INSTRUCTION MANUAL
S3030, REV A
15W COB
Under-hood Light
The new super bright Under-hood Light for
powerful illumination of the entire engine bay.
Shines brighter, grips stronger & outlasts most
other lights!
15W COB Under-hood Light
3 powerful COB lamps of 5W each
Light Output
Single button, user controlled light output for
maximized operating time. Choose between three
light sittings-high, medium & low
Sturdy Construction
a. Aluminium extruded body with ABS coating.
Built to withstand the toughest of job site
conditions
b. Soft padded aluminium hooks resist wear and
provide scratch proof grip. Large gripping
surface provides larger contact for better
positioning when mounting the light under-
hood, undercarriage or elsewhere
c. 3 light bulbs with sturdy polycarbonate lens to
withstand the toughest of job site conditions
d. Fully adjustable light head: bulbs can be
rotated 40° to provide the optimum light
angle depending upon job need
LED-351
LITHIUM-ION
RECHARGEABLE
Rechargeable
Battery
3.7V 5200 Mah
FEATURES
BEAM
ANGLE
60°
−5°C TO 40°C
(−23°F TO 104°F)
OPERATING TEMPERATURE
INTENSITY
HIGH MEDIUM LOW
NR. OF LAMPS USED 3 2 1
LUMEN 1000 700 350
RUN TIME 3 hours 5 hours 7 hours
CAT NR. SIZE (L×H×D)
(INCH) (MM)
LED/351 47-21/32 × 3 × 2-3/8 1210 × 75 × 60
Expandable Length
47 - 69 inch
(1200 mm - 1750 mm)
NEW!
RoHs
Light bulbs pivot
independently
to direct light as
needed
Soft padded
aluminium hooks for
scratch proof grip
USB charging port
with LED charging
indicators
Expandable Length
47 - 69 inch (1200 mm - 1750 mm)
This covers wide cars & trucks, making it a perfect
choice for mechanics working in automotive
shops or fleet maintenance
Power Source
Charging of Battery
Battery can be recharged using in-built USB
charging port protected by rubber bezel
Complete with USB cable and AC Power Adaptor
Charging Time
4 hours

2
SAFETY INFORMATION
• Keep the work area clean and dry. Damp or
wet work areas can result in injury.
• Check for damaged parts and any other
conditions that may aect the operation
of this product. Replaced damaged parts
immediately
• Do not use the lamp in the immediate vicinity
of inflammable materials or gases.
• Only use the accessories included with the
product.
• Keep the lamp out of reach of unauthorized
persons, especially children.
• Do not point the light directly in your own or
any other person’s or animal’s eyes.
• Do not attempt to open the battery
compartment.
PACKAGING CONTENT
NOMENCLATURE
1. Hooks for mounting
2. 3 COB LEDs
3. Battery status LEDs
4. Charging Micro USB port
5. ON/OFF Button
OPERATING INSTRUCTIONS
(Refer “NOMENCLATURE”)
Charging:
• Before charging, make sure the work light is
turned o.
• Connect the micro USB end of the charging
cable to the micro USB port on the work light.
• Insert the USB end of the cable into the USB
port on the wall charger.
• Plug the AC charger into a live AC outlet. The
green LEDs will light, to indicate battery status.
• Charging will take 7-8 hours. When the battery
is fully charged, all four LEDs will be lit. When
fully charged, unplug from the AC outlet, and
then from the work light. The work light is now
ready for use.
• Fully charge the battery before the first use.
Operation:
• To switch ON the light press the button at the
side of the unit.
• Press the button once to switch on one
(center) light.
• Press the button twice to switch on two lights.
• Press the button thrice to switch on all 3 lights.
• Press the button four times to switch o the
lights.
MAINTENANCE
• Before cleaning the LED work light, disconnect
the USB cable (if being charged) and allow the
work light to cool down suciently.
• Clean with a dry or slightly moist, clean, lint
free cloth and a mild detergent if required.
• Do not use cleaners that contain abrasives or
solvents.
• Check the LED work light for damage before
each use. If the lens is damaged it must be
replaced immediately.
• Clean any dirt from the housing or the lens
immediately, since it could cause overheating.
DISPOSAL
The components or the used products must be
given to companies that specialize in the disposal
and recycling of industrial waste.
DESCRIPTION QUANTITY
Light 1
USB cable 1
Adaptor 1
125 4 3

3
