Next 654755 User manual

GIRLS LOCKER ROBE
654755
Assembly instruction
Actual product size
Actual product size
H82.5 x W55 x D50cm
H169 x W76 x D50 cm
IMPORTANT - RETAIN FOR FUTURE REFERENCE
Produced in China for NEXT retail Ltd. 1

654755-2014-V 1.
GIRLS LOCKER ROBE
654755
Assembly instruction
Warnings Number of people required to assemble
Important: Retain these instructions for future reference
Time to assemble
This product should only be used on firm level ground.
Please periodically check all fittings and re-tighten as necessary
Please do not sit or stand on your furniture
Tips
Do's
Tools required
Missing parts
Home service technicians
Dont's
You can write to us at
Produced in China for NEXT retail Ltd. 2
Need two person to lift the unit into position.
We suggest you spend a short time reading through the leaflet before
you start
Keep fittings out of children’s reach and keep children well away from
construction area.
Avoid exposing the furniture to excessive heat or direct sunlight as
this can cause deterioration of the colour
Unwrap all packaging materials and place the components on top of
the carton box or on a clean floor to protect it from damage
BEFORE YOU START
To view our full furniture range please visit www.next.co.uk
Next Retail Ltd.
Desford Road,
Leicester,
LE19 4AT
If you have a fault with your product. Please contact our customer service team on
0333 777 8999 . If you have had the product for 28 days or less you may be offered
a replacement,refund or for a fully trained home service technician to visit your home
to assess the fault and repair the product where possible. If you have had the
product for more than 28 days we will send an independant home service technician
to review and repair the product where possible and recommend further action.
Wipe occasionally with a soft cloth slightly dampened with water. Then
buff with a dry clean soft cloth
Do not tighten screws until fully assembled.
Do not overtighten screws or bolts.
Look out for the symbol througout this manual. Wherever you see it we will have a
handy tip to help you with the assembly of your product.
When you are ready to start. Make sure that you have the right tools.
Plenty of space and a clean, dry area for assembly
Due to the size of this product we recomment that it is assembled in
the room intended for use.
Unwrap all packaging materials and place the components on a clean
surface to protect it from damage, We recommend that the packaging
is used to protect the surfaces during assembly.
Carefully check that you have all the parts before beginning assembly
We suggest you retain these instructions for future reference
Do not use power tools to construct this product.
If you are missing any fixtures and fittings for your product. Please contact our
customer service team on 0333 777 8999 and they will be happy to arrange for a
replacement to be sent to you free of charge.
Do not use silicone based furniture polish. Silicone in furniture
polishes can break down the finish.
Never allow any kind of liquid to remain on your furniture. Absorption
can cause wood to warp or finishes to de-laminate.
Due to the size of the product we recommend that it is assembled in
the room intended for use
Do not use this product if parts are missing, damagerd or worm.
Ensure the product is fully assembled as illustrated and all fixings fully
tightened before use. Check fixings regularly to ensure they remain
tight
Do not drag or pull your furniture.

654755-2014-V 1.
GIRLS LOCKER ROBE
654755
Assembly instruction
GETTING TO KNOW YOUR PRODUCT

Produced in China for NEXT retail Ltd. 3
654755-2014-V 1.
GIRLS LOCKER ROBE
654755
Assembly instruction
Ref Visual Q'ty
11
21
31
41
51
61
71
81
91
10 1
11 1
12 1
50 x 76 cm
45 x 75.5 cm
38 x 165 cm
If you have any problem with this product or require any replacement fitting please contact customer services 0333 777 8999
Components supplied
CUSTOMER HELPLINE
26 x 76 cm
D 2 x 76 cm
50 x 165 cm
37 x 156 cm
50 x 165 cm
47 x 75.5 cm
Dimensions
26 x 76 cm
39 x 165 cm
35.5 x 156 cm

Produced in China for NEXT retail Ltd.
654775-2014-V 1.
GIRLS LOCKER ROBE
654755
Assembly instruction
Ref Q'ty
A 4
B 2
C 4
F 1
G D 8 x 4 mm 4
Fixture and fittings supplied
D 2
E 1
Fixture and fittings supplied (actual size)
12 x 140 mm
12 x 145 mm
D 12 x 4 mm
M4 x 10 mm
CUSTOMER HELPLINE
If you have any problem with this product or require any replacement fitting please contact customer services 0333 777 8999
Dimensions
4x12 mm
6x85 mm

Produced in China for NEXT retail Ltd. 4
654755-2014-V 1.
GIRLS LOCKER ROBE
654755
Assembly instruction
1
2
1
4
3
1
4
3
2
NB: Make sure the holes on leg 2 which face towards the back of the item as shown in the diagram.

Produced in China for NEXT retail Ltd. 5
654755-2014-V 1.
GIRLS LOCKER ROBE
654755
Assembly instruction
3
4
3
5
4
6
4
3
10
4
3

Produced in China for NEXT retail Ltd. 6
654755-2014-V 1.
GIRLS LOCKER ROBE
654755
Assembly instruction
5
6
11
3
4
4
3
11
9

Produced in China for NEXT retail Ltd. 7
654755-2014-V 1.
GIRLS LOCKER ROBE
654755
Assembly instruction
7
8
12
3
4

X 2
Produced in China for NEXT retail Ltd. 8
654755-2014-V 1.
GIRLS LOCKER ROBE
654755
Assembly instruction
9

Produced in China for NEXT retail Ltd. 9
654755-2014-V 1.
GIRLS LOCKER ROBE
654755
Assembly instruction
10
1. Use screws (F) to secure the nylon straps (E )o the back panel 5.
2. Secure the other end of strap to the wall with anappropriate screw and wall plug for your wall type.
WARNING: Always ensure intended wall area to be drilled is free from hidden electrical wires, water and gas pipes.
NB: Wall fixings are not included, please source suitable fixings for your wall type, if in doubt, please consult a qualified

Produced in China for NEXT retail Ltd. 10
654755-2014-V 1.
