Calculite®HID Adjustable Pinhole C4MRP
Page 1 of 2 4 1/2" Aperture (1) 20W CMH MR16
15"
7" 8"
9.66"
9.66"
7.41"
Frame-In Kit
Ceiling Cutout: 5 1/16" (129 mm) Dia. Ceiling Thickness: 1 1/8” Max
Trim Kit Frame-In Kit Lamp
C4MRP WH
C4MRP BK
Matte White Trim Plate, White Baffle, Flanged
Matte White Trim Plate, Black Baffle, Flanged
C420MREU – Electronic 120/277V Non-IC (1) 20W MR16 CMH GX10 Base
Features
1. Baffle: Die-cast aluminum. 1 ¼” diameter miniature baffle minimizes view
into fixtures. Permanently fastened to trim plate.
2. Trim Plate: Die-cast aluminum plate (matte white) overlaps ceiling cut-out
for clean look in finishing ceiling.
3. Lamp Support: Die-formed aluminum with knurled surface for easy gripping
during relamping. Spring tension clips hold lamp and lens, allow fast snap-in,
snap-out relamping. Matte black finish.
NOTE: HID lampholder ship with the frame. Discard the incandescent
lampholder that ships standard with the trims.
4. Trim Kit Vertical Adjustment Mechanism: Die-cast aluminum. Built in
aperture shield blocks view into fixture. Provides 0°-45° (35° max. with
remodel fik) vertical tilt up to 1” thick ceiling, less in thicker ceilings; lockable.
EZ-Aim Helical Drive System provides fast and accurate hot aiming with
Philips screwdriver. Matte black finish. Lamp shield keeps interior of fixture
dark.
5. Horizontal Adjustment Mechanism: Die-form steel ring, matte black
finish. Provides 360° horizontal stop, lockable.
6. Frame Vertical Adjustment Mechanism: Accommodates mounting to
virtually any ceiling system using pre-installed mounting bars, or ½” EMT
tubing (by others). Single locking feature secures all adjustments. Alignment
holes and markings allow fixture to be pre-set prior to installation. Final
adjustment can be made from below inside fixture. Attaches to steel or wood
joists without accessories.
7. Mounting Bars: Galvanized steel, 0.048”; pre-installed telescoping bars
extend from 30” long and lock securely into position. Built-in locking tabs
provide positive attachment to common T-bars systems. Self-centering
feature simplified installation in 24” O.C. grid systems.
Features (Continued)
8. Socket Harness: Twist and lock base. 5kV (600V) pulse rated PPS, black
T240 body socket with nickel-plated contacts. 18 AWG silicone leads with
fiberglass outer sleeve
Options and Accessories
Accepts one accessory
Labels
U.L (Suitable for Damp Locations)
Teflon®is a registered trademark of E.I. DuPont.

631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • C0711
Calculite®HID Adjustable Pinhole C4MRP
Page 2 of 2 4 1/2" Aperture (1) 20W CMH MR16
Job Information Type:
200
400
600
800
0°
30°
60°
90°
500
1000
1500
0°
30°
60°
90°
20W G.E.HID MR16, 12° SPOT, GX10 BASE
1250
2500
3750
5000
0°
30°
60°
90°
20W G.E.HID MR16, 25° FLOOD,GX10 BASE
20W G.E.HID MR16, 40° WIDE FLOOD, GX10 BASE
LAMP @ 30 DEGREE VERTICAL TILT
LUMEN RATING = 1000 LMS.
CBCP = 5585 CD
BEAM ANGLE = 12°
TEST REPORT NO. 3400FR
LAMP @ 30 DEGREE VERTICAL TILT
LUMEN RATING = 1000 LMS.
CBCP = 1619 CD
BEAM ANGLE = 20°
TEST REPORT NO. 3397FR
CANDLEPOWER SUMMARY
Angle CP
0 57
5 59
10 75
15 185
20 733
25 2705
30 5585
35 2363
40 609
45 127
50 37
55 7
60 0
65 0
70 0
75 0
80 0
85 0
90 0
LAMP @ 30 DEGREE VERTICAL TILT
LUMEN RATING = 1000 LMS.
CBCP = 812 CD
BEAM ANGLE = 30°
TEST REPORT NO. 3387FR
CANDLEPOWER SUMMARY
Angle CP
0 36
5 53
10 112
15 324
20 945
25 1548
30 1619
35 1369
40 858
45 330
50 67
55 14
60 0
65 0
70 0
75 0
80 0
85 0
90 0
CANDLEPOWER SUMMARY
Angle CP
0 26
5 46
10 78
15 171
20 407
25 691
30 812
35 733
40 557
45 372
50 205
55 34
60 1
65 0
70 0
75 0
80 0
85 0
90 0
30° DEGREE AIMING ANGLE HORIZONTAL SURFACE
DC FC L W
6' 3.5' 101 1.7' 1.5'
8' 4.6' 57 2.3' 1.9'
10' 5.8' 36 2.8' 2.4'
12' 6.9' 25 3.4' 2.9'
14' 8.1' 19 3.9' 3.4'
30° DEGREE AIMING ANGLE VERTICAL SURFACE
DC FC L W
2' 3.5' 175 1.7' 0.8'
3' 5.2' 78 2.6' 1.3'
4' 6.9' 44 3.5' 1.7'
5' 8.7' 28 4.3' 2.1'
6' 10.4' 19 5.2' 2.5'
30° DEGREE AIMING ANGLE HORIZONTAL SURFACE
DC FC L W
6' 3.5' 29 2.9' 2.4'
8' 4.6' 16 3.8' 3.3'
10' 5.8' 11 4.8' 4.1'
12' 6.9' 7 5.7' 4.9'
14' 8.1' 5 6.7' 5.7'
30° DEGREE AIMING ANGLE VERTICAL SURFACE
DC FC L W
2' 3.5' 51 3.1' 1.4'
3' 5.2' 22 4.7' 2.1'
4' 6.9 13' 6.2' 2.8'
5' 8.7' 8 7.8' 3.5'
6' 10.4' 6 9.3' 4.2'
30° DEGREE AIMING ANGLE HORIZONTAL SURFACE
DC FC L W
6' 3.5' 15 4.4' 3.7'
8' 4.6' 8 5.9' 5.0'
10' 5.8' 5 7.3' 6.2'
12' 6.9' 4 8.5' 7.4'
14' 8.1' 3 10.2' 8.7'
30° DEGREE AIMING ANGLE VERTICAL SURFACE
DC FC L W
2' 3.5' 25 5.5' 2.1'
3' 5.2' 11 8.2' 3.2'
4' 6.9' 6 10.9' 4.3'
5' 8.7' 4 13.7' 5.4'
6' 10.4' 3 16.4' 6.4'
