Lightolier FW01 User manual

Architectural Decorative FW01
Page 1 of 2 Vetro Wall Mount
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2010 Philips Group • F0710
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
4 1/2"
3
4 13/16
3 9/16"
11"
2 3/8"
2
13 61/64"
Ordering Information:
Spec ID Powerhead Inner Diffuser Outer Glass Lamp Volts
FW01 PW13SA
SG02 or SA02 NA
4-Pin Elect. Twin Tube 13W 120V
FW201 PW132SA 4-Pin Elect. Twin Tube 13W 277V
FW01Q PW13QSA 4-Pin Quad Tube 13W 120V
FW201Q PW132QSA 4-Pin Quad Tube 13W 277V
IW01 PW50SA T-4 Mini-Can 50W 120V
Must order wall chassis and glass separately. Spec ID is for reference only.
Features
1. Power Compartment: Die Cast and Machined Aluminum Components.
Brushed and Clear Lacquer Finish.
2. Primary Diffuser: (SG02) Triplex hand blown glass or (SA02) opal acrylic.
3. Backplate: Die Cast Aluminum, Brushed and Clear Lacquer Finish.
Lamping (by others)
Incandescent: 50W Max. T-4 Mini Candelabra
Compact Fluorescent:
General Electric Osram/Sylvania Philips
(1) 13W Twin Tube 4-Pin Compact Fluorescent Lamp
N/A CF13DS/E/* N/A
(1) 13W Quad Tube 4-Pin Compact Fluorescent Lamp
F13DBX/SPX*/4P CF13DD/E/* PL-CL3W/*/4P/ALTO
*Manufacturers Color Temperature Designation
Electrical - Lampholders
Incandescent: E11 Base, Porcelain, Plated Copper Alloy Screw Shell
Compact Fluorescent: 13W Twin: 2GX7 Base, High Impact Thermoset
Polymer with Brass Contacts.
13W Quad: G24Q-1 Base, High Impact Thermoset Polymer with
Brass Contacts.
Electrical - Lampholders (continued)
Ballasts: Fluorescent: Electronic 13 Watts TT 13 Watts QT
Voltage 120 277 120 277
Max. Watts 16 11 20 14
Max. Line Current (Amps) 0.136 0.08 0.174 0.114
Labels
cULus Listed. Suitable for Damp Locations.

Architectural Decorative FW01
Page 2 of 2 Vetro Wall Mount
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2010 Philips Group • F0710
Job Information Type:
Catalog No. FW01, 13W 4 Pin Twin Tube, 800 Lumens.
60°
30°
0
18
55
73
37
Report No. 3115FR
CANDLEPOWER SUMMARY
Angle 0˚ 45˚ 90˚
0 42 42 42
5 35 37 50
10 43 47 62
15 53 60 68
20 60 65 69
25 61 66 67
30 61 64 65
35 59 62 63
40 58 61 61
45 57 60 60
50 57 60 60
55 58 60 61
60 59 61 61
65 60 62 62
70 61 63 63
75 62 64 63
80 63 65 64
85 63 65 62
90 63 65 63
95 63 65 62
100 63 65 62
105 62 64 60
110 61 63 59
115 60 62 56
120 57 59 53
125 55 56 50
130 51 53 46
135 47 49 41
140 43 45 36
145 39 40 30
150 33 34 22
155 27 26 14
160 19 17 8
165 10 8 3
170 3 3 1
175 1 1 1
180 1 1 1
ZONAL LUMENS AND PERCENTAGES
Zone Lumens %Lamp %Fixt
0-30 53.06 6.6 8.2
0-40 97.48 11.4 14.1
0-60 190.3 23.8 29.4
0-90 381.35 47.7 58.9
90-120 174.62 21.8 27
90-130 214.22 26.8 33.1
90-150 257.49 32.2 33.1
90-180 265.77 33.2 41.1
0-180 647.03 80.9 100
** Efficiency = 80.9% **
COEFFICIENTS OF UTILIZATION
Ceiling 80% 70% 50% 30%
Wall 70 50 30 10 50 10 50 10 50 10 0
RCR Zonal Cavity Method - Effective Floor Reflectance = 20%
Room Cavity Ratio
0 88 88 88 88 82 82 71 71 61 61 48
1 77 71 67 62 66 58 57 50 48 43 32
2 68 60 54 48 56 45 48 39 40 33 24
3 62 52 44 38 48 36 41 31 34 26 19
4 56 45 37 32 42 30 36 26 30 22 15
5 51 40 32 26 37 25 31 21 26 18 12
6 47 36 28 23 33 21 28 18 24 16 11
7 43 32 25 19 30 18 25 16 21 14 9
8 40 29 22 17 27 16 23 14 19 12 8
9 37 26 19 15 24 14 21 12 18 11 7
10 35 24 18 13 22 13 19 11 16 9 6
Determined In Accordance With Current IES Published Procedures
Luminaire Imput Watts = 18
