Lightolier QVS1GPFOS232 User manual

Mounting Methods / Features Dimensions
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902 Section 5 / Folio L20-30
Features
• Efficiency 49.8%.
• Swing down microperforated lamp shield for easy relamping and
maintenance.
• Alter soft white film on inside of mesh conceals lamp image provid-
ing balance between reflected and direct light.
• Fully recessed luminaire and lamp compartment.
• 95% Reflective Alter soft white paint finish.
• Specular interior reflector. (solid lamp shield only)
• One piece body for easy installation.
• Easy access to ballast through lamp compartment.
• Fits standard T-Grid ceilings.
• Optional acrylic drop-down visual element.
ALTER SOFT LIGHTS QVS1GPFOS232
Page 1 of 2 1'x4' RECESSED DIRECT/INDIRECT FLUORESCENT,
2 LAMP, TT8, 5’’ DEEP
MICROPERFORATED MESH LAMP SHIELD, STATIC
Microperforated mesh
lamp shields
Also available with solid opaque swing-
down lamp shield
Ceiling compatibility for G type luminaire e.g. QVS1GPFOS232120SO
Suited to standard exposed
T-grid ceilings
Suited to standard exposed
Slot T-grid ceilings
T type luminaire
e.g. QVS1TPFOS232120SO
Construction specially
designed for exposed slot
T-grid to preserve the cove effect

Photometry
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902 Section 5 / Folio L20-30
Job Information Type:
Specifications
MATERIALS: One piece chassis constructed from die formed 20 gauge cold rolled
steel. Reflectors - 95% reflectance baked white acrylic matte paint finish.
Specular interior reflector (only with solid shield). Soft white acrylic film on inside
of lamp shield conceals lamp image.
FINISH: Chassis exterior - phosphate undercoating, baked white acrylic matte
high reflectance paint finish.
ELECTRICAL: Rapid start HPF, thermally protected class “P” ballast. If K.Os are
within 3” of ballast use wire suitable for at least 90C.
LABELS: Listed by
Ordering Information
Explanation of Catalog Number. Example: QVS1GPFOS232120SO
ALTER SOFT LIGHTS QVS1GPFOS232
Page 1 of 2 1'x4' RECESSED DIRECT/INDIRECT FLUORESCENT,
2 LAMP, TT8, 5’’ DEEP
MICROPERFORATED MESH LAMP SHIELD, STATIC
QUALITY
VISUAL
STATIC
Recessed direct
indirect soft light
optical system FIXTURE
WIDTH:
1’
CEILING TYPE:
Standard exposed
T-grid ceilings
LAMP SHIELD:
PF = Microperforated
SD = Solid
LAMP
QUANTITY
LAMP/FIXTURE
LENGTH:
(NOMINAL 48”)
32 = 32WT8
VOLTAGE:
120V
277V
347V
QVS 1 G 2 32
BALLAST:
OC = Magnetic T8
SO = Electronic T8 instant start
SR = Electronic T8 rapid start
PS = PowerSpec
OPTIONS:
R = Radio Interference Filter
O = Emergency Lighting System
(for Canada)
N = Emergency Lighting System
(for U.S.)
CLEAR POLISHED
ACRYLIC DROP
DOWN VISUAL
ELEMENT:
OS = Open slot (no acrylic)
GC = Clear acrylic
GG = Clear acrylic / Green projected color face
GB = Clear acrylic / Blue projected color face
GR = Clear acrylic / Red projected color face
