LIGNEUS DS2W-415300640RB User manual

2-Tier Adjustable Wooden A-Frame 415x300x640 For more information visit https://ligneus.co.uk/a-frames
Ligneus Products Ltd. Hangar 107, Aston Down Business Park, Stroud Gloucestershire. GL6 8GA • Tel: [phone] • Email: [email protected] • www.ligneus.co.uk
2-Tier Adjustable A-Frame
What’s included:
Parts:
Legs Bottom box Top Box Handle
Tools & fixings:
Male Connectors Female Connectors Allan Key
What you will need:
•A basic level of DIY experience

2-Tier Adjustable Wooden A-Frame 415x300x640 For more information visit https://ligneus.co.uk/a-frames
Ligneus Products Ltd. Hangar 107, Aston Down Business Park, Stroud Gloucestershire. GL6 8GA • Tel: [phone] • Email: [email protected] • www.ligneus.co.uk
Products covered in this guide:
Name
MPN
GTIN
Rustic Brown 2-Tier Frame
DS2W-415300640RB
5060632682338
Black 2-Tier Frame
DS2W-415300640BK
5060632682390
Amberley Grey 2-Tier Frame
DS2W-415300640AG
5060632682406
Kingscote Blue 2-Tier Frame
DS2W-415300640KB
Tetbury Green 2-Tier Frame
DS2W-415300640TG
White 2-Tier Frame
DS2W-415300640WHT
Assembly instructions:
Please refer to diagrams overleaf
1. Clarify the front and back of each leg. This is determined by the
holes. The lower holes indicate the front edge.
2. Clarify the front and back of each box. The front of each box has the
double hole configuration.
3. Using 2 of the M6x25 male connectors and 2 M6x12 female
connectors and fix bottom box to one leg. The bottom box holes are
further apart. The female connectors are on the inside.
4. Repeat step 3 for the top box on the same leg.
5. Fix the handle to same leg using one of the M6x35 male connectors.
6. Now place the leg flat on the floor and position the remaining leg on
top aligning with the boxes and handle below. Fasten with the
remaining connectors. Again ensure correct front to back alignment
Do contact us if you are unsure of the assembly instructions
Adjustable configuration
Each shelf can be set in either a slanted position for an optimum display
or a level position for easy access from both sides. Simply alter the
position of the male/female fastenings on the front of each box.
Maintenance:
These A-Frames are robustly manufactured so should be very
comfortable in a busy environment. We do however recommend a wipe
over with a damp cloth from time to time and also a visual check over for
any defects and tighten any fastenings as appropriate.
We recommend keeping these assembly instructions in a
safe place for future reference. You can also scan the QR
code for an electronic copy
