Lightolier Lytespan 23F39T4 User manual

Lytespan®Track Lighting System 23F39T4
Page 1 of 2 Alcyon HID 39W T4 GU6.5 CMH Flood
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • C0309
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier is a Philips group brand
5 3/8 in
[136 mm]
8 11/16 in
[220 mm]
4 7/8 in
[124 mm]
3 in
[77 mm]
3 9/16 in
[90 mm]
1 1/16 in
[27 mm]
1 15/16 in
[50 mm]
1 1/2 in
[38 mm]
6 5/16 in
[160 mm]
1/4 in
[6 mm]
4 9/16 in
[116 mm]
7 in
[178 mm]
2
9
6
1
8
3
4
5
7
10
Ordering Information
Catalog No. Finish Mounting Lamps
23F39T4AL Aluminum For use with Lytespan Radius, Basic and Advent 39W T4 GU6.5 Base Ceramic Metal Halide
23F39T4BK Black Track. Not compatible with extension wands or
23F39T4WH White slope ceiling adapters. For monopoint
applications refer to spec sheet 6172.
Features
1. Track Attachment Fitting: Locking lever for mechanical/
electrical connection.
2. Brass Contact: Extends for connection to second circuit
(Advent track only).
3. Horizontal Pivot: Wireless stem profile with 365° horizontal rotation.
Position may be locked using an allen key.
4. Vertical Pivot: 0-90° vertical adjustment with aiming indicator.
Position may be locked using an allen key.
5. Fixture Housing: Extruded and diecast alumninum.
6. Ballast Housing: Molded polycarbonate
7. Lamp Cartridge: Allows easy side relamping without removal
of glass shield.
8. Safety Lens: Tempered 1/8" glass. Meets or exceeds UL safety requirement
for metal halide lamps.
9. On/Off Switch: Rocker switch to disconnect power to the ballast.
10.Safety Locking Lever: Locks ballast housing to track.
Finish
All Painted finishes are baked enamel.
Accessories
Visor: 22VZ4AL, 22VZ4BK, 22VZ4WH
Electrical
Electronic Ballast
Input Voltage: 120V
Power Factor: .9
Input Power: 45W
Max. Input Current: 0.40A
ANSI Code: C(M)130
Do not use on dimming circuit.
Labels
UL, cUL

Job Information Type:
Lightolier is a Philips group brand
Lytespan®Track Lighting System 23F39T4
Page 2 of 2 Alcyon HID 39W T4 GU6.5 CMH Flood
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • C0309
2’
Lighting Data
1 120 86 36 8 2
2 86 69 36 13 4
3 44 38 25 13 4
4 23 21 17 11 4
5 15 13 11 6 4
6 8 8 6 6 4
7 6 6 4 4 2
8 4 4 4 2 2
Footcandles on Wall
Track 2 Feet From Wall Single Unit Multiple Units
187 189 187
160 162 160
97 99 97
59 61 59
38 40 38
25 25 25
19 19 19
13 13 13
2’
126 69 126
95 74 95
55 50 55
34 34 34
23 23 23
17 17 17
13 13 13
8 8 8
4’
Distance From Ceiling
50˚
EXAMPLE: With track located 2’ from wall and multiple units spaced
3’ on center and aimed 50˚ from horizontal, the illumination on wall 3’
from ceiling will be 33 f.c. beneath units and 32 f.c. between units.
1 59 50 29 13 4
2 59 53 34 17 6
3 40 36 27 17 8
4 23 23 19 13 8
5 36 36 13 8 6
6 11 11 8 6 6
7 8 6 6 6 4
8 6 4 4 4 4
84 84 84
92 95 92
71 71 71
50 50 50
36 36 36
27 27 27
21 21 21
15 15 15
67 50 67
71 69 71
55 55 55
40 40 40
29 29 29
21 21 21
17 17 17
13 13 13
61 42 61
63 50 63
46 42 46
32 32 32
23 23 23
19 19 19
15 15 15
11 11 11
Track 3 Feet From Wall Single Unit Multiple Units
3’ 4’ 5’
Distance From Ceiling
50˚
Footcandles on wall:
69 f.c.
69 f.c.
67 f.c.
0’ 1’ 2’ 3’ 4’
0’ 1’ 2’ 3’ 4’
Beam Center
Beam Center
Lamp Information:
39W T4 Gu6.5
Lumens: 3400
Rated Avg. life: 10,000 hrs.
134 124 134
111 109 111
69 67 69
44 44 44
29 29 29
21 21 21
15 15 15
11 11 11
3’
3’
