Lilin PIH-0422 P User manual

MERIT LILIN ENT. CO., LTD
http://www.meritlilin.com
INSTRUCTION MANUAL
66-042CSE
PIH-0422/0442 N/P
INFRARED DOME CAMERA

IMPORTANT SAFEGUARDS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
GRAPHIC SYMBOL EXPLANATION
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated "dangerous voltage" within the product's enclosure
that may be of sufficient magnitude to constitute a risk of electric
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
shock to persons.
accompanying the unit.

PART DESCRIPTION & DIMENSION
COVER
BRACKET
CAMERA
LIGHT SENSOR
Unit mm
74.0
93.0
66.2
INFRARED LED
LENS
VIDEO OUTPUT JACK
DC POWER INPUT
(DC12V 10%) JACK

FEATURES
1. Attached installation.
2. Adopts "special OLPF" no focus shift.
3. High efficiency infrared LED, radiant distance - 16meters.
4. Sensor auto activate infrared LED under 10lux light level.
5. Monochrome image at night, no color noise.
6. Under infrared illuminating, based on the distance between
object and camera, the shutter speed will be controlled by
the camera inner circuit automatically to avoid illuminated
object being exposed ensuring best picture quality.
7. Aluminum housing case.
8. High sensitivity sensor, excellent picture quality.
9. Choices of 3.6mm or 4.3mm or 6.0mm lens.

INSTALLATION
1. Take out the camera first, which is connected with the
bracket, and turn the lens downward. Fix the bracket on the
desired place with supplied screws (M4.0x25, wooden screw)
(FIG. 1).
2. Adjust the camera to the desired angle (should be between
40 to 90 , otherwise the cover will be difficult to replace),
and then tighten two screws on both side of the camera
(FIG.2&FIG.3).
FIG. 1
FIG. 2
40 FIG. 3
90

3. Take out the cover. Align the mark on the cover with the hinge
of the bracket (FIG. 4) and turn right to twist lock properly
(FIG. 5).
4. To take off the cover, turn the cover left to unlock (FIG. 6).
FIG. 4 FIG. 5
FIG. 6

INFRARED COLOR DOME CAMERA
Model No.
Power Input Voltage
System
Sync. Mode
Pick Up Element
Effective Pixels
Chip Size
Scanning System
Resolution
Minimum Illumination
S/N Ratio
Auto Gain Control
Aperture Correction
Power Consumption
Shutter
Back Light Compensation
Video Output
Gamma Characteristic
Lens
Operating Temperature
Weight
Dimension
DC12V ( 10%)
NTSC or PAL
Internal
1/3" Super HAD CCD Sensor
2 1 Interlace
540TV Lines
0.5Lux(F1.8), 0Lux(IR ON)
More Than 50dB (AGC OFF)
36dB Variable Gain
Horizontal , Vertical
3.0W
1/60(1/50)S ~ 1/100,000S(Auto)
Auto
CVBS 1.0Vp-p , 75ohm
=0.45
-10 ~ +50 (14 ~ 122 )
93x74mm(L)
768(H) x 494(V) [NTSC]
752(H) x 582(V) [PAL]
15.734KHz / 59.94Hz [NTSC]
15.625KHz / 50Hz [PAL]
Horizontal & Vertical
Sync. Frequency
Focal Length
Iris
Angle of view
4.3mm 6.0mm
F2.0 F1.8
White Balance ATW
230g
H
V
D
3.6mm 6.0mm
F2.0 F1.8
54.5 33.1
73 44.5
92 56
46.8 33.1
62.4 44.5
78 56
510(H) x 492(V) [NTSC]
500(H) x 582(V) [PAL]
380TV Lines
0.2Lux(F1.8), 0Lux(IR ON)
16M
PIH-0442 4.3 PIH-0442 6PIH-0422 3.6 PIH-0422 6
SPECIFICATIONS
850nm
5.59mm (H) x 4.68mm (V)
Infrared
LED
Peak Wavelength
Beam Spread
Radiant Distance
30
66-042CSE-7
To use this camera with third party's AC adaptor, please make sure
that the adaptor contains built-in DC regulator. An AC adaptor
without built-in DC regulator can damage this camera.
Design and specifications are subject to change without notice.
