Lytecaster®Recessed Downlighting 2000LVNT
Page 1 of 1 3 3/4" Aperture Low Voltage MR16 Remote Transformer Frame-In Kit
Features
1. Mounting Frame: 0.036" galvanized steel. Accommodates all ceilings up
to1"thick. (Push-in/twist-out rotoclips hold reflector flush to ceiling.)
2. Junction Box: 4" x 3 1/2” x 2"; 0.063" galvanized steel. U.L. listed for;
maximum of 8 No. 12 ga. 90° C through branch circuit supply conductors
(75° C end of run). Integral cable clamps permit attachment of nonmetallic
Romex® or armored cable without need of additional connectors.
3. MountingBars: 0.059"galvanized steel 13"long bars extend to 27" with
integral nailing tabs. Attaches to wood joist without need of accessories.
4. Socket Housing: Aluminum, with lamp adjustment assembly allows 35°
max. vertical, 358° horizontal adjustment.
5. Socket: Field replaceable. Two pin socket, pre-wired with #18 SF1 leads to
junction box.
6. Transformer: Frame-in Kit is provided without transformer. Transformer
must be provided by others. Lightolier Cat. #8608 or 8609 transformers may
be used. Frame-in Kit is rated at 50VA. Use only 12V. A.C. input.
7. Thermal Protector: Meets NEC and UL requirements. Insulation must be
kept 3" away from fixture sides and wiring compartments and must not be
placed above fixture in a manner which will entrap heat.
Dimming
Dimming Controls: Use only dimmers specifically designed for use with
transformers, like Lightolier Onset®, Sunrise® series LV or VA dimmers, or any
Lightolier Controls dimming system. Low voltage fixtures may produce audible
sound when used with dimmers, which may be objectionable in acoustically criti-
cal areas.
Options and Accessories
Mounting Bars: 1964 - 20" set of (2)
T-Bar Ceiling Clips: 1956 - set of (4)
Plaster Ceiling Ring: 1959 - 7/8" deep for wet plaster ceilings.
MR16 Socket Replacement: 1975B
Remote Transformer: 8608 or 8609
Labels
UL (Suitable for Damp Locations), I.B.E.W.
Romex® is a registered trademark of General Cable Industries Inc.
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Frame-In Kit Reflector Trims — See Individual Reflector Trim Specification Sheets
Open Downlight Adjustable Enclosed
Aperture Cone Satin Cone Baffles Slot Pinhole Mini Swivel Diffuser
2000LVNT 2012 2008 2005 2006 2011 2025WH 2090LV
2012NM 2008NM 2005WH 2026WH
2013BKNM 2010 2005BNM
2013CD 2010NM 2005NM
2013CDNM
2013NM
2013BK
2013WH
2013
2013WD
2013WDP
