Linon 6280SF-AB-KD-U User manual

PAGE 4
STEP 3)
ATTENTION: ASSEMBLE THE TABLE FACE DOWN ON A CLEAN SURFACE (CARPET, CARTON, ETC), TO
AVOID SCRATCHING THE SURFACE.
3.1. ATTACH THE PRE- ASSEMBLED UNIT TO THE TABLE TOP #1, USING THE PRE-DRILLED HOLES AS
GUIDE AND THE WOODEN DOWELS ALREADY INSERTED AT PIECE # 3.
NOTE: THE TWO INSERTED WOODEN DOWELS AT PIECE #3 HAVE AS FUNCTION JUST TO CENTRALIZE
THE LEGS, UPPER AND LOWER RAILS AND PEDESTAL TO THE TOP #1.
3.2. LASTLY, FIX THESE PARTS USING (8) SCREWS (A), A PHILLIPS HEAD SCREWDRIVER (NOT PROVIDED)
AND THE PRE-DRILLED HOLES AS GUIDE, AS SHOWN ON FIGURE 3.
NOTE: THERE ARE (04) ADJUSTABLE BRACKETS ON LEGS #5 (4X). THEY WILL ENABLE YOU TO
ADJUST THE ROUND TABLE ALREADY ASSEMBLED ON THE FLOOR AND MAINTAIN IT BALANCED
(STABLE).
FIGURE 3
A
AA
AA
A
A
4
1
PAGE 1
ASSEMBLY INSTRUCTIONS
PEDESTAL TABLE
MODEL # 6280SF-AB-KD-U
WE ARE HERE TO HELP!
LINON HOME DECOR PRODUCTS, INC.
PLEASE READ ALL INSTRUCTIONS IN THIS BOOKLET BEFORE STARTING ASSEMBLY.
IMPORTANT:
TOLL FREE NUMBER 1.800.262.1852
MADE IN BRAZIL
FOR LINON HOME DECOR PRODUCTS, INC.
TEL: [phone] FAX: [phone]
e-mail: [email protected]
WE TRY TO INSURE THAT YOUR FURNITURE ARRIVES IN EXCELLENT CONDITIONS.OUR
SERVICE REPRESENTATIVES ARE READY TO HELP YOU WITH QUICK SERVICE.PLEASE
CALL IF A PART IS DAMAGED OR MISSING. PLEASE CALL PRIOR TO RETURNING THE
ITEM TO THE STORE. OUR OFFICE IS OPEM 9 AM TO 5 PM EASTERN STANDARD TIME.
04/03
29 1/2”
38 1/8”

A
16SCREW 2 3/8" LONG
WASHER
NUT
SCREW KEY
WOODEN DOWEL
04
04
01
02
B
C
D
E
1 - TABLE TOP
2 - UPPER RAIL
3 - LOWER RAIL
4 - PEDESTAL
5 - LEGS (4X)
STEP 2)
FIGURE 2
2.1. INSERT (2) WOODEN DOWELS (E) TO
LOWER RAIL #3, USING THE PRE-DRILLED
HOLES AS GUIDE.
2.2. ATTACH PIECES: UPPER RAIL #2 AND LOWER
RAIL #3 TO PEDESTAL #4 USING THE GROOVES
LOCATED AT PIECE #4 AS GUIDE, AS SHOWN ON
FIGURE 2.
2.3. NOW, FIX UPPER RAIL #2 AND LOWER RAIL #3
TO PEDESTAL #04 USING (08) SCREWS (A), A
STANDARD PHILLIPS HEAD SCREWDRIVER (NOT
PROVIDED) AND THE PRE-DRILLED HOLES AS GUIDE,
AS SHOWN ON DRAWING.
PAGE 3PAGE 2
OPEN HARDWARE PACKAGE ON A FLAT SURFACE COVERED WITH NEWSPAPER.
COUNT EACH PIECE OF HARDWARE TO MATCH THE QUANTITY NUMBER IN THE
HARDWARE LIST COLUMN. CALL CUSTOMER SERVICE IF ANY PARTS ARE MISSING.
FOLLOW THE LETTER IDENTIFICATION WHEN READING THE ASSEMBLY DRAWING
"A" THROUGH "E".
HARDWARE PACKAGE COUNT.
HARDWARE IDENTIFICATION
PARTS IDENTIFICATION
1
2
3
4
55
5
5
STEP 1)
FIGURE 1 DETAIL 1.1
1.1. ATTACH LEGS # 5 (4x) TO PEDESTAL # 4 USING THE WOODEN DOWELS ALREADY
INSERTED AT THE LEGS AND THE PRE-DRILLED HOLES AS GUIDE, AS SHOWN ON DRAWING..
1.2. THEN, FIX LEGS # 5 (4x) TO PEDESTAL # 4 USING (4) WASHERS (B), (4) NUTS (C)
AND THE SCREW KEY (PROVIDED “D”) AS SHOWN ON FIGURE 1. PLEASE SEE DETAIL 1.1.
PAGE 3
B
C
E
E
A
A
A
A
D
5
4
4
3
5
5
5
5
2
55
5
TOOLS REQUIRED:
A SCREW KEY (PROVIDED “D”) AND A PHILLIPS HEAD SCREWDRIVER (NOT PROVIDED)
ARE REQUIRED TO ASSEMBLE THIS UNIT.
