WATSON Haven User manual

ASSEMBLY
360.394.1300 watsonfurniture.com
V.21.1 1/2022
Haven Laptop Table

2 HAVEN LAPTOP TABLE ASSEMBLY INSTRUCTIONS
Laptop Table Components
Vertical Support
Table Base
Table Surface - Laminate Option Table Surface - Steel Option
Hardware
M8 X 1.25 x 20
Flat Head Screw
(0003014)
Tools
Electric Drill T25 Torx Bit
*For Laminate Surface
3mm Hex Bit
*For Steel Surface
M6 X 1 X 8mm
Low Profile Screw
(0001259)
#10 x 5/8 Torx Screw
(0002148)

3 HAVEN LAPTOP TABLE ASSEMBLY INSTRUCTIONS
Laminate Surface Option: Attach Vertical Support to Surface
Lay the surface upside down on a soft surface so that the pilot holes are
facing upward. Place the vertical support top plate in the dado and secure
it with (5) screws.
1A.
Steel Surface Option: Attach Vertical Support to Surface
Lay the surface upside down on a soft surface so that welded bracket is facing upward.
Align the vertical support top plate with the bracket and secure it with (5) screws.
1B.
M6 X 1 X 8mm
Low Profile Screw
(0001259)
#10 x 5/8 Torx Screw
(0002148)

4 HAVEN LAPTOP TABLE ASSEMBLY INSTRUCTIONS
Connect Base Plate to Vertical Support
With the surface still upside down, hold the base with sliders and
countersinks facing up and align the screw cutouts with the holes in the
vertical support. Secure the base with (2) screws.
2.
M8 X 1.25 x 20
Flat Head Screw
(0003014)
