Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
ProSpec® Accent Lighting System 28B20E
Page 1 of 1 PowerArc™ Modular 20W Electronic Metal Halide Ballast Module
Features
1. Housing: .10" thick extruded aluminum body with die cast end caps.
2. Track Attachment Fitting: Molded polycarbonate; rotates into track.
3. Ground Clip: Ensures proper grounding of module.
4. Safety Locking Lever: Locks and supports module in track.
5. On/Off Switch: Rocker switch to disconnect power to the ballast.
6. Power Connector: 5kv rated, insulated. Accepts power connector
from fixture.
7. Integral Track Groove: To mount PowerArc™ Modular spots and wall
wash fixtures.
Electrical
Electronic Ballast
Input Voltage: 120V, 60Hz
Power Factor: High
Input Power: 24W
Max. Input Current: 0.20A
Total Harmonic Distortion: <10%
ANSI Code: M156
Do not use on dimming circuit.
Finish
All painted finishes are baked enamel.
Labels
UL, cUL
Ordering Information
Catalog No. Finishes Track Mountings Luminaires Lamp
28B20EWH
28B20EBK
28B20EAL
Matte White
Matte Black
Metallic Aluminum
All ProSpec® Track Systems and Multipoint. DO NOT USE with any
other mounting accessories, stem mounted Radius® Track, Lytespan
Track Systems, or ATOM®. Can be wall mounted. NO REMOTE
MOUNTING.
Use one of:
8314
83W4
20W Ceramic
Metal Halide
7 3/4"
(197mm)
2"
(51mm)
2 3/8"
(60mm)
2 1/16"
(52mm)
3 17/64"
(83mm)
2
5
1
3
6
74
