Lytecaster Recessed Downlighting 304X
Page 1 of 2 3 3/4" (95mm) Aperture Adjustable Specular Cone MR16 & ES/ESD16
Complete fixture consists of Reflector Trim & Frame-In Kit. Select each separately
Reflector Trim Frame-In Kit Lamp
304BAX
304CLX
304CCDX
Specular Black Specular and White Flange
Specular Clear Specular and White Flange
Specular Gold Specular and White Flange
Remodeler
Remodeler
Remodeler
Non-IC
Non-IC
Non-IC
IC
IC
IC
Air Seal / IC
Air Seal / IC
Air Seal / IC
300MRSPX
3401MREX
300ESX
302MRSPX
302MREX
302ESX
302MRIC7SPX*
302MRIC9SPX
302ESICX
302MRAICSPX
302MRAICEX
302ESAICX
50W MR16
50W MR16
50W ES/ESD16 (GZ10)
50W MR16
50W MR16
50W ES/ESD16 (GZ10)
50W MR16 (37W MR16*)
50W MR16
50W ES/ESD16 (GZ10)
50W MR16
50W MR16
50W ES/ESD16 (GZ10)
Features
1. Housing: 25ga. galvanized steel.
2. Residence Mounting Clip: Factory-installed ; zinc plated spring steel;
free-hand installation.
3. Flange Housing: Cold rolled steel 22ga. White trim flange.
4. Aperture Cone: 18ga. hydroformed aluminum. Specular finish.
5. Adjustable Lampholder Support: 27ga. steel ;
Rotates 358˚ horizontally and 0° to 35° vertically.
6. Mounting Clips (2): 24ga. spring steel, zinc plated. Provide easy snap-in /
snap-out action.
7. Lamp Guard: 2" (51mm) dia. borosilicate glass.
Frame-In Kit
Note: For complete Frame-In Kit specifications,
see 300 frame specification sheets.
* Self-Flanged trims 37W Max.
Labels
CSA, UL Suitable for damp locations.
4 1/2"
1"MAX
1/8"
4 1/2"
2 7/8"
