Table of Contents
SAFETY CONSIDERATIONS .................................................... I-VI
INSTALLATION ........................................................ SECTION A
TECHNICAL SPECIFICATIONS ............................................................... 3
SUPPORT EQUIPMENT REQUIRED ........................................................... 4
C
OOLANT RECOMMENDATIONS ............................................................. 4
TORCH LEAD CONNECTION ............................................................... 4
INSTALLING SPOOL ASSEMBLY .............................................................. 5
I
NTERCONNECTIONS ...................................................................... 6
OPERATION .......................................................... SECTION B
GENERAL ............................................................................... 7
BARRELS ................................................................................ 7
CONTROLS AND SETTINGS................................................................. 7
DRIVE ROLL AND IDLER ROLLS ............................................................ 8
ACCESSORIES ......................................................... SECTION C
CONTACT TIPS - AIR COOLED............................................................. 9
GAS CUPS - AIR COOLED ...............................................................10
C
ONTACT TIPS - WATER COOLED ........................................................10
GAS CUPS - WATER COOLED ............................................................10
BARREL LINERS .........................................................................11
B
ARREL ASSEMBLIES .....................................................................11
OPTIONAL BARRELS .....................................................................13
OPTIONAL KITS.........................................................................13
OPTIONAL ACCESSORIES .................................................................13
H
EAVY DUTY CONTACT TIPS .............................................................14
FINNED COPPER GAS CUPS ..............................................................14
KOOL CUP ADAPTER & CUPS............................................................15
GAS CUP & CONTACT TIPS - 48° ......................................................15
MAINTENANCE........................................................ SECTION D
PERIODIC MAINTENANCE .................................................................17
RECOMMENDED SPARE PARTS LIST ........................................................18
TROUBLESHOOTING ................................................... SECTION E
TROUBLESHOOTING GUIDE ...............................................................20
T
ESTING THE TORCH ....................................................................21
APPENDICES.......................................................... SECTION F
DIAGRAMS/PARTS LIST ..................................................................22
MECHANICAL ...........................................................................23
ELECTRICAL ............................................................................35
MK REPAIR STATIONS
SAFETY WARNINGS
WARRANTY
