Symmetric Reflector SV5R Series
Page 1 of 2 White or Specular for 1 or 2 Lamp T5 Strip, 22”, 34” or 46” Lengths,
Features
• Only 1 3/8" deep.
• Installation on regular SV T5 strip, 1 or 2 lamps.
• Available in white or high reflectivity specular finish.
• Optional micro-perforated or slotted white reflector.
Dimensions
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
Copyright 2002 Lightolier Section 3A/Folio H120-22
5/03
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Job Information Type:

Symmetric Reflector SV5R Series
Page 2 of 2 White or Specular for 1 or 2 Lamp T5 Strip, 22”, 34” or 46” Lengths
Photometry Model No. SV4S254UNVPG/SV5R1W4SSLD
Ordering Information
Explanation of Catalog Number. Example: SV5R1W4SSLD
Options & Accessories
Wire Guard: White wire guard to work with SV5 Symmetric reflector. Catalog
number SV5G1W3S for 34” Symmetric Reflector; SV5G1W4S for 46” Symmetric
Reflector.
Specifications
Materials: Die-formed heavy gauge cold rolled steel.
Reflector: White - phosphate undercoating, baked white acrylic matte high
reflectance paint finish. Specular - Reflective plane made of high purity
aluminium, total reflectivity of 95% without iridescence.
1S
Reflector Style Reflector Length
2 = 22”
3 = 34”
4 = 46”
Light Distibution
S = Symmetric
Reflector Style:
SLD = Solid
SLT = Slotted (white only)
PER = Micro-perforated (white only)
SV5R
Reflector Type
Reflector for SVT5 Strip
(order strip separately)
Finish
W = White
S = Specular
