Lightolier Calculite ProSpec PA4H3070 User manual

12
3
4
5
6
7
8
9
10
11
12
13
Flanged Trimless
Top View
8 3/4"
Depth
6" OC
39 1/2" L X 10" W
1 3/4"
6" OC 6" OC
13"
8"
41 15/16"
16"


24" L X 6" W Opening
24 1/16" L X 7 3/16" W Cutout
Calculite® ProSpec®Linear Downlight PA4H3070
Page 1 of 2 4 Light PAR30 MH Series A
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
L ghtol er a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • (50 ) 679- 131 • Fax (50 ) 674-4710
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Thomas Group LLC (Lightolier Division) • B0711
Features
1. Aperture Frame: Provides clean support for lamp holders and overlapping
flange or trimless installation. Extruded aluminum. Rigidly welded together
on all corners.
2. Med a Cartr dge: Allows convenient loading and removal of up to two
accessories. Easily installed and removed for lamping with a simple twisting
motion. Constructed of die-formed aluminum.
3 Cross Blade Louver: Extruded aluminum. 1" deep, provides additional
shielding and can be easily removed.
4. Adjustable R ng: Allows 35° (on width) and 45° (on length) vertical
adjustment.
5. Tort ont te Spr ng: For easy installation of aperture frame.
6. Hous ng: Die-formed NYC 20 ga. steel. Finish: Black
7. Mount ng Brackets: Adjustable vertically from outside of housing.
8 Thermal Protector: Meets NEC, CEC, UL, and CSA requirements.
9. Lampholder: Porcelain medium based; nickel plated screw shell. 5KV pulse
rated, prewired with #1 SF-1 leads to ballast housing.
10 Junct on Box: 14 ga. steel, 4" x 3 1/2" x 3" box. Allows inspection from
below.
11. Ballast Hous ng: Die-formed 1 ga. steel.
12. Lamp and Accessory Support: .032" steel, flared for easy entry of Media
Cartridge.
13. Lens Reta n ng R ng: .093" spring steel rod. Holds accessories in place.
Electr cal
Electron c Ballast: Individual for each lamp. High Power Factor. Input watts:
7 , line current: .67 amps. Accessible from below.
UL listed for through branch circuit wiring with maximum of ( ) no.12 AWG 90°C.
Ce l ng Cutout: 24 1/16" L x 7 3 /16" W
Order ng Informat on: PAR30 MH Ser es A
Cat. No. Lamp Ce l ng Tr m Aperture F n sh
PA4H3070BL (4) 70W PAR30 MH Overlap Black with White Flange
PA4H3070WL (4) 70W PAR30 MH Overlap White with White Flange
PA4H3070BTL (4) 70W PAR30 MH Trimless Black
PA4H3070WTL (4) 70W PAR30 MH Trimless White
F n sh
All painted finishes are powder coated baked enamel.
Opt ons & Accessor es
Accessor es: 3 3/4" dia. series, filters, lenses, screens, and louvers. (1) max.
Label
UL/cUL (Suitable for Damp Location), I.B.E.W.
MasterColor®is a registered trademark of Koninklijke Philips Electronics N.V.
PA4H3070BL = (Flanged) Black/White
PA4H3070WL = (Flanged) White
PA4H3070BTL = (Trimless) Black
PA4H3070WTL = (Trimless) White

(FC) is initial footcandles at center of
beam.
Beam length (L) and beam width (W) are
to where the candlepower is reduced to
50% of center beam candlepower.
CBCP is center beam candlepower. (C) is
distance to the center of the beam.
Performance data shown is based on bare
lamp photometrics of MasterColor™
lamps by Philips Lighting. Contact lamp
manufacturers for availability and
performance.
Accent L ght ng performance data
PA4H3070
04/01
0° A m ng Angle 30° A m ng Angle 30° A m ng Angle 45° A m ng Angle
D FC LW DC FC LW D CFC LW D CFC LW
Beam Spread Rated
50% Max CP CBCP Life-Hrs
9000
9000
6 000
10000
10°
Lamp
70W PAR30
(MC/MH) FL
70W PAR30
(MC/MH) SP
70W
15’ 302 2.6’ 2.6’
20’ 170 3.5’ 3.5’
25’ 109 4.4’ 4.4’
30’ 76 5.2’ 5.2’
’ .0’ 376 2. ’ 2.0’
12’ 12.0’ 167 4.2’ 3.0’
1’ 16.0’ 74 5.6’ 4.0’
20’ 20.0’ 60 7.1’ 4.9’
7’ 204 5.1’ 5.1’
10’ 100 7.3’ 7.3’
13’ 59 9.5’ 9.5’
16’ 39 11.6’ 11.6’
6’ 3.5’ 1 0 6.1’ 5.0’
9’ 5.2’ 0 9.1’ 7.6’
12’ 6.9’ 45 12.2’ 10.1’
15’ .7’ 29 15.2’ 12.6’
4’ 4.0’ 221 6.7’ 4.1’
6’ 6.0’ 9 10.1’ 6.2’
’ .0’ 55 13.4’ .2’
10’ 10.0’ 35 16. ’ 10.3’
2’ 3.5’ 313 9.7’ 2.9’
3’ 5.2’ 139 14.5’ 4.4’
4’ 6.9’ 7 19.3’ 5. ’
5’ .7’ 50 24.2’ 7.3’
10’ 5. ’ 442 2.3’ 2.0’
15’ .7’ 196 3.5’ 3.0’
20’ 11.5’ 110 4.7’ 4.0’
25' 14.4’ 71 5. ’ 5.1’
5’ .7’ 340 3.6’ 1.7’
’ 13.9’ 133 5.7’ 2.9’
11’ 19.1’ 70 7.9’ 3. ’
14’ 24.2’ 43 10.0’ 4.9’
40°
Calculite® ProSpec®Linear Downlight PA4H3070
Page 2 of 2 4 Light PAR30 MH Series A
L ghtol er a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • (50 ) 679- 131 • Fax (50 ) 674-4710
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Thomas Group LLC (Lightolier Division) • B0711
