Lilliput 1/C/T Assembly instructions

10.1＂USB Monitor
Manual

CONTENTS
1. Safety Instructions......................................................................................................
2. Product Features..........................................................................................................
3. connections and Installation..................................................................................
4. Installation Monitor Driver....................................................................................
5. USB MONITOR Display Setting.......................................................................
6. System Requirements...............................................................................................
7. Touch and Sound Function Instruction……………………………………
8. Cable specification(Y type USB cable)……………………………………………..
9. Specification..................................................................................................................
10.Accessories....................................................................................................................
11. Troubleshootiong........................................................................................................
YP-01120405

1. Safety Instructions
These safety instructions must be followed to ensure your safety and prevent
property damage.
Warning/Cautions Otherwise, it may result in personal injury or property damage.
Make sure to read the instructions carefully and use the product in the correct
manner.
1.1. Do not place USB MONITOR in a location exposed to moisture, dust, smoke,
water, or in a car.
Otherwise, this may result in electric shock or fire.
1.2. Clean the product using a soft cloth with a monitor cleaner only.
Make sure to disconnect USB Cable while cleaning
Ensure that water does not enter the product and that it is not wet.
Otherwise, this may result in electric shock, fire or a malfunction.
1.2.1 Do not force on LCD Screen
Do not tap or scratch LCD Screen with a sharp object，
Otherwise , LCD may get damage.
1.2.2 Product Input/Output Connectors
Do not insert any metal, such as chopsticks, coins, pins and steel.
If foreign material enters the product, disconnect the USB cable and
contact a Service Center.
1.2.3 Do not install USB MONITOR in an unstable location.
Otherwise, it may fall and cause personal injury and/or damage the
product.
1.3. Ensure that users do not disassemble, repair or modify the product themselves.
If the product needs to be repaired, contact a Service Center.
If water enters the product, disconnect the USB and contact a Service Center.
This may result in a product malfunction, electric shock, or fire.

2. Product Features
USB Monitor is A USB Powered Touch Screen Monitor, a user may utilize USB
MONITOR as Multiple Input/output devices for Video Conference, Instant
Messaging, News and Stock casting.
The model has special functions: extended monitoring and touch control
Model 1
1. Brightness down
2. Brightness up
3. POWER：ON/OFF
4. USB Interface：extended interface
5. Power and Signal Input（Mini USB interface）
6. POWER:DC

Model 2
1. POWER：ON/OFF
2. Brightness down
3. Brightness up
4. Bracket
5. USB Interface
6. Built-in speakerx2

7. Power and Signal Input（Mini USB interface）
8. Power interface: DC5V
3. Connections and Installation
3.1. USB Monitor can connected with USB interface only.
Mini USB input：connect the device and PC with USB cable.
3.2. System Requirements
CPU: Intel Pentium/Celeron/AMD/K6/Athlon/Duron 1.2GHz or above
RAM: 512MB RAM or above
USB: at least one or more USB2.0 port
HDD: 30MB HDD space above
O/S: Windows 2000/Windows XP （32bit、64bit）/ Windows Vista
（32bit、64bit）/ Windows7（32bit、64bit）/ Mac OS X。
3.3. Using
With only USB cable connection, a user may operate USB MONITOR as
Extension monitor
4. Installing monitor driver (Auto Run)
4.1. Insert the CD into the CD-ROM drive
Please make sure that your USB MONITOR is connected to the PC
4.2. Installation takes about 1 minute.
Do not power off or disconnect the USB cable until installation is completely
finished. This may damage systems or may cause system errors.
The USB MONITOR screen resolution is fixed for the best picture quality
with each model.
4.3. Installation steps :
Get“setup-UM-5.2.21675” install software from disk.
4.3.1 Double click the icon

4.3.2 If you see following message window, select “I agree”to accept the
terms of use
4.3.3 When the installation is complete, the USB MONITOR setting icon
appears on your system tray and the connected USB monitor
information will pop-up.
5. USB MONITOR display setting
5.1. When the USB MONITOR driver installation is complete, the USB
MONITOR setting icon appears on your system tray.
5.2. Click-on USB MONITOR icon then you may see the USB MONITOR setup
menu for Screen Resolution, Colors, Rotation, Extension and etc.
Ps：If USB monitor goes black, please check whether the setting of USB
monitor is shut down or not; if yes, please setup “Extend”.

6. System Requirements & Restrictions
6.1. System Properties
Windows 2000
Windows XP（32bit、64bit）
Windows vista（32bit、64bit）
Windows 7（32bit、64bit）
Mac OS X
User may check the Operating System version by Right-click „My
Computer‟→„Properties‟→„System Properties‟
6.2. USB MONITOR is a USB monitor to be recognized as a Generic USB device.
Therefore system boot-up screen or DOS screen cannot be displayed properly.
6.3. Any software that requires Hardware 3D accelerator cannot be displayed
properly with USB monitor. Such as below:
Real Player(Expansion Mode)
3D Graphic Games
Programs based on Direct X graphic engine
6.4. If the PC doesn‟t support USB2.0 USB MONITOR may not operate properly.
6.5. If the systems‟Graphic card doesn‟t support WDDM (Windows Display
Driver Model), the USM monitor‟s extension mode may not work properly
with Windows vista System.
7. Touch Function Instruction（for devices with touch function use
only.）
7.1. Touch software installation.
7.1.1 Select file “TOUCHIT-DRIVERS”from disk.
7.1.2 Enter and select file “ALL_In_One_2k_XP…”
7.1.3 Enter, select and double click the following icon to start installation.

Keep press“NEXT”until“FINISH”to finish installation. The task bar
shows icon .
7.2 Touch Setting:
Double click shortcut icon ，or right click the icon on task bar ，
popup menu.
pop-up below dialog box when selected "Calibration Utility"

Picture 1
click “Monitor Mapping", it shows as follows:
Picture 2
Click picture1, press SPACE bar, or waiting for 10seconds, and select the touch
screen need to Calibrate. picture 2 shows 》Please touch here《, and then
shows 》OK《to confirm this monitor to 4-point calibration(refer to 7.3. Touch
Calibration) then can start calibration.
Ps: please start calibration setting when touch abnormally.
