Lytespan® Track Lighting System 23MHRNF
Page 1 of 2 Alcyon HID T4 GU6.5, BT PGJ5 Narrow Flood Reflector
Features
1. Narrow Flood Reflector: Aluminum, faceted, specular, anodized
and sealed.
Finish
Specular Anodized and Sealed.
Labels
UL, cUL
Ordering Information
Catalog No. Finish Lamps For Use With Luminaires
23MHRNF Anodized T4 GU6.5, BT PGJ5 23S20T4, 23C20T4
23MHRNFCCZ Champagne Bronze 23S20BT, 23C20BT
23MHRNFWRM Incandescent Warm
2 5/8 in
[66 mm]

Lytespan® Track Lighting System 23MHRNF
Page 2 of 2 Alcyon HID T4 GU6.5, BT PGJ5 Narrow Flood Reflector
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2010 Philips Group • C0510
Job Information Type:
Aiming Angle: 0° 30° Horizontal 30° Vertical 45° Vertical
L Beam length D Distance
W Beam Width A Aiming Angle
C Distance to center beam FC Footcandles
L and W are the outer points where the candle
power drops to 50% of the maximum. FC are the
initial footcandles at the center of the beam.
Lamp data shown is typical. Consult lamp
manufacturers for availability and performance.
CBCP = Center Beam Candle Power.
20W T4, 23MHRNF, 2386 9000
23C20T4,
23S20T4 25°
Lamp
Beam Spread CBCP Rated
(To 50% CBCP) Life (Hrs.)
D FC L W D C FC L W D C FC L W D C FC L W
6' 3.5' 43 3.6' 3.1'
8' 4.6' 24 4.8' 4.1'
10' 5.8' 15 6.0' 5.1'
12' 6.9' 11 7.2' 6.1'
2' 2.0' 211 1.9' 1.3'
3' 3.0' 94 2.8' 1.9'
4' 4.0' 53 3.7' 2.5'
5' 5.0' 34 4.7' 3.1'
2' 3.5' 75 4.2' 1.8'
3' 5.2' 33 6.2' 2.7'
4' 6.9' 19 8.3' 3.5'
5' 8.7' 12 10.4' 4.4'
6' 66 2.7' 2.7'
8' 37 3.5' 3.5'
10' 24 4.4' 4.4'
12' 17 5.3' 5.3'
22W BT-5, 23MHRNF, 2538 12000
23C20BT,
23S20BT 25°
Lamp
Beam Spread CBCP Rated
(To 50% CBCP) Life (Hrs.)
D FC L W D C FC L W D C FC L W D C FC L W
6' 3.5' 46 3.6' 3.1'
8' 4.6' 26 4.8' 4.1'
10' 5.8' 16 6.0' 5.1'
12' 6.9' 11 7.2' 6.1'
2' 2.0' 224 1.9' 1.3'
3' 3.0' 100 2.8' 1.9'
4' 4.0' 56 3.7' 2.5'
5' 5.0' 36 4.7' 3.1'
2' 3.5' 79 4.2' 1.8'
3' 5.2' 35 6.2' 2.7'
4' 6.9' 20 8.3' 3.5'
5' 8.7' 13 10.4' 4.4'
6' 71 2.7' 2.7'
8' 40 3.5' 3.5'
10' 25 4.4' 4.4'
12' 51 5.3' 5.3'
Note: For Champagne Bronze (CCZ), multiply FC values by 0.64.
For Incandescent Warm (WRM), multiply FC values by 0.85.
