100)
2.Static Color
Select 32 static
colors
2.Dmx Signal
State Data status
Hold keep
Break black
Version:
V2.0
3. Auto mutation
Color mutation
Adjust speed after
confirmed (1-99)
3.Sound Mode3
Sound controlled
color changing
strobe
Sensitivity after
confirmed (1-100)
3.2.4g wireless
ON/OFF
Dmx Channel:
10CH
4.Auto Strobe
Color changing
strobe
Adjust speed after
4.Sound Mode4
Sound control
mode
combination
4.Infrarrd
Infrared remote
control on / off
Run Time:
00:00

6
confirmed (1-99)
Sensitivity after
confirmed(1-100)
5.Wifi Mode
APP control
5.Display backlight
LCD Backlight
brightness section
0-100％
User Time:
00:00
6.LCD Cose time
LCD Backlight
display on / off
1.Open
2.10S
3.30S
4.45S
5.60S
Temperature:00
0
7.Restore factory
Factory recovery
8888
8.Limit Light
Current setting
6666
9、Temperature
Temperature
status
ON/OFF
10、Battery
Power status
ON/OFF
11.LCD
Background Color
00Black base
01yellow base
02 orange base
03 light grey
04 dark blue
05 grey blue
06 Pure blue
07 light green
08 dark grey blue
12.Key Power
ON/OFF
13.Menu Lock
ON/OFF
14.Language Set
Chinese /English

7
WIFI Operation Mode:
A. the WiFi mode in the menu＂show＂mark, the word "no WiFi" is displayed below the WiFi, means this
version has no mobile app control function. The word "led-xxx" is displayed below the WiFi. This version
has mobile app control function, and XXX represents three numbers, which is also the address of this light.
B. After confirmed the menu “help” , the information query is appeared. Press up and down to select any of
the two code to scan and install.
C. The operation steps of mobile wifi control are as follows:
Step 1 install the app (LED lamp) of the software on the mobile phone first. Note: multiple application
marks will appear when opening the app operation interface. This light is required to be controlled by "LED
light".
Step 2 switch the light display function to WiFi mode (item 5 in “show” mode)
Step 3 open the setting on the mobile phone, open WiFi and search the WiFi address, and the words
beginning with LED appear. For example, "led-xxx". And connect it.
Step 4: open the installed app on the mobile phone and see if it connected successfully.
D. In A001 console mode, press the OK key frequently, can adjust 7 frequency bands, and these 7 frequency
bands are for its related (00 red / 01 green / 03 yellow / 04 Blue / 05 light blue / 06 Purple / 07 white).
E. During charging, the operation and operation interface are displayed on the display screen. When the
power switch is not turned on, the light will not light up and is only in charging. If the light is using while
charging, the power switch must be turned on and the lamp can be used properly.
F. Over temperature protection function: (when the temperature is above 70 ℃, the power of the whole light
will be automatically reduced by 30%. When the temperature is above 95 ℃, the light will automatically
turn off).
G. This light supports RDM and software online upgrade function.

8
Infrared remote control function:
1. Dimming up key
2. Dimming down key
3. Off: light off pause
4. On: light on operation
5. R. G, B, W, A and UV keys are for these 6 kinds LED Color
6. 0-9 keys for 9 static color mixing (AC 1... AC 9)
7. 0 key is A001 (console), and the light address is adjusted up and down
8. Auto key is color changing, up/down for adjusting speed
9. Strobe key is the color selecting strobe mode, and the speed is adjusted by up and down keys (single color
strobe is optional)
10. The fade key is the fade mode, and the speed is adjusted by pressing up and down
11. The sound key is the sound control mode, and the up and down keys adjust the voice control mode
APP Guideline

9
4.DMX Channels
6 CH Mode
Channel
Function
DMX Value
Description
CH1
R Dimmer
0-255
Red dimming from dark to bright
CH2
G Dimmer
0-255
Green dimming from dark to bright
CH3
B Dimmer
0-255
Blue dimming from dark to bright
CH4
W Dimmer
0-255
White dimming from dark to bright
CH5
A Dimmer
0-255
Amber dimming from dark to bright
CH6
UV Dimmer
0-255
UV dimming from dark to bright
8 CH Mode
Channel
Function
DMX Value
Description
CH1
General dimmer
0-255
General dimmer from dark to bright
CH2
Strobe
0-9
Close
10-255
Strobe from slow to fast
CH3
R Dimmer
0-255
Red dimming from dark to bright
CH4
G Dimmer
0-255
Green dimming from dark to bright
CH5
B Dimmer
0-255
Blue dimming from dark to bright
CH6
W Dimmer
0-255
White dimming from dark to bright
CH7
A Dimmer
0-255
Amber dimming from dark to bright
CH8
UV Dimmer
0-255
UV dimming from dark to bright
10 CH Mode
Channel
Function
DMX Value
Description
CH1
General dimmer
0-255
General dimmer from dark to bright
CH2
R Dimmer
0-255
Red dimming from dark to bright
CH3
G Dimmer
0-255
Green dimming from dark to bright
CH4
B Dimmer
0-255
Blue dimming from dark to bright
CH5
W Dimmer
0-255
White dimming from dark to bright
CH6
A Dimmer
0-255
Amber dimming from dark to bright

10
CH7
UV Dimmer
0-255
UV dimming from dark to bright
CH8
Strobe
0-9
Close
10-255
Strobe from slow to fast
CH9
Function
0-8
light off
9-50
static color mixing mode (32 kinds)
51-100
jumping mode
101-150
mutation mode
151-200
gradual changing mode
201-220
sound control mode 1
221-240
sound control mode 2
241-255
sound control mode 3
CH10
Speed
0-255
Speed from slow to fast

11
5.Trouble Shooting
F ollo w ing a r e a few c o mm on p r oble m s th a t m a y occu r d uring ope r a tion . He r e a r e s o m e s ug g es tion s fo r
ea s y tr ou b leshooting :
A. The un it does no t work , no li ght a n d t he f a n d o es no t w o r k
1. Check th e c on nect ion of p owe r a nd m a in fu s e .
2. M eas ure th e m a ins volt a ge on th e m a i n co nn e ct o r .
3. Check th e pow er on LED .
B. N o t responding t o D MX c on t ro ll er
1. D M X LED s h ou ld b e on. If no t, che ck D M X co n nectors, ca b l es to s ee if link p r ope r ly .
2. If th e D M X LE D i s on a nd no r espons e t o th e c h a nn el, che ck th e a dd r ess s etti ng s a nd D M X p ol a r ity .
3. If y ou h a ve i nter m ittent D M X s ig n a l p r oble m s , che ck th e p ins on c onn ecto r s or on
PCB of th e u nit or the p r ev iou s on e.
4. Tr y to us e a no th er D M X co ntroller .
5. Check if th e D M X ca b le s r un ne a r or run a lon g s id e t o h ig h volta ge c a b les th a t m a y c a us e d a m a ge or
in terfer ence to D M X inter face circui t.
C . One of the cha nn el s is no t w o r k ing w el l
1. Th e s tep p er moto r m ig h t b e dam a g ed or the c a b le c on nect ed to th e PCB is b r oken.
2. Th e m oto r ’ s d r ive IC on th e PCB m ig h t b e o ut of co ndition
6.Fixture Cleaning
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,
smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
