Lightolier Task Lighting F7600 User manual

Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2007 Genlyte Group LLC • A0107
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Task Lighting F7600
Page 1 of 2 Portable Ambient
Features
Housing end: Die-cast aluminum, welded to the housing.
Finish: Powder coat baked enamel. Standard colors: white or aluminum.
Shielding: Extruded opal lens.
Lamp: 2x39 watt T5HO lamps (included).
Ballast: Electronic and meets ANSI starting, end of life protection, THD and
sound rating specifications.
Switching: On/off switch on stem. Optional cord switch available.
Wiring: 3-wire cord with grounded low profile plug. Minimum length 9 feet.
Listing: UL/cUL listed.
6 7/8"
175mm
1 5/8"
41mm
Ordering Information
Style Lamps Length Wattage Voltage Type Color Mounting
F76 = Rectangle 2= Lamps 3= 3 Foot 7= 39W 1= 120V 5= Lens AL = Aluminum F= Floor Stand
8= 39W WH = White P= Panel Bolt-on
Dimming E= Expandable Bracket
B= Binder Bin
F76 2 3 1 5
Example = F7623715ALF

Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2007 Genlyte Group LLC • A0107
Job Information Type:
Task Lighting F7600
Page 2 of 2 Portable Ambient
5 5/8"
Adjustable
10" to 13"
Adjustable
10" to 13"
Adjustable
10" to 13"
5 5/8"
Adjustable
55" to 75"
20"
508mm
12"
305mm
Floor Stand
5 5/8"
5 5/8"
Binder Bin Mount
Weighted Base
Weighted base allows fixture to sit atop
shelves or overhead cabinets.
Not recommended for use in seismic areas.
Panel Mount (Bolt-On)
Bolts to the top of furniture systems or short walls.
A small steel bracket is bolted though the top cap.
The stem assembly slides onto this bracket and is
held in place with hidden set screws.
Expandable Bracket
This adjustable bracket clamps onto
furniture systems ranging from 2" to 4" thick.
1900
1425
950
475
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
Candlepower Curve
Report No:
ITL54683.IES.MOD
Catalog No:
F7623715xxx
Lamps:
2-F39T5/HO
Lumens:
3500 each
Efficiency:
95.7%
Zonal Lumen Summary
Zone Lumens % Barelamp % Luminaire
0-90 2100 30.0 31.4
90-180 4597 65.7 68.6
0-180 6697 95.7 100.0
Coefficients of Utilization
% Effective Ceiling Cavity Reflectance
80 70 50
% Wall Reflectance
50 30 10 50 30 10 50 30 10
0 81 81 81 73 73 73 58 58 58
1 70 67 64 63 60 58 50 48 47
2 61 56 52 55 51 47 44 41 38
3 53 48 43 48 43 39 38 35 32
4 47 41 36 43 37 33 34 30 27
5 42 36 31 38 32 28 30 26 23
6 37 31 27 34 28 24 27 23 20
7 34 28 23 30 25 21 24 20 18
8 30 24 20 28 22 19 22 18 15
9 28 22 18 25 20 17 20 16 14
10 25 20 16 23 18 15 19 15 12
