Linksys WSB24 Original operating instructions

WWW.LINKSYS.COM
A. With your Access Point/Router powered off, place the Wireless Signal
Booster on top of the Access Point/Router.
B. Disconnect the Access Point’s/Router’s antennas.
C. Connect the Signal Booster Cables from the Access Point’s/Router’s anten-
na ports to the Wireless Signal Booster’s cable ports.
D. Connect the antennas to the Wireless Signal Booster’s antenna ports.
E. Connect the appropriate power adapters to both the Access Point/Router
and Wireless Signal Booster.
F. Now you are ready to use the Wireless Signal Booster in your wireless
network.
Connecting the Wireless Signal Booster
to Your Linksys Access Point/Router
QI-WSB24-10/25/02NC BW
B
Minimum Requirements
• One of the following Linksys products:
Wireless Access Point, WAP11
Wireless Router, BEFW11S4
Package Contents
• One Linksys Wireless Signal Booster
• Two Signal Booster Cables
• One Power Adapter
• One Quick Installation guide
Wireless Signal
Booster
Instant Wireless®
WSB24
The Wireless Signal Booster with Access Point C
D
E
Note: The images in this document show the Wireless Signal Booster being con-
nected to anAccess Point; the same directions can be followed when connecting the
Wireless Signal Booster to a wireless Router.
