Lightolier Calculite C6AD User manual

Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Group LLC • D0711
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Calculite® Evolution Incandescent Open Downlight C6AD
Page 1 of 2 6" Aperture A19 / A21 / BT15 / MB19 Reflector Trim
876
54321
Perspec. Drawing Nos.
Calculite Evolution
Ceiling Cutout: 6 11/16" Dia.
Reflector Trim Frame-In Kit
C6AD CLW Specular Clear, White Flange Shallow Shallow Shallow Deep Deep Deep
C6AD CLP Specular Clear, Polished Flange Non-IC Non-IC AirSeal® IC-AirSeal® Non-IC Non-IC AirSeal® IC-AirSeal®
C6AD Add suffix. See options for other finishes. C6120 C6A120 C6AIC C6D120 C6DA120 C6DAIC
100W A19, MB19 100W A19, BT15, MB19 100W A19, MB19
100W BT15 150W A21 100W BT15
150W A21
14 1/4"
10"
8 1/2"
(10 1/4")
(18 1/8")
(13 1/2")
IC AirSeal®
C6AIC / (C6DAIC)
Non-IC AirSeal®
C6A120 / (C6DA120)
Non-IC
C6120 / (C6D120)
(24 1/4" O.A.)
(17 3/8"O.A.)
(9 1/8")
7 3/4"
9 1/2" DIA.
(12 1/4" DIA.)
(15 3/4")
(15 3/8" O.A.)
(9 1/8")
(12 1/4" DIA.)
20 1/4" O.A. Included)
(Mounting Bars
Adjustment
Included)
(Mounting Bars
Adjustment 13 3/4" TO 24"
9 1/2" DIA.
14 3/8" O.A.
7 3/4" 12 1/2"
12 3/8" O.A.
13 3/4" TO 24"
Note: Dimensions in parentheses refer to the C6D series deep Frame-In-Kits.
Features
1. Reflector: 16 ga. aluminum, 50° visual cut- off to lamp and lamp image,
medium spread distribution. Available with painted white or polished
flange. Interchangeable with other Evolution 6” line voltage trims.
2. Socket Harness: Spring tension clips snap into die-cast aluminum top
at pre-focused positions insuring correct optical alignment. Medium base
porcelain socket with nickel plated screw shell, No. 18 SF-1 leads to keyed
plug-in quick connector for power connection to junction box.
3. Frame-in-Kit: Compatible frame-in kits are listed above. See separate
frame-in kit specification sheets for details.
Non-IC and Non-IC AirSeal® - Insulation must be kept 3” away from fixture
sides and wiring compartments and must not be placed above fixture in a
manner which will entrap heat.
IC-AirSeal® - Fixture may be in direct contact with insulation.
Options & Accessories
Reflector Finishes1
Clear: CL
Comfort Clear Diffuse: CCD
Champagne Bronze: CCZ
Gold: GD
White: WH
1Specify desired flange: WWhite, PPolished
Labels
UL Listed (suitable for damp locations), I.B.E.W.
132
C6 series
**11 1/8"min. is for up to 3/4" thick ceiling.
C6ADCLW / C6D120 or C6ADCLW / C6DA120
C6ADCLW / C6120 or C6ADCLW / C6A120
8"
(10 3/8" )
6" Dia.
7 1/4" Dia.
*8 3/4"min. is for up to 3/4" thick ceiling. 1/2" to 1 1/4" Max. Ceiling Thk.
(11 7/8" max.)
(11 1/8" min.)**
C6 series
9 1/4" max.
8 3/4" min.*
(C6ADCLW / C6DAIC)
(11 1/4")
C6ADCLW / C6AIC
1/2" to 1" Thk. Ceiling
9 1/4"

Job Information Type:
Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Group LLC • D0711
Calculite® Evolution Incandescent Open Downlight C6AD
Page 2 of 2 6" Aperture A19 / A21 / BT15 / MB19 Reflector Trim
876
54321
Perspec. Drawing Nos.
Calculite Evolution
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY REFLECTANCE
80 70 50 30 10 0
% WALL REFLECTANCE
50 30 10 50 30 10 50 30 10 50 30 10 50 30 10 0
1 .64 .63 .62 .63 .62 .61 .61 .60 .59 .59 .58 .57 .57 .56 .56 .55
2 .61 .59 .57 .60 .58 .56 .58 .56 .55 .56 .55 .54 .55 .54 .53 .52
3 .57 .55 .53 .56 .54 .53 .55 .53 .52 .54 .52 .51 .53 .51 .50 .49
4 .54 .52 .50 .54 .51 .49 .53 .50 .49 .51 .50 .48 .50 .49 .48 .47
5 .51 .48 .46 .51 .48 .46 .50 .48 .46 .49 .47 .45 .48 .46 .45 .44
6 .49 .46 .44 .48 .46 .44 .48 .45 .43 .47 .45 .43 .46 .44 .43 .42
7 .46 .43 .41 .46 .43 .41 .45 .42 .41 .44 .42 .40 .44 .42 .40 .40
8 .44 .41 .39 .43 .40 .38 .43 .40 .38 .42 .40 .38 .42 .39 .38 .37
9 .41 .38 .36 .41 .38 .36 .40 .38 .36 .40 .37 .36 .39 .37 .35 .35
10 .39 .36 .34 .39 .36 .34 .38 .35 .34 .38 .35 .34 .37 .35 .33 .33
20% FLOOR CAVITY REFLECTANCE
ROOM CAVITY RATIO
SPACING RATIO = 1.1
Date: July 20, 1999
Prepared for Lightolier, Fall River, MA
SPACING RATIO = 0.9
Date: July 19, 1999
Prepared for Lightolier, Fall River, MA
Conversion Factors
60W to 100W BT15: Clear C.U. x 1.00; Diffuse/Gold, C.U. x 0.90
60W to 100W MB19: Clear C.U. x 0.95; Diffuse/Gold, C.U. x 0.85
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY REFLECTANCE
80 70 50 30 10 0
% WALL REFLECTANCE
50 30 10 50 30 10 50 30 10 50 30 10 50 30 10 0
1 .63 .62 .61 .6 61 .60 .60 .59 .58 .57 .57 .56 .56 .55 .55 .54
2 .59 .57 .56 .58 .57 .55 .57 .55 .54 .55 .54 .53 .53 .53 .52 .51
3 .56 .53 .51 .55 .53 .51 .54 .52 .50 .52 .51 .49 .51 .50 .49 .48
4 .53 .50 .48 .52 .50 .48 .51 .49 .47 .50 .48 .47 .49 .47 .46 .45
5 .50 .47 .45 .49 .46 .44 .48 .46 .44 .47 .45 .44 .46 .45 .43 .42
6 .47 .44 .42 .46 .44 .42 .46 .43 .41 .45 .43 .41 .44 .42 .41 .40
7 .44 .41 .39 .44 .41 .39 .43 .40 .39 .42 .40 .38 .42 .40 .38 .37
8 .41 .38 .36 .41 .38 .36 .40 .38 .36 .40 .38 .36 .39 .37 .36 .35
9 .39 .36 .34 .39 .36 .34 .38 .35 .33 .38 .35 .33 .37 .35 .33 .32
10 .36 .33 .31 .36 .33 .31 .36 .33 .31 .35 .33 .31 .35 .33 .31 .30
20% FLOOR CAVITY REFLECTANCE
ROOM CAVITY RATIO
CERTIFIED TEST REPORT NO. 0833FR
COMPUTED BY LSI PROGRAM **TEST-LITE**
RECESSED OPEN REFLECTOR DOWNLIGHT
6” DIA. APERTURE, SPECULAR CLEAR FINISH REFLECTOR
150W A-21 SYLVANIA LAMP. LUMEN RATING = 2780 LMS.
CERTIFIED TEST REPORT NO. 0835FR
COMPUTED BY LSI PROGRAM **TEST-LITE**
CALCULITE 6” DIA/ APERTURE BY-LAMP OPEN DOWNLIGHT
CAT. #C6AIC120/C6ADCLW, SPECULAR CLEAR FINISH REFLECTOR
100W BT15 PHILLIPS LAMP. LUMEN RATING = 1880 LMS. LOWER POSITION
CANDLEPOWER SUMMARY
ANGLE MEAN CP LUMENS
0 1390
5 1375 131
10 1338
15 1284 364
20 1224
25 1119 509
30 934
35 696 432
40 422
45 114 129
50 16
55 3 5
60 1
65 0 0
70 0
75 0 0
80 0
85 0 0
90 0
ZONAL LUMENS AND PERCENTAGES
ZONE LUMENS % LAMP % LUMINAIRE
0-30 1003 36.08 63.94
0-40 1434 51.60 91.46
0-60 1568 56.42 99.99
0-90 1568 56.42 100.00
40-90 134 4.82 8.54
60-90 0 .01 .01
90-180 0 .00 .00
0-180 1568 56.42 100.00
**EFFICIENCY = 56.4% **
CANDLEPOWER SUMMARY
ANGLE MEAN CP LUMENS
0 1204
5 1171 111
10 1090
15 1002 283
20 897
25 771 348
30 567
35 394 250
40 239
45 85 82
50 12
55 2 4
60 1
65 0 0
70 0
75 0 0
80 0
85 0 0
90 0
ZONAL LUMENS AND PERCENTAGES
ZONE LUMENS % LAMP % LUMINAIRE
0-30 741 39.42 68.82
0-40 991 52.75 92.08
0-60 1076 57.27 99.98
0-90 1076 5728 100.00
40-90 85 4.54 7.92
60-90 0 .01 .02
90-180 0 .00 .00
0-180 1076 57.28 100.00
**EFFICIENCY = 57.3% **
Tested according to IES procedures. Test
distance exceeds five times the greatest
luminous opening of luminaire.
Tested according to IES procedures. Test
distance exceeds five times the greatest
luminous opening of luminaire.
Conversion Factors
150W A21: Clear; C.U. x 1.0; Diffuse/Gold. C.U. x 0.90FL
60W - 100W A19: Clear; C.U. x 1.15; Diffuse/Gold. C.U. x 1.0FL
