EtherFast®3124
24-Port 10/100
Ethernet Switch
ith its advanced switching technology, the EtherFast®
3124 24-Port 10/100 Ethernet Switch will boost your
network performance with much more than just full
duplex data transfer and dedicated bandwidth. It features non-
blocking,wire-speed switching that forwards packets as fast as
your network can deliver them. Also included are Address
Learning and Aging to prevent data transfer errors and Data
Flow Control to help prevent packet collisions.
The EtherFast 3124 is rack mountable and includes an
Expansion Slot that accepts an optional Fiber Module to let you
grow your network by linking to other switches in full duplex
mode up to 2000 meters (6560 feet) away.
No matter how intensive your network demands, the EtherFast
3124 24-Port 10/100 Ethernet Switch's advanced chipset sup-
ports your needs with an affordable and efficient networking
solution you can count on.
• 24-Port 10/100 Full Duplex,Autosensing Ports
• Run Blazing Speeds of up to 200Mbps at Full Duplex
• Perfect for Running 10BaseT, 100BaseTX and 100BaseFX
Hardware Together Seamlessly
• Optional 100BaseFX Fiber Optic Module Sends Data Up to
2000 Meters (6560 feet) Away in Full Duplex Mode
• Data Flow Control Filters Out Faulty Data Packets
• Auto MDI/MDI-X
• Supports aging function, 802.3x Pause Frame for full duplex
• Broadcast storm control avoids unnecessary bandwidth
absorption
EtherFast®3124 24-Port 10/100 Ethernet Switch
Model No.: EF3124
High-speed 10/100 Switching
with Linksys reliability and Fiber Expandability
Features
Features
Benefits
Benefits
• 24 Autosensing 10/100 full duplex, auto
MDI/MDI-X ports
• Optional 100BaseFX Fiber Optic Module con-
nects multiple switches at high speed as your
network grows
• Run blazing speeds up to 200Mbps
• Address Learning and Data Flow Control for
transmission reliability
Instant EtherFast®Series
W

Package ContentsSpecifications
Model Number EF3124
Standards IEEE 802.3, IEEE 802.3u, IEEE 802.1p,
IEEE 802.3x
Ports 24 10/100 Auto-Negotiation RJ-45 Ports,
One Fiber Module Expansion Port
Cabling Type UTP/STP Category 5 or Better
LEDs Power, Link/Activity (per port),
Full Duplex (per port)
Environmental
Dimensions 7.09" x 1.75" x 16.93"
(180 mm x 44.5 mm x 430 mm)
Unit Weight 6.61 lbs. (3 kg)
Power 100-240V AC, 50-60 Hz
Certifications FCC Class A, CE
Operating Temp. 32ºF to 122ºF (0ºC to 50ºC)
Storage Temp. -40ºF to 158ºF (-40ºC to 70ºC)
Operating Humidity 20% to 95%, Non-Condensing
Storage Humidity 20% to 95%, Non-Condensing
• EtherFast®24-Port Switch
• AC Power Cable
• User Guide and Registration Card
• Mounting kit containing:
Four rubber feet for mounting the switch on
a table
Two mounting brackets
Six screws for attaching the brackets to the
switch
DS-ef3124-122402NC KL
