Liko Ultra LiftPants 920 Manual

Product Descripon
Liing very heavy paents requires special techniques and
specially designed li equipment. Liko has developed the
Ultra product series to help li such paents in a safe and
comfortable manner.
The Liko Ultra LiPants sling also give very heavy paents
the chance to pracce standing and gait training without
risk of falling. They also reduce the risk of injuries to
caregivers.
The Liko Ultra LiPants sling aid in safe standing and
gait training for paents with poor balance and poor leg
funcon. It is essenal that the paent is able to bear
weight on their legs. The LiPants allow the paent to
move while relieving him/her of a greater or lesser degree
of body weight.
The Liko Ultra LiPants sling are equipped with two hip
straps on either side for more even weight distribuon.
There are two dierent sizes.
Selecng a suitable li
It is recommended that at least two caregivers be present
when transferring a paent.
The Liko Ultra LiPants sling can be used along with Liko’s
overhead or mobile lis. An overhead li can be used by the
paent for unrestricted movement within the li’s liing
area. You can choose between:
- Liko’s UltraTwin system with two li units. The maximum
load is 500 kg (1100 lbs.), depending on which individual
products are included in the assembled li system.
The UltraTwin system is available for both staonary
installaon and for freestanding installaon in the
UltraTwin FreeSpan™.
- LikoGuard™ L overhead li for liing up to 272 kg (600 lbs.)
or LikoGuard™ XL overhead li for liing up to 363 kg
(800 lbs.).
- Viking™ XL mobile li for liing up to 300 kg (660 lbs.).
May be equipped with arm rest to give extra support
during standing- and gait training
In this document, the person being lied is referred to as the paent and the person helping them is referred to as the
caregiver.
Liko™ Ultra LiPants™, Mod. 920
Sling
Instrucon Guide
7EN160181 Rev. 6
ENGLISH
Symbol descripon
is a warning triangle used for situaons which require extra care and aenon.
reference to read instrucon guide for detailed informaon

2
Liko™ Ultra LiPants™ sling • 7EN160181 Rev. 6 www.hill-rom.com I www.liko.com
Table of Contents
Safety Instrucons ........................................................................................................................ 3-4
Care and Maintenance .................................................................................................................... 4
Denions ....................................................................................................................................... 4
How to Aach a Sling to Dierent Sling Bars ................................................................................... 5
How to Aach an Ultra LiPants Sling to a Sling Bar with 4 Hooks (Twin Bars and Cross Bars) ...... 6
Applying the LiPants sling ........................................................................................................... 6-7
Adjustment of Loop Straps .............................................................................................................. 8
Removing the LiPants sling ............................................................................................................ 8
Choosing the Right Size .................................................................................................................... 9
Accessories ....................................................................................................................................... 9
Overview, Liko Ultra LiPants sling, Mod. 920 ............................................................................... 10
Recommended Combinaons ........................................................................................................ 10

23
Liko™ Ultra LiPants™ sling • 7EN160181 Rev. 6 www.hill-rom.com I www.liko.com
Safety Instrucons
Before liing, keep the following points in mind:
• A responsible person within your organizaon should decide on a case-by-case basis whether one or more caregivers are
needed.
• Ensure that the sling selected meets the paent’s needs with reference to model, size, fabric and design.
•
The total maximum load for a li system is always determined by the product in the system with the lowest specied
maximum load.
• For safety and hygiene reasons, use individual slings.
• Plan the liing operaon so that it can be done as safely and smoothly as possible.
• Check that the liing accessory hangs vercally and can move freely.
• Although the Liko sling bars are equipped with latches, special cauon must be exercised: before the paent is lied from
the underlying surface, but when the straps are fully extended, make sure the straps are correctly connected to the sling
bar hooks.
• Never li a paent higher o the underlying surface than is needed to complete the liing and transfer procedure.
• Never leave a paent unaended during a liing situaon.
• Make sure that the wheels on the wheelchair, bed, gurney, etc., are locked during the liing/transfer operaon.
• Always work ergonomically. Use the paent’s ability to acvely parcipate in the operaons.
• When the sling is not being used, do not place in direct sun light.
Medical Device Class I Product
Liko Ultra LiPants complies with the harmonized standard ISO10535:2006
The management system for both manufacturing and development of the product is cered in accordance with ISO9001
and its equivalent for the medical device industry, ISO13485. The management system is also cered in accordance with the
environmental standard ISO14001.
PATENT www.hill-rom.com/patents
May be covered by one or more patents. See above Internet address.
The Hill-Rom companies are the proprietors of European, US, and other patents and pending patent applicaons.
Design and Quality by Liko in Sweden
Liko’s products undergo connuous development, which is why we reserve the right to make product changes without prior
noce. Contact your Hill-Rom representave for advice and informaon about product upgrades.
IMPORTANT!
Liing and transferring a paent always involves a certain risk. Read the instrucon guide for both the li and liing
accessories before use. It is important to completely understand the contents of the instrucon guide. The equipment
should be used only by trained personnel. Ensure that the liing accessories are suitable for the li being used. Exercise care
and cauon during use. As a caregiver, you are always responsible for the paent’s safety. You must be aware of the paent’s
ability to handle the liing situaon.

4
Liko™ Ultra LiPants™ sling • 7EN160181 Rev. 6 www.hill-rom.com I www.liko.com
Care and Maintenance
Check the sling before each use. Check the following points with regard to wear and damage:
• Fabric
• Straps
• Seams
• Suspension loops
• Buckle
Do not use damaged liing accessories.
If anything is unclear, please contact the manufacturer or supplier.
If the sling is used for bath or shower: Aer use in bath and shower situaons, the sling should be placed so that it dries as
soon as possible.
Washing instrucons: Please see the sling’s product label and the aached appendix ”Care and Maintenance of Liko Slings”.
Expected Life Time
The product has an expected life me of 1-3 years during normal use. Expected life me varies depending on the fabric, use
frequency, washing procedure, and weight carried.
Periodic Inspecon
The product must be inspected at least once every 6 months. More frequent inspecons might be required if the product is
used or washed more oen than normal. See Liko’s protocol ”Periodic Inspecon Liko Texle Products”.
Denions
1. Rear suspension straps
2. Product label
3. Serial number
4. Label: Periodic Inspecon
5. Label: Individual marking (Belongs to)
6. Size marking (only for size XXL)
7. Loop straps
8. Rear part
9. Upper hip strap
10. Lower hip strap
11. Front part
12. Front suspension strap
1
2 3
6
7
8
9
10
11
12
4 5

45
Liko™ Ultra LiPants™ sling • 7EN160181 Rev. 6 www.hill-rom.com I www.liko.com
Sling bar Sling loops to sling bar hooks Correct
SlingGuard™
Universal
SlingGuard™ Twin
Universal Twin
Cross-bar
Wrong!
How to Aach a Sling to Dierent Sling Bars

6
Liko™ Ultra LiPants™ sling • 7EN160181 Rev. 6 www.hill-rom.com I www.liko.com
The inial posion when using the Liko Ultra
LiPants sling are the sing posion.
The paent leans to the side so that the
LiPants sling can be slid into place under the
buocks. Place the LiPants sling as far under
the paent as possible with the product label
facing out from the back. Make sure that the
LiPants sling are centered and in a good
posion with as much pant material in back as
in front. Adjust as needed.
Applying the LiPants
Pull the front secon of the
LiPants sling up between the
legs so that the hip straps are
accessible from the front.
Feed the front suspension straps
through the loop straps using the
appropriate loop (see page 8,
Adjusng the Loop Straps).
Alternave applicaon of the Liko Ultra LiPants sling: The paent can be lied in a normal sling and then lowered onto the
LiPants sling placed on a chair or at the edge of the bed. The sling used can be e.g. the Liko UltraSling Mod. 06, Liko Original
HighBack Sling Mod. 200 or Liko So Original HighBack Sling Mod. 26. This applicaon makes it easier if for some reason the
paent cannot lean to the side, or if there is no room to apply the LiPants sling from the side.
How to Aach an Ultra LiPants Sling to a Sling Bar with 4 Hooks
(Twin Bars and Cross Bars)
Rear suspension strap
Front suspension strap
The illustraons 1, 2, and 3 shows a twin bar but this
also applies to a Cross-bar.
B
B
A
A1.
2. 3.
A
B
B
ABA

67
Liko™ Ultra LiPants™ sling • 7EN160181 Rev. 6 www.hill-rom.com I www.liko.com
Before assisng the paent to his/her feet: Make sure the
paent has a steady foong on the oor to lighten the load during
the raising. Run the li slightly upwards to apply tension to the
suspension straps without liing the buocks, and make sure
that the loop straps are providing adequate support around the
paent’s upper body.
During the liing operaon: Pull the li forward in the direcon
of movement so that weight transfer takes place properly unl
the paent is upright and well-balanced.
When the paent has gained his/her balance
standing, the liing height is adjusted to
provide appropriate relief with help from the
LiPants sling. Gait training can now begin!
Connect the rear suspension straps onto the
rear hooks on the sling bar, or onto the rear
sling bar. Connect the front suspension straps
to the front hooks on the sling bar or to the
front sling bar. The outermost strap loop is
the most commonly used. See page 5-6 for
instrucons on how to aach the sling loops
to dierent sling bars.
Fasten the hip strap’s buckles and pull ght. Depending on the size of
the paent, either one or both hip straps may be fastened from the
standing posion.

8
Liko™ Ultra LiPants™ sling • 7EN160181 Rev. 6 www.hill-rom.com I www.liko.com
Loop Clips
A praccal accessory for indicang the loops that work for a certain person.
This makes it easier for caregivers to choose the right loop when applying the
LiPants sling.
Adjusng the Loop Straps
A smaller person can have the
suspension straps fed through
an inner loop.
A larger person can have the
suspension straps fed through an
outer loop.
The loop straps should be neither
too loose nor too ght around the
upper body. Resistance with comfort
is best.
Removing the LiPants
Loosen the hip straps before lowering the paent down
into a sing posion to avoid undue pressure from the hip
straps.
The paent leans to the side. Seize hold of the outer corner
of the rear part of the LiPants sling. Now fold the LiPants
sling in under itself and pull it away.

89
Liko™ Ultra LiPants™ sling • 7EN160181 Rev. 6 www.hill-rom.com I www.liko.com
Accessories
Padded cases for shoulder strap Prod. No. 3666021
Pressure-relieving padded cases for mounng onto the forward and/or rear
suspension straps.
The padded cases come with Velcro along one longitudinal side for easy mounng.
Solo Cover for Ultra LiPants (XXL/XXXL) Prod. No. 3692908
Solo Cover for Ultra LiPants sling (XXL and XXXL) is a protecve cover made from
disposable material. It is used to avoid dirtying the LiPants sling and to prevent
contagion.
Choosing the Right Size
Choosing the right size is important for a safe and secure li and for reaching the required li height. Liko Ultra LiPants sling
should reach above waist height but not so high that the loop straps cut into the armpits. Refer to the measurement table
below for guidance. Size XXXL has higher fabric secons and longer hip straps in order to reach around a larger belly.
Do not choose too large size as this can mean that the required li height cannot be achieved.
Measurement 1 2 3
XXL 185-260 cm (73-102 inch.) 150-210 cm (59-83 inch.) 140 cm (55 inch.)
XXXL 185-300 cm (73-118 inch.) 150-250 cm (59-98 inch.) 150 cm (59 inch.)
1
2
3

Name Prod. No. Size Paent weight¹ Paent height¹ Maximum load² Material
Liko Ultra LiPants 35920328 XXL 200-500 kg (440-1100 lbs.) 170-210 cm (67-83 inch.) 500 kg (1100 lbs.) Net polyester
Liko Ultra LiPants 35920329 XXXL 200-500 kg (440-1100 lbs.) 170-210 cm (67-83 inch.) 500 kg (1100 lbs.) Net polyester
Overview, Liko™ Ultra LiPants™ sling, Mod. 920
Explanaon: 1 = Recommended, 2 = May work, 3 = Not advised, 4 = Inappropriate
¹ The indicated paent weight and height are only guidelines – there may be deviaons.
² To maintain maximum load, li/accessories intended for the same load or more are required.
To choose the right size – refer to ”Choosing the right size” on page 9.
When using two li units (UltraTwin), only the below combinaons are possible
¹ Sling bar 450 relates to Universal SlingBar 450 Prod. No. 3156075, 3156085, and 3156095, SlingBar Standard 450 Prod. No. 3156001, 3156003, 3156007,
and 3156016, and also SlingGuard 450 Prod. No. 3308020 and 3308520 .
² Twin bars 670 relates to Universal TwinBar 670 Prod. No 3156077, and 3156087, and also SlingGuard 670 Twin Prod. No. 3308040 and 3308540.
³ Sling bar 350 relates to Universal SlingBar 350 Prod. No. 3156074, 3156084, and 3156094, and also SlingGuard 350 Prod. No. 3308010 and 3308510.
⁴ Sling bar 600 relates to Universal SlingBar 600 Prod. No. 3156076 and 3156086, and also SlingGuard 600 Prod. No. 3308030 and 3308530.
Explanaon: 1 = Recommended, 2 = May work, 3 = Not advised, 4 = Inappropriate
When using one li system (LikoGuard™ L and XL overhead lis, Likorall™ 243 and 250 overhead lis, Viking™ L and XL
mobile lis)
Recommended Combinaons
Other Combinaons
Combinaons of accessories/products other than those recommended by Liko can result in risks for the safety of the paent.
© Copyright Liko R&D AB 2018
3 3 2 1 1 1 4 1 1 4 4 4 4
3 3 2 1 1 1 4 1 1 4 4 4 4
Liko AB
Nedre vägen 100
SE-975 92 Luleå, Sweden
[phone]
www.hill-rom.com I www.liko.com
Recommended combinaons of the
Liko Ultra LiPants sling with Liko’s
sling bars:
Mini 220 Universal 350 Standard 450 Universal 450 Universal 600 Ultra SlingBar
Ultra LiPants, XXL 321
1
1
1
Ultra LiPants, XXXL 321
1
1
1
Recommended combinaons of the
Liko Ultra LiPants sling with Liko’s
sling bars:
Mini 220 Sling bar 350³ Sling bar 450¹ Sling bar 600⁴ Wide 670 Twin bars 670² Ultra Slingbar Sling Cross-bar 450 Sling Cross-bar 670 Univ. Side bars + Universal 350 Side bars + Standard 450 Univ. Side bars + Universal 450
Ultra LiPants, XXL 332
1
1
1411444
Ultra LiPants, XXXL 332
1
1
1411444
