4SB224 (28) (35) (42)
Decorative, Pendalux Suspension, Basic Canopy
Page 1 of 2
Job Information Type:
Job Name:
Cat. No.:
Notes:
Pendant Diagram
AB
C
4
45º
6
3
5
Complete Luminaire consists of Body and Suspension. Order each separately.
Multiple Stem Suspension, with Swivel, Basic Canopy.
Catalog No. Nominal Overall Length (A)* Nominal Length (B)* Suspension (Stem) and Canopy Finish
4SB224PB 17 ⅞" 13 ⅜" Polished Brass
4SB224SB 17 ⅞" 13 ⅜" Satin Brass
4SB224SN 17 ⅞" 13 ⅜" Satin Nickel
4SB224WH 17 ⅞" 13 ⅜" White
4SB228PB 21 11 ⁄16"16 ¼" Polished Brass
4SB228SB 21 11 ⁄16"16 ¼" Satin Brass
4SB228SN 21 11 ⁄16"16 ¼" Satin Nickel
4SB228WH 21 11 ⁄16"16 ¼" White
4SB235PB 27 5⁄16" 20 ½" Polished Brass
4SB235SB 27 5⁄16" 20 ½" Satin Brass
4SB235SN 27 5⁄16" 20 ½" Satin Nickel
4SB235WH 27 5⁄16" 20 ½" White
4SB242PB 32 ⅝" 24 ½" Polished Brass
4SB242SB 32 ⅝" 24 ½" Satin Brass
4SB242SN 32 ⅝" 24 ½" Satin Nickel
4SB242WH 32 ⅝" 24 ½" White
*Add this length (A) to Body length (C) from Body Spec Sheet(s) to get Total Luminaire Nominal OAL.

4SB224 (28) (35) (42)
Decorative, Pendalux Suspension, Basic Canopy
Page 2 of 2
