PREFACE
Thank you for choosing PIH-800III keyboard. For trouble free
installation and optimum performance please read this manual
thoroughly before attempting installation or operation.
CONTENTS
1. Introduction
2. Specifications
3. Keyboard Layout
4. Matrix and Receiver Operation
5. Fast Speed Dome Operation
6. Wiring Diagrams
7. Dip Switch Setting
2
2
2
3,4
5,6
6
7
Page

11 22 23
16 13 14 15 12 17 18 20 19 21
1. INTRODUCTION
2. SPECIFICATIONS
3. KEYBOARD LAYOUT
The PIH-800III is a control keyboard For a rage of matrix switchers, dome cameras and telemetry
receivers. It allows operation of all the functions of that equipment an provides an simple operator
When matrix is present in the system, up to 8 keyboards can be used ,howeve,r one keyboard must
If when keyboard is controlling Fast Domes directly without matrix, only one keyboard is allowed.
Data is transmitted via screened, twisted pair cables, usually in serial configuration.(RS-485)
interface.
always be configured as the Master, having greater access to settings than the slaves.
Data Communication
Input Voltage
Power Consumption
Operating Temperature
Weight
Dimensions
RS-485, 9600 Baud
12Vdc
250mA
-5 C ~ +60 C
1.5Kg
370(L) 190(W) 83(H)mm
55
PS. Key Functions
1. Refer to Page 3,4 when connects to Matrix Switcher.
2. Refer to Page 5,6 when connects to Fast Dome Camera directly.
Auto Pan IndicatorPower Indicator
Auto Iris Indicator
Auto Focus Indicator
2

4. MATRIX AND RECEIVER OPERATION
Function Keys
F1 Turns on or off the on-screen display.(time,date monitor and camera number)
F2 Displays the log of last 10 camera or video loss alarms.
F3 Adjust the position of the on-screen display.
F4 Sets the P/T/Z preset position groups.
Joystick
Controls the movement of pan and tilt cameras.
Matrix Setup Menu Selection.
Under controlling single fast dome, "9013+CLR" can rectify the joystick.
Numeric Keys
0~9 for entering camera, monitor numbers ets.
ESC Key
This can be used to exit from any function or programming.
ALARM RESET Key
Clears alarms and video loss alarms.
CTRL1 / CAM SETUP Key
A spare control key when keyboard connects to Receiver.
OSD Setup Menu recall key when keyboard connects to Fast Dome Camera.
CTRL 2 / REV Key
A spare control key when keyboard connects to Receiver.
180 Horizoneal Instant Flip key when connects to Fast Dome Camera.
SPRAY Key
This operates the washer system where fitted to a camera housing.
WIPER / LENS SPEED Key
The housing wiper control key when connects to Receiver.
Manual speed switch of Zoom, Focus and Iris when connects to Fast Dome Camera.
AUX LIGHT / CAM ESC Key
Auxiliary lighting switch when connects to Receiver.
OSD Setup Menu escape key when connects to Fast Dome Camera.
*
*
'
*
*
'
*
*
*
*
*
*
*
180
3

SETUP Key
Enters Matrix Setup Mode.
Selects a particular monitor.
Selects a particular camera.
MON Key
CAM Key
CLR Key
Selects a particular camera.
ENT Key
Used to enter or confirm data and programming.
PRESET Key
For recalling and storing preset positions.
PRESET 1/2/3/4Keys
These Keys instantly move the selected camera to relevant preset position 1-4
ZOOM IN / ZOOM OUT Keys
Manually adjusted the zoom lens.
FOCUS FAR / FOCUS NEAR Keys
Manually adjusted the focus of the lens.
AUTO FOCUS Key
Auto Focus control key when connects to Fast Dome Camera.
IRISO/IRISCKeys
Manually opens or closes the iris of the lens.
AUTO IRIS Key
Sets the iris to automatic mode.
SEQ Key
Starts an automatic switching sequence on a particular monitor.
AUTO PAN Key
Puts a Pan/Tilt head into auto pan mode or a Fast Dome Camera into auto tour mode.
23
22
21
20
19
18
17
16
15
14
13
12
4
11

5. FAST DOME CAMERA OPERATION
Numeric Keys
0~9 for entering camera, monitor numbers ets.
Function Keys
F1 To set the speed that Fast Dome Camera travels between preset positions.
F2 To set the dwell time of preset position.
F3 To store the preset data
F4 To set the preset groups
Joystick
Controls the movement and speed of the dome.
Under controlling single fast dome, "9013+CLR" can rectify the joystick.
ALARM RESET Key
Clears alarms and video loss alarms.
OSD Setup Menu escape key when connects to Fast Dome Camera.
CAM Key
Selects a particular camera.
PRESET Key
For recalling preset positions.
*
*
'
*
*
'
*
*
*
*
*
*
CTRL1 / CAM SETUP Key
A spare control key when keyboard connects to Receiver.
OSD Setup Menu recall key when keyboard connects to Fast Dome Camera.
CTRL 2 / 180 REV Key
A spare control key when keyboard connects to Receiver.
180 Horizontal Instant Flip key when connects to Fast Dome Camera.
WIPER / LENS SPEED Key
The housing wiper control key when connects to Receiver.
Manual speed switch of Zoom, Focus and Iris when connects to Fast Dome Camera.
AUX LIGHT / CAM ESC Key
Auxiliary lighting switch when connects to Receiver.
5

PRESET 1/2/3/4Keys
These Keys instantly move the selected camera to the relevant preset position 1-4.
ZOOM IN / ZOOM OUT Keys
Manually controls the zoom lens.
FOCUS FAR / FOCUS NEAR Keys
Manually adjusts the focus of the lens.
AUTO FOCUS Key
Auto Focus control key when connects to Fast Dome Camera.
IRISO/IRISCKeys
Manually opens or closes the iris of the lens.
AUTO IRIS Key
Sets the iris to automatic mode.
AUTO PAN Key
Puts a Pan/Tilt head into auto pan mode or a Fast Dome Camera into auto tour mode.
RS-485 (IN / OUT)
1st Pin connects to positive, 2nd Pin to negative, leave the 3rd Pin.
12
6. WIRING DIAGRAM
To 2nd Keyboard Input
To Matrix or Fast Dome Camera
6
13
14
15
16
11

123456
ON ON
OFF
Dip Switch 1 Transmission Mode Setting
ON One Shoot: Only when press button, then transmits the protocol.
OFF Continue: Per 100 millisecond transmits protocol once.
Dip Switch 2, 3 Protocol Setting
DIP SWITCH
MLP2 VERSION
MLP1 VERSION
23
ON
OFF
ON
ON
MLP1 (MERIT LILIN PROTOCOL 1) is same as PIH-717 Fast Dome Protocol.
MLP2 (MERIT LILIN PROTOCOL 2) is the new protocol for controlling fast dome
cameras. The protocol contains 7 bytes which include a check-sum byte and extra
control codes. The check-sum byte, for example, can prevent RS-485 interference
affecting a protocol. The extra control codes, for example, can provide the feature
of controlling absolute position of a fast dome camera.
Remark: MLP1 / MLP2 protocol control mode is N, 8, 1 Baud Rate : 9600bps
Fast Dome
6 Setting OFF
123456
ON
123456
ON
123456
ON
123456
ON
7
7. DIP SWITCH SETTING

Matrix
123456
ON ON
OFF
Dip Switch 1, 2, 3 Master & Slave Setting
DIP SWITCH
1st Keyboard
5th Keyboard
2nd Keyboard
6th Keyboard
3rd Keyboard
7th Keyboard
4th Keyboard
8th Keyboard
123
ON
ON
OFF
OFF
ON
ON
ON
OFF
ON
ON
ON
ON
ON
OFF
ON
ON
OFF
OFF
OFF
OFF OFF
OFF
OFF OFF
1
1
2
2
3
3
4
4
5
5
6
6
ON
ON
1
1
2
2
3
3
4
4
5
5
6
6
ON
ON
1
1
2
2
3
3
4
4
5
5
6
6
ON
ON
1
1
2
2
3
3
4
4
5
5
6
6
ON
ON
Key Sound
Dip Switch 4 Key Sound Setting
ON Beep
OFF Silent
Alarm Buzzer
Dip Switch 5 Alarm Buzzer Setting
ON ON
OFF Silent
123456
ON
123456
ON
123456
ON
123456
ON
8 66-800IIICSE-1
