Lincoln Electric Prism 2400 User manual

Prism 2400 Stationary Fan
Register your machine:
www.lincolnelectric.com/register
Authorized Service and Distributor Locator:
www.lincolnelectric.com/locator
IM10589 | Issue Date Apr - 22
© Lincoln Global, Inc. All Rights Reserved.
For use with machines having Code Numbers:
13120, 13121
Save for future reference
Date Purchased
Code: (ex: 10859)
Serial: (ex: U1060512345)
Operator’s Manual
™

THANK YOU FOR SELECTING
A QUALITY PRODUCT BY
LINCOLN ELECTRIC.
PLEASE EXAMINE CARTON AND EQUIPMENT FOR
DAMAGE IMMEDIATELY
When this equipment is shipped, title passes to the purchaser
upon receipt by the carrier. Consequently, claims for material
damaged in shipment must be made by the purchaser against the
transportation company at the time the shipment is received.
SAFETY DEPENDS ON YOU
Lincoln arc welding and cutting equipment is designed and built
with safety in mind. However, your overall safety can be increased
by proper installation ... and thoughtful operation on your part.
DO NOT INSTALL, OPERATE OR REPAIR THIS EQUIPMENT
WITHOUT READING THIS MANUAL AND THE SAFETY
PRECAUTIONS CONTAINED THROUGHOUT. And, most importantly,
think before you act and be careful.
This statement appears where the information must be followed
exactly to avoid serious personal injury or loss of life.
This statement appears where the information must be followed
to avoid minor personal injury or damage to this equipment.
KEEP YOUR HEAD OUT OF THE FUMES.
DON’T get too close to the arc.
Use corrective lenses if necessary
to stay a reasonable distance
away from the arc.
READ and obey the Safety Data
Sheet (SDS) and the warning label
that appears on all containers of
welding materials.
USE ENOUGH VENTILATION or
exhaust at the arc, or both, to
keep the fumes and gases from
your breathing zone and the general area.
IN A LARGE ROOM OR OUTDOORS, natural ventilation may be
adequate if you keep your head out of the fumes (See below).
USE NATURAL DRAFTS or fans to keep the fumes away
from your face.
If you develop unusual symptoms, see your supervisor.
Perhaps the welding atmosphere and ventilation system
should be checked.
WEAR CORRECT EYE, EAR &
BODY PROTECTION
PROTECT your eyes and face with welding helmet
properly fitted and with proper grade of filter plate
(See ANSI Z49.1).
PROTECT your body from welding spatter and arc
flash with protective clothing including woolen
clothing, flame-proof apron and gloves, leather
leggings, and high boots.
PROTECT others from splatter, flash, and glare
with protective screens or barriers.
IN SOME AREAS, protection from noise may be appropriate.
BE SURE protective equipment is in good condition.
Also, wear safety glasses in work area
AT ALL TIMES.
SPECIAL SITUATIONS
DO NOT WELD OR CUT containers or materials which previously
had been in contact with hazardous substances unless they are
properly cleaned. This is extremely dangerous.
DO NOT WELD OR CUT painted or plated parts unless special
precautions with ventilation have been taken. They can release
highly toxic fumes or gases.
Additional precautionary measures
PROTECT compressed gas cylinders from excessive heat,
mechanical shocks, and arcs; fasten cylinders so they cannot fall.
BE SURE cylinders are never grounded or part of an
electrical circuit.
REMOVE all potential fire hazards from welding area.
ALWAYS HAVE FIRE FIGHTING EQUIPMENT READY FOR
IMMEDIATE USE AND KNOW HOW TO USE IT.
WARNING
CAUTION
Safety 01 of 04 - 5/16/2018

SECTION A:
WARNINGS
CALIFORNIA PROPOSITION 65 WARNINGS
WARNING: Breathing diesel engine exhaust
exposes you to chemicals known to the State
of California to cause cancer and birth defects,
or other reproductive harm.
• Always start and operate the engine in a
well-ventilated area.
• If in an exposed area, vent the exhaust to the outside.
• Do not modify or tamper with the exhaust system.
• Do not idle the engine except as necessary.
For more information go to
www.P65 warnings.ca.gov/diesel
WARNING: This product, when used for welding or
cutting, produces fumes or gases which contain
chemicals known to the State of California to cause
birth defects and, in some cases, cancer. (California
Health & Safety Code § 25249.5 et seq.)
WARNING: Cancer and Reproductive Harm
www.P65warnings.ca.gov
ARC WELDING CAN BE HAZARDOUS. PROTECT
YOURSELF AND OTHERS FROM POSSIBLE SERIOUS
INJURY OR DEATH. KEEP CHILDREN AWAY.
PACEMAKER WEARERS SHOULD CONSULT WITH
THEIR DOCTOR BEFORE OPERATING.
Read and understand the following safety highlights. For
additional safety information, it is strongly recommended
that you purchase a copy of “Safety in Welding & Cutting -
ANSI Standard Z49.1” from the American Welding Society,
P.O. Box 351040, Miami, Florida 33135 or CSA Standard
W117.2. A Free copy of “Arc Welding Safety” booklet E205
is available from the Lincoln Electric Company, 22801
St. Clair Avenue, Cleveland, Ohio 44117-1199.
BE SURE THAT ALL INSTALLATION, OPERATION,
MAINTENANCE AND REPAIR PROCEDURES ARE
PERFORMED ONLY BY QUALIFIED INDIVIDUALS.
FOR ENGINE POWERED
EQUIPMENT.
1.a. Turn the engine off before troubleshooting
and maintenance work unless the
maintenance work requires it to be running.
1.b. Operate engines in open, well-ventilated areas or vent the engine
exhaust fumes outdoors.
1.c. Do not add the fuel near an open ame welding
arc or when the engine is running. Stop the
engine and allow it to cool before refueling to
prevent spilled fuel from vaporizing on contact
with hot engine parts and igniting. Do not spill fuel when lling
tank. If fuel is spilled, wipe it up and do not start engine until
fumes have been eliminated.
1.d. Keep all equipment safety guards, covers
and devices in position and in good repair.
Keep hands, hair, clothing and tools away
from V-belts, gears, fans and all other
moving parts when starting, operating or
repairing equipment.
1.e. In some cases it may be necessary to remove safety guards to
perform required maintenance. Remove guards only when
necessary and replace them when the maintenance requiring
their removal is complete. Always use the greatest care when
working near moving parts.
1.f. Do not put your hands near the engine fan. Do not attempt to
override the governor or idler by pushing on the throttle control
rods while the engine is running.
1.g. To prevent accidentally starting gasoline engines while turning
the engine or welding generator during maintenance work,
disconnect the spark plug wires, distributor cap or magneto wire
as appropriate.
1.h. To avoid scalding, do not remove the radiator
pressure cap when the engine is hot.
ELECTRIC AND
MAGNETIC FIELDS MAY
BE DANGEROUS
2.a. Electric current owing through any conductor
causes localized Electric and Magnetic Fields (EMF).
Welding current creates EMF elds around welding cables
and welding machines
2.b. EMF elds may interfere with some pacemakers, and
welders having a pacemaker should consult their physician
before welding.
2.c. Exposure to EMF elds in welding may have other health effects
which are now not known.
2.d. All welders should use the following procedures in order to
minimize exposure to EMF elds from the welding circuit:
2.d.1. Route the electrode and work cables together - Secure
them with tape when possible.
2.d.2. Never coil the electrode lead around your body.
2.d.3. Do not place your body between the electrode and work
cables. If the electrode cable is on your right side, the
work cable should also be on your right side.
2.d.4. Connect the work cable to the workpiece as close as pos-
sible to the area being welded.
2.d.5. Do not work next to welding power source.
SAFETY
Safety 02 of 04 - 5/16/2018

ELECTRIC SHOCK
CAN KILL.
3.a. The electrode and work (or ground) circuits are
electrically “hot” when the welder is on. Do
not touch these “hot” parts with your bare skin or wet clothing.
Wear dry, hole-free gloves to insulate hands.
3.b. Insulate yourself from work and ground using dry insulation.
Make certain the insulation is large enough to cover your full area
of physical contact with work and ground.
In addition to the normal safety precautions, if
welding must be performed under electrically
hazardous conditions (in damp locations or while
wearing wet clothing; on metal structures such as
floors, gratings or scaffolds; when in cramped
positions such as sitting, kneeling or lying, if there
is a high risk of unavoidable or accidental contact
with the workpiece or ground) use the following
equipment:
• Semiautomatic DC Constant Voltage (Wire) Welder.
• DC Manual (Stick) Welder.
• AC Welder with Reduced Voltage Control.
3.c. In semiautomatic or automatic wire welding, the electrode,
electrode reel, welding head, nozzle or semiautomatic welding
gun are also electrically “hot”.
3.d. Always be sure the work cable makes a good electrical
connection with the metal being welded. The connection should
be as close as possible to the area being welded.
3.e. Ground the work or metal to be welded to a good electrical (earth)
ground.
3.f. Maintain the electrode holder, work clamp, welding cable and
welding machine in good, safe operating condition. Replace
damaged insulation.
3.g. Never dip the electrode in water for cooling.
3.h. Never simultaneously touch electrically “hot” parts of electrode
holders connected to two welders because voltage
between the
two can be the total of the open circuit voltage of both
welders.
3.i. When working above floor level, use a safety belt to protect
yourself from a fall should you get a shock.
3.j. Also see Items 6.c. and 8.
ARC RAYS CAN BURN.
4.a. Use a shield with the proper filter and cover plates to protect your
eyes from sparks and the rays of the arc when welding or
observing open arc welding. Headshield and filter lens should
conform to ANSI Z87. I standards.
4.b. Use suitable clothing made from durable flame-resistant material
to protect your skin and that of your helpers from the arc rays.
4.c. Protect other nearby personnel with suitable, non-flammable
screening and/or warn them not to watch the arc nor expose
themselves to the arc rays or to hot spatter or metal.
FUMES AND GASES
CAN BE DANGEROUS.
5.a. Welding may produce fumes and gases
hazardous to health. Avoid breathing these
fumes and gases. When welding, keep your head out of the fume.
Use enough ventilation and/or exhaust at the arc to keep fumes
and gases away from the breathing zone. When welding
hardfacing (see instructions on container or SDS)
or on lead or cadmium plated steel and other
metals or coatings which produce highly toxic
fumes, keep exposure as low as possible and
within applicable OSHA PEL and ACGIH TLV limits
using local exhaust or mechanical ventilation
unless exposure assessments indicate otherwise.
In confined spaces or in some circumstances,
outdoors, a respirator may also be required.
Additional precautions are also required when
welding
on galvanized steel.
5. b. The operation of welding fume control equipment is affected by
various factors including proper use and positioning of the
equipment, maintenance of the equipment and the specific
welding procedure and application involved. Worker exposure
level should be checked upon installation and periodically
thereafter to be certain it is within applicable OSHA PEL and
ACGIH TLV limits.
5.c. Do not weld in locations near chlorinated hydrocarbon vapors
coming from degreasing, cleaning or spraying operations. The
heat and rays of the arc can react with solvent vapors to form
phosgene, a highly toxic gas, and other irritating products.
5.d. Shielding gases used for arc welding can displace air and
cause
injury or death. Always use enough ventilation, especially in
confined areas, to insure breathing air is safe.
5.e. Read and understand the manufacturer’s instructions for this
equipment and the consumables to be used, including the
Safety Data Sheet (SDS) and follow your employer’s safety
practices. SDS forms are available from your welding
distributor or from the manufacturer.
5.f. Also see item 1.b.
SAFETY
Safety 03 of 04 - 5/16/2018

WELDING AND CUTTING
SPARKS CAN CAUSE
FIRE OR EXPLOSION.
6.a. Remove fire hazards from the welding area. If
this is not possible, cover them to prevent the welding sparks
from starting a fire. Remember that welding sparks and hot
materials from welding can easily go through small cracks and
openings to adjacent areas. Avoid welding near hydraulic lines.
Have a fire extinguisher readily available.
6.b. Where compressed gases are to be used at the job site, special
precautions should be used to prevent hazardous situations.
Refer to “Safety in Welding and Cutting” (ANSI Standard Z49.1)
and the operating information for the equipment being used.
6.c. When not welding, make certain no part of the electrode circuit is
touching the work or ground. Accidental contact can cause
overheating and create a fire hazard.
6.d. Do not heat, cut or weld tanks, drums or containers until the
proper steps have been taken to insure that such procedures
will not cause flammable or toxic vapors from substances inside.
They can cause an explosion even though they have been
“cleaned”. For information, purchase “Recommended Safe
Practices for the Preparation for Welding and Cutting of
Containers and Piping That Have Held Hazardous Substances”,
AWS F4.1 from the American Welding Society
(see address above).
6.e. Vent hollow castings or containers before heating, cutting or
welding. They may explode.
6.f. Sparks and spatter are thrown from the welding arc. Wear oil free
protective garments such as leather gloves, heavy shirt, cuffless
trousers, high shoes and a cap over your hair. Wear ear plugs
when welding out of position or in confined places. Always wear
safety glasses with side shields when in a welding area.
6.g. Connect the work cable to the work as close to the welding area
as practical. Work cables connected to the building framework or
other locations away from the welding area increase the
possibility of the welding current passing through lifting chains,
crane cables or other alternate circuits. This can create fire
hazards or overheat lifting chains or cables until they fail.
6.h. Also see item 1.c.
6.I. Read and follow NFPA 51B “Standard for Fire Prevention During
Welding, Cutting and Other Hot Work”, available from NFPA, 1
Batterymarch Park, PO box 9101, Quincy, MA 022690-9101.
6.j. Do not use a welding power source for pipe thawing.
CYLINDER MAY EXPLODE IF
DAMAGED.
7.a. Use only compressed gas cylinders containing
the correct shielding gas for the process used
and properly operating regulators designed for
the gas and pressure used. All hoses, fittings,
etc. should be suitable for the application and
maintained in good condition.
7.b. Always keep cylinders in an upright position securely chained to
an undercarriage or fixed support.
7.c. Cylinders should be located:
• Away from areas where they may be struck or subjected
to physical damage.
• A safe distance from arc welding or cutting operations
and any other source of heat, sparks, or flame.
7.d. Never allow the electrode, electrode holder or any other
electrically “hot” parts to touch a cylinder.
7.e. Keep your head and face away from the cylinder valve outlet
when opening the cylinder valve.
7.f. Valve protection caps should always be in place and hand tight
except when the cylinder is in use or connected for use.
7.g. Read and follow the instructions on compressed gas cylinders,
associated equipment, and CGA publication P-l, “Precautions for
Safe Handling of Compressed Gases in Cylinders,” available from
the Compressed Gas Association, 14501 George Carter Way
Chantilly, VA 20151.
FOR ELECTRICALLY
POWERED EQUIPMENT.
8.a. Turn off input power using the disconnect
switch at the fuse box before working on
the equipment.
8.b. Install equipment in accordance with the U.S. National Electrical
Code, all local codes and the manufacturer’s recommendations.
8.c. Ground the equipment in accordance with the U.S. National
Electrical Code and the manufacturer’s recommendations.
Refer to
http://www.lincolnelectric.com/safety
for additional safety information.
SAFETY
Safety 04 of 04 - 5/16/2018

TABLE OF CONTENTS
PRISM 2400 STATIONARY FAN
TABLE OF CONTENTS
Page
Installation........................................................................................................................
General Description .........................................................................................................1
1................................
:rewoPtupnI
05/1/V032&06/1/V021rofseirosseccAderiuqeR
Technical Specifications ..................................................................................................1
Installation of Wall Mounting Brackets.............................................................................3
Installation of Prism 2400 Stationary Fan With Flexible 10 FT OR 13 FT Extraction
Arm ..................................................................................................................................4
Installation of Prism 2400 Stationary Fan With Telecopic 5 ft Extraction Arm .................6
Installing The Starter/Overload Switch ............................................................................7
Operation..........................................................................................................................
Operating Instructions......................................................................................................8
Maintenance .....................................................................................................................
Routine Maintenance.......................................................................................................8
Troubleshooting ..............................................................................................................
Troubleshooting Guide ....................................................................................................9
Wiring Diagrams ..........................................................................................................10
Parts List ................................................................................parts.lincolnelectric.com
Content/details may be changed or updated without notice.
For most current Instruction Manuals, go to parts.lincolnelectric.com
....
.

INSTALLATIONPRISM 2400 STATIONARY FAN
GENERAL DESCRIPTION
The Prism 2400 Stationary Fan provides low vacuum, high volume
most commonly paired with a Lincoln Electric Flexible 10 ft or 13 ft
spring-balanced, articulated arm. The Telescopic, or Flexible 7 FT
arm is a popular choice for small booth or workstation applications.
Extracted air can be vented to the outside through an Air Exhaust
Prism Wall Mount.
Operation of the Prism 2400 Stationary Fan is controlled using the
Starter/Overload Switch or the Lamp Kit with Arc Sensor. The
Starter/Overload Switch allows the operator to manually turn the
Prism 2400 Stationary Fan on and off and protects the fan motor
against overcurrent. The Lamp Kit with Arc Sensor includes a lamp
for illuminating the work piece, hood-mounted on/off switches for
the lamp and extraction fan, motor overload protection, and an arc
sensor for automatic operation of the extraction fan.
REQUIRED ACCESSORIES FOR 120V/1/60 INPUT
POWER:
K1494-2 STARTER/OVERLOAD SWITCH
REQUIRED ACCESSORIES FOR 230V/1/50 INPUT
POWER:
K1494-3 STARTER/OVERLOAD SWITCH
Available Equipment:
K1655-8 Flexible 10 FT Extraction Arm
K1655-9 Flexible 13 FT Extraction Arm
K1655-10 Telescopic 5 FT Extraction Arm
K1655-12 Flexible 7 FT Extraction Arm
K1655-13 Low Ceiling 13 FT Extraction Arm
K1534-2 Air Exhaust Silencer
TECHNICAL
SPECIFICATIONS
NOTE: Technical specifications are subject to change without prior notice.
Specifications and guarantees are valid only when specified spare parts
and filters are used.
FIGURE 1 – DIMENSIONS
10”
(250 mm)
9”
(230 mm)
5”
(130 mm)
11”
(275 mm)
9”
(230 mm)
6.5” (ø160 mm)
ø6.3” (ø160 mm)
ø6.3”
(160 mm)
3”
(70 mm)
12”
(300 mm)
GENERAL
PRODUCT NUMBER K1656-9 K2497-13
INPUT POWER 115V, 1Ph, 60Hz 230V, 1Ph, 50Hz
RATED CURRENT DRAW 9.4A 4.7A
HORSEPOWER 1HP (0.75 kW)
SOUND LEVEL 69 dB(A)
WEIGHT 28 lbs. (14 kg)
AMBIENT CONDITIONS
MINIMUM TEMPERATURE 41ºF (5ºC)
MAXIMUM TEMPERATURE 113ºF (45ºC)
MAXIMUM RELATIVE HUMIDITY 80%
1

2
INSTALLATIONPRISM 2400 STATIONARY FAN
FIGURE 2 – PRESSURE DROP
PRISM 2400 FAN
AND
Flexible 10 FT and 13 FT ARMS
500 750
4
6
00010520
2
0
Air Flow (CFM)
V
(Inches WG)
PRISM 2400
Flexible 10 FT or 13 FT
Vacuum (inches WG) vs. Airflow (CFM)
FIGURE 3 – PRESSURE DROP
PRISM 2400 FAN
AND
Telescopic and Flexible 7 FT ARM
6
4
2
0
0 250 500 750 1000
PRISM 2400
Telescopic or
Flexible 7 FT
(Inches WG)
Air Flow (CFM)
Vacuum (inches WG) vs. Airflow (CFM)

3
INSTALLATIONPRISM 2400 STATIONARY FAN
INSTALLATION OF WALL
MOUNTING BRACKETS
The installer is responsible for following Federal, State and
Local safety codes and regulations.
Before drilling, verify locations of existing gas, water, or
electrical conduits.
ELECTRIC SHOCK can kill.
• Do not touch electrically live parts such as
internal wiring.
• Turn the input power off at the fuse box before
working on this equipment.
• Have a qualied person install and service this
equipment.
MOVING PARTS can injure.
• Do not operate with covers open or lter
removed.
• Keep away from moving parts.
ONLY QUALIFIED PERSONNEL SHOULD INSTALL,
USE OR SERVICE THIS EQUIPMENT.
K1657-1 Wall Mounting Bracket kit includes:
• (2) Bracket pieces
• Hanging Adapter
• Spring Bracket
• Flexible Hose
• (2) Bolts, M8x1.25, about 1.75” (45mm) long
• (4) Bolts, M8x1.25, about 3.00” (75mm) long
• (6) Nuts, Self-Locking, M8
• (6) Washers, M8
K1657-2 Wall Mounting Bracket kit includes:
• (2) Bracket pieces
• Tapered connection ange
• Hose Clamp, 8” (203mm)
NOTE:
Starter/Overload Switch must be installed with this package. See the
installation section later in this manual for details on installing this
equipment.
K1494-2 STARTER/OVERLOAD SWITCH FOR 120V
K1494-3 STARTER/OVERLOAD SWITCH FOR 230V
Standard mounting height is approximately 8 ft., 2 in. from the oor to
the top of the wall mounting bracket. See Figure 4 for drilling
dimensions.
See Figure 5 for recommended mounting methods for installation on
various wall types.
A. Mounting on a thin wall (recommended minimum wall thickness 5 in.
(100 mm), using four threaded rods, 3/8 in. (M10).
B. Mounting on a thick wall using four cotter bolts 3/8 in. (M10).
C. Mounting on a steel I-beam using four threaded rods 3/8 in. (M10)
and two box-prole stabilizers (1x1x0.1 in., 30x30x3mm).
WARNING
FIGURE 4
9" (230 mm)
8.3"
(210 mm)
6.3" (160 mm)
FIGURE 5
A
C
B
3/8"
3/8"
3/8"
3/8"

4
INSTALLATIONPRISM 2400 STATIONARY FAN
INSTALLATION OF PRISM
2400 STATIONARY FAN WITH
FLEXIBLE 10 FT OR 13 FT
EXTRACTION ARM
K1656-9 Prism 2400 Stationary Fan Includes:
• Prism 2400 Stationary Fan
• (2) Bolts, M8x1.25, about 0.75” (20mm) long
• (2) Bolts, M8x1.25, about 2.5” (65mm) long
• (4) Washers, M8
K1655-8 Flexible 10 FT or K1655-9 Flexible 13 FT Arm
includes:
• Assembled arm, 2 sections
• Flexible hose, (2) 8” Rubber seals for hood hinge
• Hood assembly
• (2) Bolts, M8x1.25, about 1.75” (45mm) long
• (2) Nuts, M8 self-locking
• Hose running guard
• Clamping pin for red plastic ring
• Metal rotating hinge
• Red plastic ring
Install mounting brackets as detailed in the section titled
“INSTALLATION OF WALL MOUNTING BRACKETS”
Mounting the Extraction Arm
Leave the tape and plastic packaging on the extraction arm
sections until the arm is completely installed (including
mounting the hood). The arm is spring-balanced to compensate for
the weight of the hood and will spring out quickly if it is not mounted
securely, with the hood in place.
The rotating hinge of the arm comes in three pieces: Metal rotating
hinge, red plastic ring, and clamping pin. See Figure 6. Mount the red
plastic ring to the metal rotating hinge by tting the clamping pin
through the hole in the rotating rod, and snapping it into place on the
U-shaped indents on the red plastic ring. The lip of the ring should t
securely against the top edge of the rotating ange, yet rotate with
the rod. The assembly should look like Part C in Figure 7.
Position the rotating hinge on the wall mounting bracket
(See Figure 7) so that the cable hole (Item A) is on the wall side and
the long side of the pin (Item B) is in the front. Use the four 3” bolts
with washers and nuts supplied withthe wall mounting brackets to
secure the rotating hinge.
SEE THE FLEXIBLE 10 FT OR 13 FT EXTRACTION ARMS
OPERATOR’S MANUAL FOR DETAILS ON COMPLETING
THE INSTALLATION OF THE ARM.
FIGURE 6
2
1
3
FIGURE 7
D
E
C
B
A

5
INSTALLATIONPRISM 2400 STATIONARY FAN
Mounting the Prism 2400 Fan
Use the (2) 0.75” bolts and the (2) 2.5” bolts with washers supplied
with the fan to mount the fan (See Figure 8, Item B) to the rotating
hinge (See Figure 8, Item C) as shown. Tighten all mounting bolts
rmly to make the seal at the inlet of the fan.
SEE INSTALLING THE STARTER/OVERLOAD SWITCH
AND INSTALLING THE OPTIONAL LAMP KIT AND
AUTOMATIC START/STOP ARC SENSOR.
FIGURE 8
A
B
C

6
INSTALLATIONPRISM 2400 STATIONARY FAN
INSTALLATION OF PRISM
2400 STATIONARY FAN
WITH TELESCOPIC 5 FT
EXTRACTION ARM
K1656-9 Prism 2400 Stationary Fan Includes:
• Prism 2400 Stationary Fan
• (2) Bolts, M8x1.25, about 0.75” (20mm) long
• (2) Bolts, M8x1.25, about 2.5” (65mm) long
• (4) Washers, M8
K1655-10 Telescopic 5 FT Extraction Arm includes:
• Telescopic Arm, Assembled
• Flexible hose, (2) 8” Rubber seals for connection to fan
Install wall mounting brackets as detailed in the section titled
“INSTALLATION OF WALL MOUNTING BRACKETS”
Position the tapered connection ange (See Figure 9, item C) on the
wall mounting brackets. Use the (2) 0.75” long and (2) 2.5” long
bolts with washers supplied with the fan to secure the Prism 2400
Stationary Fan (See Figure 9, item B) and the tapered connection
ange to the wall mounting brackets. Tighten all bolts securely to
make a good seal on the inlet of the fan.
Position one of the 8” rubber seals supplied with the Telescopic
5 FT Arm on the largest part (8” diameter) of the tapered connection
ange. Roll the bottom of the rubber seal up, and slide one end of
the 4 ft. exible hose (supplied with the arm) up over the tapered
connection ange until it butts up against the folded side of the
rubber seal. Fold the rubber seal down over the hose.
Secure the connection with one 8” hose clamp. Apply the second 8”
rubber seal and the other end of the exible hose to the top of the
telescopic arm tube.
SEE THE TELESCOPIC 5 FT EXTRACTION ARM
OPERATOR’S MANUAL FOR DETAILS ON COMPLETING
THE INSTALLATION OF THE ARM.
INSTALLING WITH OPTIONAL PRISM WALL MOUNT
The Prism Wall Mount Filter Unit can be installed to lter the
exhausted air before it is recirculated or exhausted outside.
The K1654-4 Prism Wall Mount Filter Unit Includes:
• Complete Filter Unit, with lter installed and inlet(s) and outlet(s)
sealed
• Reducer, 6”-8”
• 8” Connection hose, 4 ft. long
• (2) 8” Hose Clamps
Fit the small (6” diam.) side of the 6”-8” Reducer (See Figure 10,
item B) over the outlet of the Prism 2400 Fan (See Figure 10, item A);
be sure to slide the Reducer all the way over the rubber seal. Secure
with three sheet-metal screws through the reducer into the plastic-
molded fan outlet.
Fit one end of the 8” Connection hose (See Figure 10, item C) over the
larger side of the 6”-8” Reducer. Secure with one 8” hose clamp.
SEE PRISM WALL MOUNT MANUAL FOR COMPLETION OF
THE INSTALLATION PROCEDURE.
FIGURE 10
8” DIAMETER
CONNECTION HOSE
8” HOSE CLAMP
REDUCER 6.3” - 8”
B
A
C
FIGURE 9
A
B
D
C

7
INSTALLATIONPRISM 2400 STATIONARY FAN
INSTALLING THE
STARTER/OVERLOAD
SWITCH
120V ARRANGEMENT
The K1494-2 Starter/Overload Switch is used for manual operation of
the Prism 2400 Stationary Fan. The Starter/Overload Switch is not
required if using a K1669-4 Lamp Kit with Arc Sensor.
Mount the Starter/Overload Switch to a wall in a location convenient
to the operator.
Route a 120VAC, 1ph, 60hz supply cable into the switch compartment
and a power cable between the switch and the Prism 2400 Stationary
diagram located in the diagram section of this manual. Set the
overload to 10.0A.
230V ARRANGEMENT
The K1494-3 Starter/Overload Switch is used for manually operation
Prism 2400 Stationary Fan. The Starter/Overload Switch is not required
if using a K1669-4 Lamp Kit with Arc Sensor. The K1750-1 230V
Conversion Kit adapts the Lamp Kit with Arc Sensor for operation on
230V.
• Mount the Starter/Overload Switch to a wall in a location
convenient to the operator.
• Route a 230VAC, 1ph, 50hz supply cable into the switch
compartment and a power cable between the switch and the
connections per the wiring diagram located in diagram section of
this manual.
Connection changes are necessary to properly operate the fan motor
on 230V/1ph. Refer to the connection diagram on motor nameplate.
.

8
OPERATION
OPERATING
INSTRUCTIONS
Use the wall-mounted starter/overload switch or the hood-mounted
remote switch (if a lamp kit is installed) to turn on the Prism 2400
Stationary Fan.
Position hood within 10-15 inches (250-400 mm) of the arc.
If using a Lamp Kit:
• The switch on the hood with a lamp symbol operates
the work lamp in the hood.
• The 0/1 switch operates the Prism 2400 Fan.
If using an Auto Start/Stop Arc Sensor:
Leave the 0/1 switch in the 0 (off) position. The arc sensor will
automatically switch the fan on when it senses an arc. Standard run-
out time is approximately 20 sec. The work lamp operates
independently of this sensor.
ROUTINE
MAINTENANCE
Every 12 months, have a qualied technician check the blower fan
and housing for encrusted particles and clean if necessary. Check the
sealing material of the extraction fan and replace if necessary.
If used, refer to the Prism Wall Mount, Extraction arm, Extension
crane, Lamp kit, and Auto start/stop arc sensor manuals for required
routine maintenance operations.
PRISM 2400 STATIONARY FAN

9
TROUBLESHOOTING
PRISM 2400 STATIONARY FAN
If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your
Lincoln Authorized Service Facility for technical troubleshooting assistance before you proceed.
WWW.LINCOLNELECTRIC.COM/LOCATOR
Service and Repair should only be performed by Lincoln Electric Factory Trained Personnel. Unauthorized repairs performed on
this equipment may result in danger to the technician and machine operator and will invalidate your factory warranty. For your
safety and to avoid ELECTRICAL SHOCK, please observe all safety notes and precautions detailed throughout this manual.
PROBLEMS / SYMPTOM(S) POSSIBLE CAUSE(S) RECOMMENDED COURSE(S) OF ACTION
MOTOR DOES NOT START. No input power. Verify 120VAC/60Hz, 1ph or 230VAC/50Hz, 1ph input power
at the machine
Input cord maybe damaged. Check the integrity of the input cord
Loose Contacts Check the contacts.
Starter/overload switch
damaged or defective.
Contact Lincoln Authorized Service Facility
Motor maybe damaged or
defective.
Contact Lincoln Authorized Service Facility
MOTOR HUMS, BUT NO
SUCTION.
Motor capacitor defective or not
connected.
Contact Lincoln Authorized Service Facility
MOTOR STOPS
AUTOMATICALLY
Motor overload protection
activated.
Let the machine cool down for a few minutes.
Motor defective or damaged Contact Lincoln Authorized Service Facility
POOR SUCTION. Leakage. Check hose connections and integrity.
Outlet grid blocked. Remove obstructions from outlet grid.
Air path in arm blocked. Remove obstructions from arm.
Filter blocked (check
Maintenance Indicator).
Spark arrester blocked. Clean the spark arrester.
Blower fan blocked. Clean excess fume or spatter from fan.
Fan seal damaged. Check or replace sealing material of fan.
DUST OR SMOKE COMING OUT
OF OUTLET.
Filter damaged, or not seated
correctly.
VIBRATIONS IN THE MACHINE. Imbalance in the fan. Clean excess dirt from fan.
TROUBLESHOOTING GUIDE

10
DIAGRAMS
PRISM 2400 STATIONARY FAN
WIRING DIAGRAM FOR PRISM 2400 FAN WITH K1494-2 STARTER/OVERLOAD SWITCH
1 / L 1 3 / L 2 5 / L 3
2 / T 1 4 / T 2 6 / T 3
L
L
1 0
1 3
1 6
S T O P S T A R T
See motor (terminal cover) for
wiring instructions that pertain
to the specific motor type.
FAN MOTOR
INPUT POWER
115V/1
230V/1PH/50HZ
PH/60HZ
L
N
G N D
L
NL
N
G N DG N D
L
L
N
N
STARTER/OVERLOAD
SWITCH
G N D
G N D

11
DIAGRAMS
PRISM 2400 STATIONARY FAN
NOTE: This diagram is for reference only. It may not be accurate for all machines covered by this manual. The specic diagram for a particular code is pasted inside the machine on one of the enclosure panels. If the diagram is illegible, write to the Service Department for a replacement. Give the equipment code number.
Sales and Service through Subsidiaries and Distributors Worldwide
Cleveland, Ohio 44117-1199 U.S.A.
THE LINCOLN ELECTRIC COMPANY
World's Leader in Welding and Cutting Products
FC7900010440PRINT
B
NOTES: NA. MOUNTING ON DIN RAIL
NB. FIELD WIRING SHALL USE UL RATED 3C MIN 14 AWG CABLE
WITH OUTER DIA BETWEEN 0.27 TO 0.51 (7MM TO 13MM)
N C. 201,208,202B,205 SHALL BE BLACK AND 14AWG
115VAC, 60Hz, 1~
2A
1A1A C C
OL
A2 FAN ON/OFF
24V
FAN MANUAL ON/OFF
ARC SENSOR
FLOOD LIGHT
C OL
SET TO 11 AMPS
BK
BK
FAN MOTOR
120VAC,
I~, 60Hz, 1HP
L
N
S1
S2
S3
GND
SCHEMATIC
610
N
2
1 3 4 5
CONTROL BOX
DISCONNECTING MEANS AND BRANCH CIRCUIT
PROTECTION SHALL BE PROVIDED BY THE INSTALLER
LN
205
204B
L1 L2 L3 A1
13
CONTACTOR
OVERLOAD RELAY
SET AT 11 AMPS
T1 T2 T3 A2
BK
WH
TRANSFORMER
N24V
2A
G
WH
BK RD
ARC SENSOR
WH BL
RD
BK
BK
WH
CONN-PCB
YE/GN
BK
WH
GND
S2
S3
START CAPACITOR
201
201
207
206
NA
205
203
207
204A
204B
WIRING
3 CORE CABLE
NOT SUPPLIED
20AWG
3 CORE CABLE
SUPPLIED
S1
209
203
209
FAN MOTOR
115VAC, I~, 60 Hz, 1HP
MOTOR
Z2
U1
U2
V2
Z1
V1
BK RD
123422
10 6
5
202A
202B
208
NB.
NB.
RD
RD
WH
BK
BK BK
BK
BK
BK
BK
202
TB
NA
NA
G
GN
MOTOR LAMP CONTROLLER PRISM 2400, 115V, 1~, 60Hz, 1HP
WIRING DIAGRAM FOR PRISM 2400 FAN WITH K1669-4 LAMP KIT

12
DIAGRAMS
PRISM 2400 STATIONARY FAN
NOTE: This diagram is for reference only. It may not be accurate for all machines covered by this manual. The specic diagram for a particular code is pasted inside the machine on one of the enclosure panels. If the diagram is illegible, write to the Service Department for a replacement. Give the equipment code number.
Sales and Service through Subsidiaries and Distributors Worldwide
Cleveland, Ohio 44117-1199 U.S.A.
THE LINCOLN ELECTRIC COMPANY
World's Leader in Welding and Cutting Products
S31225-25PRINT
B
230VAC, 1~,50Hz
N
2
24V
2A
1A1A C C
OL
A2 FAN ON/OFF
N
24V
FAN MANUAL ON/OFF
ARC
SENSOR
FLOOD LIGHT
C OL
SET TO 5.75A
BK
BK
FAN MOTOR
230VAC, 1~,50Hz, 1HP
LN
S1
S2
S3
SCHEMATIC
1 3 4 5
6
10
GND
CONTROL BOX
L
GND
CONNECT GND TO TERMINAL
N
205
204B
L1 L2 L3 A1
13
CONTACTOR
OVERLOAD RELAY
SET AT 5.75A
T1 T2 T3 A2
13
TRANSFORMER
N24V
2A
WH BK
RD
3 CONDUCTOR CABLE, PROVIDED 20AWG
ARC SENSOR
WH BL
RD
BK
BK
WH
CONN-PCB
YE/GN
MOTOR
GND
FAN MOTOR
S1
S2
S3
START CAPACITOR
230VAC, 1~, 50Hz, 1HP
201
202
202
201
4 5
207
206
NA
205
203
209 203
207
204A
204B
209
WIRING
3 CORE 16AWG CABLE
20AWG
3 CORE CABLE
NL
NL
Z2
U2
V2
U1 V1 Z1
BK
RD
2
610
N B.
N B.
DISCONNECTING MEANS AND BRANCH CIRCUIT
PROTECTION SHALL BE PROVIDED BY THE INSTALLER
208
MOTOR LAMP CONTROLLER PRISM 2400, 230V, 1~, 50Hz, 1HP
NOTES: NA. MOUNTING ON DIN RAIL NB. FIELD WIRING SHALL USE UL RATED 3C MIN 16AWG CABLE WITH OUTER DIA BETWEEN 0.27 TO 0.51 (7MM TO 13MM)
N C. 201,202,208SHALL BE BLACK AND 14AWG
WIRING DIAGRAM FOR PRISM 2400 FAN WITH K1750-1 CONVERSION KIT

THIS PAGE INTENTIONALLY LEFT BLANK

WARNING
AVISO DE
PRECAUCION
ATTENTION
WARNUNG
ATENÇÃO
Spanish
Fren h
German
Portuguese
Japanese
Chinese
Korean
Arabi
READ AND UNDERSTAND THE MANUFACTURER’S INSTRUCTION FOR THIS EQUIPMENT AND THE CONSUMABLES TO BE
USED AND FOLLOW OUR EMPLO ER’S SAFET PRACTICES.
SE RECOMIENDA LEER ENTENDER LAS INSTRUCCIONES DEL FABRICANTE PARA EL USO DE ESTE EQUIPO LOS
CONSUMIBLES QUE VA A UTILIZAR, SIGA LAS MEDIDAS DE SEGURIDAD DE SU SUPERVISOR.
LISEZ ET COMPRENEZ LES INSTRUCTIONS DU FABRICANT EN CE QUI REGARDE CET EQUIPMENT ET LES PRODUITS A
ETRE EMPLO ES ET SUIVEZ LES PROCEDURES DE SECURITE DE VOTRE EMPLO EUR.
LESEN SIE UND BEFOLGEN SIE DIE BETRIEBSANLEITUNG DER ANLAGE UND DEN ELEKTRODENEINSATZ DES HER-
STELLERS. DIE UNFALLVERHÜTUNGSVORSCHRIFTEN DES ARBEITGEBERS SIND EBENFALLS ZU BEACHTEN.
l Do not touch electrically live parts or
electrode with skin or wet clothing.
l Insulate yourself from work and
ground.
l No toque las partes o los electrodos
bajo carga con la piel o ropa moja-
da.
l Aislese del trabajo y de la tierra.
l Ne laissez ni la peau ni des vête-
ments mouillés entrer en contact
avec des pièces sous tension.
l Isolez-vous du travail et de la terre.
l Berühren Sie keine stromführenden
Teile oder Elektroden mit Ihrem
Körper oder feuchter Kleidung!
l Isolieren Sie sich von den
Elektroden und dem Erdboden!
l Não toque partes elétricas e elec-
trodos com a pele ou roupa molha-
da.
l Isole-se da peça e terra.
l Keep flammable materials away.
l Mantenga el material combustible
fuera del área de trabajo.
l Gardez à l’écart de tout matériel
inflammable.
l Entfernen Sie brennbarres Material!
l Mantenha inflamáveis bem guarda-
dos.
l Wear eye, ear and body protection.
l Protéjase los ojos, los oídos y el
cuerpo.
l Protégez vos yeux, vos oreilles et
votre corps.
l Tragen Sie Augen-, Ohren- und Kör-
perschutz!
l Use proteção para a vista, ouvido e
corpo.
