WSTXF
WIRELESS DMX TRANSMITTER
OWNER’S MANUAL
Version 1.0
06/28/2022

Page 2 of 3
WSTXF WIRELESS DMX TRANSMITTER
Version 1.0 OWNER’S MANUAL 6/28/2022
www.lightronics.com
Lightronics Inc. 509 Central Drive, Virginia Beach, VA 23454 757 486 3588
DESCRIPTION
The WSTXF is a compact RF transmitter unit which
transmits a DMX-512 lighting control signal. Its input
signal is received from a normal wired DMX system via
a standard 5-pin male XLR connector. The WSTXF is
supplied with an external power supply and a
transmitting antenna.
The WSTXF can operate with multiple compatible
wireless DMX dimmers and/or receivers. The receiver
units get the same information they would get using a
cable connected to a DMX lighting controller.
The wireless system uses the 2.45 GHz band and
operates at low power (< 100mW). The operating
range is approximately 1400 ft. indoors and about 4000
ft. for outdoor operation. This range could vary
significantly depending on the surrounding conditions.
A link between a specific single WSTXF transmitter
and one or more compatible receiving units is invoked
to enable wireless operation. The linking operation is
performed at the transmitter. Once linked, the
receiver(s) can operate ONLY with that specific
transmitter. The link is retained even when the
receiver(s) and/or transmitter are powered off.
Receivers may be released from the link either at the
transmitter or at the receiver. If released at the
transmitter then ALL receivers linked to that transmitter
will be released. If released at the receiver then ONLY
that receiver will be released.
INSTALLATION
POWER CONNECTION
The WSTXF is powered by an external 120VAC power
supply which provides 12VDC at 1 Amp to the unit.
The power connector on the unit is a 2.1mm male
socket. When using a DC power supply, the center pin
must be POSITIVE. It can be powered by another
source if it meets the requirements marked on the
WSTXF.
Connect the power supply to any convenient 120VAC
outlet. Then connect the 2.1mm plug to the WSTXF.
ANTENNA CONNECTION
Carefully thread the antenna on the gold antenna
connector on one end of the unit. It should be finger
tight only. The connectors can be damaged or jammed
if too tight. The antenna will swivel to a convenient
orientation while connected.
DMX INPUT CONNECTION
Connect the incoming DMX signal to the 5-Pin Male
XLR connector on the end of the WSTXF.
DMX CONNECTOR
PIN NUMBER
SIGNAL NAME
1
DMX COMMON
2
DMX DATA -
3
DMX DATA +
4
NOT USED
5
NOT USED
OPERATION
LINK CONTROL BUTTON
This pushbutton switch is used to both link and release
the links with all free receiver units within its range.
LED ON SOLID
LINK + DMX OK
LED FLASHING
NO DMX IN
PUSH ONCE TO
LINK TO ALL FREE
RECEIVERS
HOLD > 5 SEC.
TO RELEASE LINK LED FAST FLASH
LINK IN PROGRESS
ANTENNA
CONNECTOR
LINK CONTROL
BUTTON
STATUS
INDICATOR
LED
FRONT VIEW
5 PIN
MALE
XLR CONNECTOR
WSTXF
8 15VAC
700mA
DMX IN
POWER
Wireless DMX Transmitter
REAR VIEW

Page 3 of 3
WSTXF WIRELESS DMX TRANSMITTER
Version 1.0 OWNER’S MANUAL 6/28/2022
www.lightronics.com
Lightronics Inc. 509 Central Drive, Virginia Beach, VA 23454 757 486 3588
STATUS INDICATOR LED
The indicator shows the status of the unit as follows:
OFF………………NO POWER
SLOW FLASH…..NO DMX IN
FAST FLASH……LINKING IN PROGRESS
ON………………..DMX IN and TRANSMITTER OK
LINKING RECEIVERS
LINKS WILL NOT BE ESTABLISHED WITH
RECEIVERS ALREADY LINKED TO ANOTHER
TRANSMITTER DEVICE.
You should begin by unlinking the receiver at the
receiver itself since it could be linked to a transmitter
other than the one you have.
Push the link control button on the transmitter once (do
not hold it down). The indicator LED will go to a fast
flash for about 10 seconds. It will then go to an ON
state.
The link indicator on the receiver will also go to fast
flash and may continue this for several more seconds
after the transmitters indicator goes to ON. The link
indicator on the receiver will go to an ON state when
the link is stable.
Note: This process can be repeated to add more
receivers without unlinking previously linked receivers.
UNLINKING RECEIVERS AT THE TRANSMITTER
Note that receivers link to a different transmitter will not
be released.
Hold the link control button down for about 5 seconds.
The indicator LED will go to slow flash showing that no
links are active.
The link indicator on the receiver unit(s) will go OFF.
MAINTENANCE AND REPAIR
OWNER MAINTENANCE
There are no user serviceable parts in the unit.
Service by other than Lightronics authorized agents will
void your warranty.
CLEANING
The unit exterior may be cleaned using a soft cloth
dampened with a mild detergent/water mixture or a
mild spray-on type cleaner. DO NOT SPRAY ANY
LIQUID directly on the unit. DO NOT IMMERSE the
unit in any liquid or allow liquid to get into the controls.
DO NOT USE any solvent based or abrasive cleaners
on the unit.
OPERATING AND MAINTENANCE ASSISTANCE
Dealer and Lightronics personnel can help you with
operation or maintenance problems. Please read the
applicable parts of this manual before calling for
assistance.
If service is required - contact the dealer from whom
you purchased the unit or contact Lightronics Service
Dept., 509 Central Drive, Virginia Beach, VA 23454
TEL: [phone].
WARRANTY INFORMATION AND
REGISTRATION – CLICK LINK BELOW
www.lightronics.com/warranty.html
