Lighting Systems LP-24
1BHFPG -JOFBS1FSG-ZUFÜ4FNJ1FSGPSBUFE-JHIU51FS'PPU/PNJOBM4FDUJPO
#
Complete ordering instructions below.
Features
1. Housing:
others.
2. Lamping: Two T8 32 watt fluorescent lamps per 4-foot section. Provided by
Ordering Information
Individual Fixtures:
1. Order number of MODULES required.
2. Order one POWER FEED END SET per MODULE.
Continuous Rows:
1. Determine run length.
2. Order the appropriate number of MODULES for the complete run.
3. Order one POWER FEED END SET per run.
4. Order one CABLE ASSEMBLY per MODULE minus one per run.
5. For runs that exceed amperage limits, order the appropriate number of SINGLE
Labels
UL, cUL and I.B.E.W.
Finish
Powder coated baked white enamel. Customcolors available, consult factory.
CABLE & CORD FEEDS.
Module Ordering Information
Style Series Type Lamps
2T8 = 2-F32T8
LP 3 B 2T8
Options
4= 4-Foot U= Universal Voltage Blank = No Options
8= 8-Foot
12 = 12-Foot
E= Emergency Pack DS = A-B Switch
D1 = Dimming 120v X4 = 4 Wire for Dimming &
Switched Emergency
D2 = Dimming 277v
Length Ballast
18 gauge perforated steel with 41% open hole pattern. Holes are
1/16” (0.16cm) diameter on 3/32” (0.24cm) centers. Die-formed steel end cap
with concealed access holes for through wiring. No exposed fasteners or
hardware.
Electrical
Ballast is universal voltage, <10% THD, .88 ballast factor, instant start. 3 con-
ductor, 18 gauge wire. Color-coded quick connectors allow ease of connection
for joiner modules. For special circuiting consult factory. Cord is 18/3 SJT. Factory
installed ballast disconnect allows the ballast to be disconnected fromand
reconnected to incoming power under load without turning the entire circuit off.
Dimming: 120/277 VAC, 4 wire feed required.
Emergency Battery Pack: 32 watt: 450 lumens @ 90 minutes.
Options
Dual Switching: Order the DS option for separate row switching. DS option
automatically ships with the X4 option included.
Mountings
Cable Suspension (not shown) - 4-1/2” (11.43cm) diameter flat canopy finished
white enamel, 1/16” (0.16cm) diameter stainless steel aircraft cable adjustable up
to 36” (91.44cm) without cutting. Overlap connector to provided 46” (116.84cm) of
perforated and 2” (5.08cm) solid sections contiguously without the presence of
hairline connections (see BottomView drawing above).
3. Diffuser: Opal acrylic diffuser.
4 Wire: Order X4 modules for remainder of the run when using dimming and/or
switched emergency battery pack modules. Also, order the 4 Wire Cord Power Feed
End Sets (LP1EC36X4) when using 4 Wire Modules.
Emer
g
enc
y
Circuitin
g
:S
p
ecial circuitin
g
- consult factor
y
.
Bottom View
9” (22.86cm)
2.5”
(6.35cm)
3.4” (8.64cm)
Perf
98” (248.92cm)
2” (5.08cm) 2” (5.08cm)2” (5.08cm)

Job Information Type:
"JSQPSU3PBE'BMM3JWFS."tt'BY
We reserve the right to change details of design, materials and finish.
XXXMJHIUPMJFSDPN½1IJMJQT(SPVQt #
Lighting Systems LP-24
1BHFPG -JOFBS1FSG-ZUFÜ4FNJ1FSGPSBUFE-JHIU51FS'PPU/PNJOBM4FDUJPO
Mounting Accessories
Power Feed End Set
Standard Cable Length is 36” (91.44cm)
Straight Cord: LP3EC36
4 Wire Cord*: LP3EC36X4
Cable/Joiner Assembly
Standard Cable Length is 36” (91.44cm)
Single Cable: LP3C36
Single Cable & Cord: LP3CC36
Single Cable & 4 Wire Cord: LP3CC36X4
Fixture Lengths & Mounting Locations
Ceiling Grid Kit CGK
Includes both Standard 1” (2.54cm)
Tee Bar Clip & Slot Tee Clip
* use for dimming and/or emergency battery packs
4’ 8’
48” (121.92cm)
4’ 2” (127.00cm)
96” (243.84cm)
8’ 2” (248.92cm)
12’
16’
20’
24’
144” (366.62cm)
12’ 2” (370.84cm)
96” (243.84cm)
16’ 2” (492.76cm)
96” (243.84cm)
144” (366.62cm)
96” (243.84cm)
20’ 2” (614.68cm)
144” (366.62cm) 144” (366.62cm)
24’ 2” (736.60cm)
Performance
CANDLEPOWER
ZONE 0 22 45 67 90
DEG.
CANDELAS
180 1272 1272 1272 1272 1272
175 1292 1259 1217 1248 1181
165 1216 1190 1201 1193 1210
155 1139 1142 1138 1151 1170
145 993 1020 1050 1085 1119
135 848 905 955 1010 1034
125 695 724 826 902 935
115 485 555 680 729 735
105 276 373 475 541 569
95 69 156 175 183 180
90 14 30 32 40 36
85 15 16 26 31 34
75 30 27 32 45 46
65 44 53 50 53 56
55 52 59 68 73 73
45 76 77 85 87 91
35 96 95 95 98 103
25 97 108 105 109 105
15 113 114 109 109 117
5 118 124 127 104 115
0 148 148 148 148 148
1200
900
600
300
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
REPORT NO: LP3B2T8.ies
LAMPS: 2-F32T8
LUMENS: 2900
EFFICIENCY: 83.0%
CAT. NO.: LP3B2T84U
ROOM CAVITY RATIO
CANDLEPOWER CURVE
DISTRIBUTION
Zone Lumens % Lamp% Luminaire
0-90 396 7.0 8.0
90-180 4417 76.0 92.0
0-180 4813 83.0 100.0
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY REFLECTANCE
80 70 50
50 30 10 50 30 10 50 30 10
080 808070 7070 505050
170 676460 5856 434240
261 565253 4945 383533
353 474346 4238 333028
447 413641 3632 262623
541 353136 3127 262220
637 312632 2723 232017
733 272329 2420 211715
830 242026 2117 191513
927 211723 1915 171411
10 24 19 15 21 17 13 15 12 10
20% FLOOR CAVITY REFLECTANCE
% WALL REFLECTANCE
4-Foot
Module
8-Foot
Module
12-Foot
Module End Set Cable/ Joiner
4-Foot Run 11
8-Foot Run 11
12-Foot Run 11
16-Foot Run 211
20'-Foot Run 111 1
24'-Foot Run 21 1
