Lilliput A12 User manual

0
User Guide

1
IMPORTANT SAFETY INSTRUCTIONS:
Please read User Guide before using this product.
Please keep User Guide for future reference.
Please read the cautions to prevent possible danger and loss of
property.
FEATURES:
High resolution: 3840×2160;
Wide voltage: DC 12-24V;
High brightness: 400cd/㎡;
High contrast: 1500:1;
Visual menu icon;
Quad view display.
CAUTIONS:
1. Please do not place the display screen towards the ground.
2. Please avoid heavy impact or drop onto the ground.
3. Please do NOT use chemical solutions to clean this product. Please
wipe with a clean soft cloth to maintain the brightness of the surface.
4. Please do not block any vent hole.
5. Please follow the instructions and trouble-shootings to adjust the
product. Other improper adjustment may result in damage. Any further
adjustment must be performed or conducted by a qualified technician.
6. Please unplug the power and remove the battery if long-term no-use,
or thunder weather.
YP-01170929

2
Contents
1. PRODUCT DESCRIPTION....................................... 3
2. BATTERY INSTALLATION ..................................... 4
3. MENU SETTING....................................................... 5
4. ACCESSORIES.......................................................... 7
5. PARAMETERS.......................................................... 8
6. TROUBLE SHOOTING............................................. 9

3
1. PRODUCT DESCRIPTION
1．MENU Dial：
Menu key：Press the dial to display menu on the screen when
screen is lit.
Options key：Left or right sliding the dial in the menu screen to
select the desired menu option.
Confirm key：Press the dial to confirm the selected option.
2．EXIT：
To return or exit the menu function.
3．F1、F2 User-definable buttons：Long press F1 or F2 key for 3-5
seconds to pop-up shortcut menu directly. As shown in Figure
(default menu button in white font).
F1：Display Mode F2：Display Rotate
4. / INPUT
Power：Long press for 3 or 5 seconds to power ON/OFF.

4
Switch：Short press to switch among of DP，HDMI 1，HDMI 2，
HDMI 3，HDMI 4 and 3G-SDI.
5．Battery jar.
6．Battery release button
7．3G-SDI input/output interface.
8．HDMI input interface.
HDMI 1: HDMI2.0, support 4K 60Hz
HDMI 2~4: HDMI1.4, support 4K 30Hz
9．DP input interface.
10．Speaker.
11．DC 12V power input.
2. BATTERY INSTALLATION
①Place battery to the slot, and then slide it down to finish
mounting.
②Press the battery release button, and then slide battery up to
take it out.

5
3. MENU SETTING
Before setting the functions, please make sure the device is
connected correctly.
3-1. F1~F2 User-definable function buttons:
Long press any F1-F2 key for 3-5 seconds to pop-up shortcut menu
directly. As shown in Figure (default menu button in white font).
Select option via sliding to the left or right.
Press to confirm option as default, then press EXIT to exit.
Functions of F1-F2 buttons can also be customized: Center Marker,
Safety Marker, Aspect Marker, Aspect , Underscan, Check Filed,
Freeze, Pixel to Pixel, Color Space, Peaking, False Color, Display
Mode , Display Rotate and Display Mirror.
F1-F2：2 user-definable function buttons
Default function:
F1：Display Mode F2：Display Rotate
3-2. Dial
Sliding the dial to activate the volume bar when not under the menu
display
Slide the dial to adjust the value of option directly.
Press “EXIT” to exit if accidentally enter the menu.
After enter the Volume menu, press the dial to select among of
Volume, Brightness, Contrast, Saturation, Hue, Sharpness, Backlight,
Menu and Exit.
3-3. MENU Operation
When power on, press dial on the device, the menu of function setting
will display on the screen.
Sliding the dial to select the menu option;
Then press the dial to confirm;
Press“INPUT/EXIT”button to exit menu.

6
Brightness
0~100
Contrast
0~100
Color Space
Rec709, Native
Saturation
0~100
Hue
0~100
Sharpness
0~4
Temperature
9300, 7500, 6500, 5800, User (R.G. B)
Backlight
0~100
Function
Center Marker
ON, OFF
Safety Marker
OFF, 95%, 93%, 90%, 88%, 85%, 80%
Aspect Marker
OFF, Full, 17:9, 16:9, 4:3, 1.85:1, 2.35:1
Aspect
Full screen, 17:9, 16:9, 4:3, 1.85:1, 2.35:1
Underscan
ON, OFF
Pixel-to-Pixel
ON, OFF
Check Filed
OFF, Red, Green, Blue
Freeze Input
ON, OFF
Peaking
ON, OFF
False Color
ON, OFF
Display Mode
1P，2P LR，2P TB，2P PIP，4P
Display Setting
Display Rotate
0°, 90°, 180°, 270°
Available when single
display.
Display Mirror
OFF, L/R, U/D
Available when dual
display on left and
right.
Select Region
Menu setting to region selected according to users’ needs.
Input
Signal switch to region selected according to users’ needs.
Audio
Volume
0~100
System
Reset
Press to confirm after selected.
Menu Time
5~60s
OSD H Position
0~100 (To set menu display area)
OSD V Position
0~100 (To set menu display area)
Language
English, Chinese
Transparency
0~255 (To set menu transparency)
OSD Rotate
0°, 90°, 270°
Border Width
0~10
Border Color
R, G, B, W
Information
To display current information.

7
4. ACCESSORIES
Standard:
1. 12V DC adapter 1 piece
2. Folding sun shade cover 1 piece
3. HDMI 2.0 A/C cable 1 piece
4. VESA battery plate 1 piece
5. Shoe mount 1 piece
6. Manual 1 copy
Optional:
1. V-mount or Anton bauer mount 1 piece
2. V-mount or Anton bauer mount power cable 1piece
3. Li-ion Battery (F970) 1 piece

8
5. PARAMETERS
Panel
12.5”8bit
Physical
Resolution
3840×2160
Brightness
400 cd/㎡
Contrast
1500: 1
Viewing Angle
170°/ 170°(H/V)
Input Voltage
DC 7-20V
Input Signal
Display Port, HDMI 1, HDMI 2, HDMI 3, HDMI 4 and 3G-SDI
Output Signal
3G-SDI
SDI Format
SD
525(59.94i)
625(50i)
HD(1920*1080)
1080(23.98p/23.98sF/24p/24sF/25p/25sF/29.97p
/29.97sF/30p30sF/50i/59.94i/60i)
HD(1920*720)
720(24p/25p/29.97p/30p/50p/59.94p/60p/23.98p)
3G-Level A
(1920*1080)
1080(23.98p/23.98sF/24p/24sF/25p/25sF/29.97p
/29.97sF/30p/30sF/50i/59.94i/60i/50p/59.94p/60p)
3G-Level A
(1280*720)
720(23.98p/24p/25p/29.97p/30p/50p/59.94p/60p)
3G-Level
A(2K*1080)
2K(23.98p/24p/25p/29.97p/30p/23.98sF/24sF
/25sF/29.97sF/30sF)
3G-Level B
(1920*1080)
1080(23.98p/23.98sF/24p/24sF/25p/25sF/29.97p
/29.97sF/30p/30sF/50i/59.94i/60i/50p/59.94p/60p)
3G-Level B
(2K*1080)
2K(23.98p/24p/25p/29.97p/30p/23.98sF/24Sf
/25sF/29.97sF/30sF)
3G-Level B
(2*HD 1080)
1080(23.98p/23.98sF/24p/24sF/25p/25sF/29.97p
/29.97sF/30p/30sF/50i/59.94i/60i)
3G-Level B
(2*HD 720)
720(23.98p/24p/25p/29.97p/30p/50p/59.94p/60p)
HDMI 4K
Format
HDMI1 (2.0)
3840*2160(23/24/25/29/30/50/59/60)
4096*2160(23/24/25/29/30/50/59/60)
HDMI2/3/4(1.4)
3840*2160(23/24/25/29/30)
4096*2160(23/24/25/29/30)
HDMI Format
1080 (23.97p/24p/25p/29.97p/30p/50p/59.94p/60p/50i/59.94i/60i)
720 (50p/59.94p/60p)
576(50p/50i)
480(59.94p/60p/59.94i/60i)
Power
Consumption
≤18W
Operating
Temperature
0℃~60℃
Storage
Temperature
-20℃~70℃
Dimension
(LWD)
297.6 x 195 x 21.8mm
Weight
960g

9
6. TROUBLE SHOOTING
1. Only black-and-white display:
Check whether the color saturation is properly setup or not.
2. Power on but no pictures:
Check whether the cables of DP, HDMI, and 3G-SDI are correctly connected
or not. Please use the standard power adapter coming with the product
package. Improper power input may cause damage.
3. Wrong or abnormal colors:
Check whether the cables are correctly and properly connected or not.
Broken or loose pins of the cables may cause a bad connection.
4. When on the picture shows size error:
Press “MENU →FUNCTION →Underscan” to zoom in/out pictures
automatically when receiving HDMI signals
5. Other problems:
Please press dial button and choose “MENU→SYSTEM→ Reset →ON”
6. According to the ISP, the machine can not function properly:
ISP for program upgrades, non-professionals do not use. Please reboot
your device if press accidentally!
Note: due to constant effort to improve products and product features,
specifications may change without notice.
