DX Series LED Exit Sign DX
Page 1 of 1 AC Only or Emergency Operation Die Cast Aluminum Housing
Lightolier is a Philips group brand
The DX Series is an upscale die cast aluminum LED exit which offers a thin profile design while providing technologically advanced characteristics. This premium
exit integrates performance with aesthetics to meet unique requirements of architects and lighting designers.
(2.92cm)
(24.61cm)
(21.84cm)
(14.32cm)
(31.49cm)
(1.65cm)
(16.17cm)
(.88cm)
(2.76cm)
5.64"
1.09"
8.60" 9.69"
12.48"
.65"
1.15"
.35"
6.37"
(2.92cm)
(24.61cm)
(21.84cm)
(14.32cm)
(31.49cm)
(1.65cm)
(16.17cm)
(.88cm)
(2.76cm)
5.64"
1.09"
8.60" 9.69"
12.48"
.65"
1.15"
.35"
6.37"
Features
1. Illumination: Illumination is accomplished with either AllnGaP(Red) or
InGaN(Green) high output Light Emitting Diodes. LEDs and supporting elec-
tronics have an expected life of 25 years. Proprietary internal molded-acrylic
panel (thickness: 0.45”) for even illumination.
2. Housing: Die cast aluminum construction with NFPA-type field selectable
chevrons. Available in brushed aluminum, white, and black
3. Mounting: For surface ceiling and end mounting applications a canopy,
which utilizes a quick connect locking system for secure installations, is pro-
vided. Also available in a wall mount version for direct surface mounting.
4. Standard Self-Testing/Self-Diagnostics: Unit runs an internal test every
five seconds for secondary voltage, charge current, battery voltage, and LED
illumination. Performs automatic 1 minute discharge test every 30 days and
30 minute discharge test every 180 days meeting and exceeding UL 924 and
NFPA 101 requirements. The Infrared Option allows a remote control to initi-
ate a 5 second and 30 minute self-test in addition to the standard 1 minute
and 90 minute manual test capability.
5. Electronics: 120/277 VAC dual voltage input. Microprocessor controlled
charge, transfer and monitoring system. Charging system is complete with
low voltage disconnect, AC lockout, and brownout protection. Self powered
units include an AC indicator/systems status lamp and manual test switch.
6. Battery: Maintenance free, sealed nickel metal hydride battery with 10 year
life and an operating temperature between 14°F (-10°C) and 113°F (45°C).
NiMH battery is a non-toxic, environmentally friendly product which is recy-
clable.
7. Input Power Requirements:
AC Only – Red: 1.29W; Green: 2.20W
Emergency Operation – Red: 3.16W; Green: 3.00W
Warranty
Electronics: 3 years, Battery: 5 years full, 5 years pro-rata.
Code Compliance
U.L. 924 listed, NFPA 101
Options
I = Infrared Remote Sensor1
F = Flashing Emergency
Z = Audible Emergency
FA = 24 VDC Fire Alarm Interface
6V = 6 VDC Input2
12V = 12 VDC Input2
2CKT1 = 120 VAC Two Circuit
2CKT2 = 277 VAC Two Circuit
Notes:
1. For use with remote control which is ordered separately. Item number: IRemote
2. For use with AC only models.
Accessories
IREMOTE - Infrared remote Control
Complete Fixture consists of base exit sign. Select options below.
How to Specify:
DX
Model Number Letter Mounting Enclosure Battery
Series of Faces Color Color
DX 1 R = Red C = Ceiling/End A = Brushed Aluminum N = NiMH
2 G = Green W = Wall W = White Blank = AC only
B = Black
