Linksys SFE2000 User manual

LINKSYS ONE COMMUNICATIONS SOLUTION
SFE2000/SFE2000P Fast Ethernet
Switch Reference Guide
December 2006

© 2006 Copyright 2006, Cisco Systems, Inc.
Specifications are subject to change without notice.
Linksys, the Cisco Systems logo, the Linksys Logo, and the Linksys One logo are registered trademarks of Cisco Systems,
Inc. All other trademarks mentioned in this document are the property of their respective owners.
Document Revision History
Revision Date Description

1
Contents
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Contents
Contents
Chapter 1: Getting Started . . . . . . . . . . . . . . . . . . . 1
Starting the Application 1
Understanding the Interface 4
Device Representation 5
Using the Linksys Management Buttons 6
Using Screen and Table Options 7
Adding Device Information 7
Modifying Device Information 7
Deleting Device Information 8
Resetting the Device 9
Logging Off The Device 9
Chapter 2: Managing Device Information . . . . . . . . . . . . . 11
Understanding the Device Zoom View 12
Defining General System Information 13
SFE 2000P System Information 13
Managing Stacks 14
Viewing Device Health 15
Chapter 3: Managing Power-over-Ethernet Devices . . . . . . . . . 17
DefiningPoE System Information 17
Chapter 4: Configuring Device Security . . . . . . . . . . . . . . 23
Passwords Management 24
Defining User Authentication 24
Defining Authentication 26
Defining Profiles 26
Mapping Profiles 28
Defining TACACS+ 29
Defining RADIUS 33
Defining Access Method 37
Defining Access Profiles 37
Defining Profile Rules 40
Defining Traffic Control 46
Defining Storm Control 46
Defining Port Security 48
Defining 802.1x 52
Defining 802.1X Properties 53
Defining Port Authentication 54
Defining Multiple Hosts 57
Defining Authenticated Host 60
Defining Access Control 61

2Contents
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Contents
Defining MAC Based ACL 61
Defining IP Based ACL 63
Defining ACL Binding 70
Defining DOS Prevention 71
Global Settings 71
Defining Martian Addresses 73
Chapter 5: Configuring Device Interfaces . . . . . . . . . . . . . 75
Defining Port Settings 75
Defining LAG Management 80
Defining LAG Settings 82
Configuring LACP 85
Chapter 6: Configuring VLANs . . . . . . . . . . . . . . . . . 89
Defining VLAN Properties 90
Defining VLAN Membership 92
Defining Interface Settings 94
Configuring GVRP Settings 97
Protocol Group 100
Protocol Port 102
Chapter 7: Configuring IP Information . . . . . . . . . . . . . .105
Domain Name System 106
Defining DNS Server 106
Host Mapping 108
Configuring Layer 2 110
Configuring IP Addressing: 110
IP Interface 110
ARP 111
Configuring Layer 3 115
Configuring IP Addressing 115
IP Interface 115
ARP Proxy 118
UDP Relay 119
DHCP Relay 122
ARP 123
Defining IP Routing 126
Chapter 8: Defining Address Tables . . . . . . . . . . . . . . .129
Defining Static Addresses 130
Defining Dynamic Addresses 132
Chapter 9: Configuring Multicast Forwarding . . . . . . . . . . .135
IGMP Snooping 135
Defining Multicast Bridging Groups 138
Defining Multicast Forwarding 141

3
Contents
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Contents
Chapter 10: Configuring Spanning Tree . . . . . . . . . . . . . 143
Defining STP on Interfaces 144
Defining Interface Settings 146
Defining Rapid Spanning Tree 150
Defining Multiple Spanning Tree 154
Defining MSTP Properties 155
Instance to VLAN 156
Instance Settings 156
Interface Settings 157
Chapter 11: Configuring SNMP . . . . . . . . . . . . . . . . 163
SNMP v1 and v2 163
SNMP v3 163
Configuring SNMP Security 164
Defining Engine ID 164
Defining SNMP Views 165
Defining SNMP Users 167
Define SNMP Groups 169
Defining SNMP Communities 171
Defining Trap Management 175
Defining Trap Settings 175
Configuring Station Management 176
Defining SNMP Filter Settings 182
Chapter 12: Configuring Quality of Service . . . . . . . . . . . 185
Defining General Settings 186
Defining CoS 187
Defining Queue 188
Mapping CoS to Queue 190
Mapping DSCP to Queue 191
Configuring Bandwidth 191
Defining Advanced Mode 194
Configuring DSCP Mapping 194
Defining Class Mapping 195
Defining Aggregate Policer 197
Configuring Policy Table 200
Defining Policy Binding 203
Defining QoS Basic Mode 205
Chapter 13: Managing System Files . . . . . . . . . . . . . . 207
File Management Overview 207
Firmware Upgrade 208
Save Configuration 209
Copy Files 210
Active Image 211

4Contents
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Contents
Chapter 14: Managing System Logs . . . . . . . . . . . . . . .213
Enabling System Logs 213
Viewing the Device Memory Logs 215
Clearing Message Logs 215
Viewing the Flash Logs 216
Clearing Message Logs 216
Viewing Remote Logs 217
Chapter 15: Configuring System Time . . . . . . . . . . . . . .221
Defining System Time 222
Defining SNTP Settings 224
Defining SNTP Authentication 226
Chapter 16: Viewing Statistics . . . . . . . . . . . . . . . . . .229
Viewing Ethernet Statistics 229
Defining Ethernet Interface 229
Resetting Interface Statistics Counters 231
Viewing Etherlike Statistics 231
Resetting Etherlike Statistics Counters 233
Viewing GVRP Statistics 233
Resetting GVRP Statistics Counters 235
Viewing EAP Statistics 235
Managing RMON Statistics 238
Viewing RMON Statistics 239
Resetting RMON Statistics Counters 240
Configuring RMON History 241
Defining RMON History Control 241
Viewing the RMON History Table 244
Configuring RMON Events 245
Defining RMON Events Control 245
Viewing the RMON Events Logs 248
Defining RMON Alarms 249
Chapter 17: Managing Device Diagnostics . . . . . . . . . . . . .255
Viewing Integrated Cable Tests 255
Performing Optical Tests 257
Configuring Port Mirroring 258
Defining CPU Utilization 261
Appendix A: Linksys One Contact Information . . . . . . . . . . .263

1
Chapter 1:
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Chapter 1
Getting Started
This section provides an introduction to the user interface, and includes the following topics:
• Starting the Application
•Understanding the Interface
• Using the Linksys Management Buttons
• Using Screen and Table Options
• Resetting the Device
• Logging Off The Device
Starting the Application
This section contains information for starting the Linksys User Interface.
Note By default, the IP address of the device is assigned dynamically. The IP address can be changed.
It is recommended to configure the IP address statically, if the system is in stack mode, in order to
prevent the user from disconnecting from the network in the event of master switchover.
To open the User Interface:
1. Open a web browser.
2. Enter the device’s IP address in the address bar and press Enter. An Appendix 1, "Enter Network
Password Page" opens:

2Chapter 1:
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Chapter
1
Enter Network Password Page
3. Enter a user name and password. The default user name is "admin". The device is not configured
with a default password, and can be configured without entering a password. Passwords are both
case sensitive and alpha-numeric.
4. Click Login The Embedded Web System Home Page opens:
Note If you have logged in automatically via the Service Router user interface, the Tree and Device
views appear and allow you to navigate through the various areas of the web interface. However,
the following page will appear within the frame provided by the Service Router user interface.

3
Chapter 1:
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Chapter 1
Embedded Web System Home Page

4Chapter 1:
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Chapter
1
Understanding the Interface
The following table lists the interface components with their corresponding numbers:
Interface Components
Linksys User Interface Components
Component Description
1 Tree View The Tree View provides easy navigation through the configurable device
features.The main branches expand to provide the subfeatures.
2 Device View The device view provides information about device ports, current
configuration and status, table information, and feature components.The
device view also displays other device information and dialog boxes for
configuring parameters.
3 Table Area The Table area enables navigating through the different device features.
Click the tabs to view all the components under a specific feature.
4 EWS Information The EWS information tabs provide access to the online help, contains
information about the EWS.

5
Chapter 1:
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Chapter 1
This section provides the following additional information:
•Device Representation — Provides an explanation of the Linksys user interface buttons, including both
management buttons and task icons.
•Using the Linksys Management Buttons — Provides instructions for adding, modifying, and deleting device
parameters.
Device Representation
The Linksys home page displays a graphical representation of the device:
Device Representation
The Linksys home page contains a graphical SFE2000 and SFE2000P front panel illustration.

6Chapter 1:
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Chapter
1
Using the Linksys Management Buttons
Device Management buttons and icons provide an easy method of configuring device information, and
include the following:
Device Management Buttons
Button Name Button Description
Apply Applies changes to the device.
Clear All Counters Clears statistic counters
Clear Logs Clears log files
Add Opens an Add page
Delete Removes entries from tables
Reset the settings of
Selected Port to
Default
Resets the settlings of a selected port
to the default settings
Test Now Performs cable tests.

7
Chapter 1:
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Chapter 1
Using Screen and Table Options
Linksys contains screens and tables for configuring devices. This section contains the following topics:
•Appendix 1, "Adding Device Information"
• Appendix 1, "Modifying Device Information"
• Appendix 1, "Deleting Device Information"
Adding Device Information
User defined information can be added to specific EWS pages, by opening a new Add page. To add
information to tables or EWS pages:
1. Open an EWS page.
2. Click the Add button. An add page opens, for example, the Add SNTP Server Page:
Add SNTP Server
3. Define the fields.
4. Click Apply. The configuration information is saved, and the device is updated.
Modifying Device Information
1. Open the EWS page.
2. Select a table entry.
3. Click the Edit Button. A Modify page opens, for example, the Interface priority Page opens:

8Chapter 1:
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Chapter
1
Edit Interface Priority
4. Define the fields.
5. Click Apply. The fields are modified, and the information is saved to the device.
Deleting Device Information
1. Open the EWS page.
2. Select a table row.
3. Check the Remove checkbox.
4. Click the Delete button. The information is deleted, and the device is updated.

9
Chapter 1:
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Chapter 1
Resetting the Device
The Reset page enables the device to be reset from a remote location. Save all changes to the Running
Configuration file before resetting the device. This prevents the current device configuration from being
lost. To reset the device:
1. Click System > General > Reset. The Reset page opens.
Reset Page
2. Click the Reset button. Each unit can be reset individually. Resetting the stack master results in
resetting the entire stack. If the master unit is reset, the device is reset, and a prompt for a user name
and password is displayed.
3. Enter a user name and password to reconnect to the Web Interface, if the stack is not part of a full
Linksys One system. If the stack is part of a Linksys One system, login is automatically done from
the Service Router.
Logging Off The Device
1. Click . The system logs off. The Embedded Web System Home Page closes.

10 Chapter 1:
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Chapter
1

11
Chapter 2:
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Chapter 2
Managing Device Information
This section provides information for defining both basic and advanced system information. This section
contains the following topics:
• Understanding the Device Zoom View
• Defining General System Information
• Managing Stacks

12 Chapter 2:
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Chapter
2
Understanding the Device Zoom View
The Zoom Page is the main window used for viewing the devices either in stand-alone mode or operating
in a stack. To open the Zoom Page:
1. Click the System > System Management > Zoom. The Zoom Page opens:
Zoom Page
The Zoom Page contains the following port indicators:
•Green — Indicates the port is currently operating.
•Red — indicates the port is not currently operating.

13
Chapter 2:
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Chapter 2
Defining General System Information
SFE 2000P System Information
The System Information page contains parameters for configuring general device information.
SFE 2000P System Information Page
The System Information page contains the following fields:
•Model Name — Displays the user defined user name.
•System Name — Displays the user configured name of the system. Configured in the Network page.
•System Location — Defines the location where the system is currently running. The field range is
up-to 0-160 Characters.
•System Contact — Defines the name of the contact person.The field range is up to 0-160
Characters.
•System Object ID— Displays the vendor’s authoritative identification of the network management
subsystem contained in the entity.
•System Up Time — Displays the amount of time that has elapsed since the last device reset. The
system time is displayed in the following format: Days, Hours, Minutes and Seconds. For example:
41 days, 2 hours, 22 minutes and 15 seconds.

14 Chapter 2:
SFE2000/SFE2000P Gigabit Ethernet Switch Reference Guide
Chapter
2
•Base MAC Address — Displays the device MAC address. If the system is in stack mode, the Base
MAC Address of the master unit is displayed.
•Hardware Version — Displays the hardware version number. If the system is in stack mode, the
hardware version of the master unit is displayed.
•Software Version — Displays the software version number. If the system is in stack mode, the
version of the master unit is displayed.
•Boot Version — Indicates the system boot version currently running on the device. If the system is
in stack mode, the version of the master unit is displayed.
•Switch Operation Mode After Reset — Indicates the mode the device operates in after the system
is reset. The possible field values are:
– Standalone — Indicates the device operates as a Standalone device after the system is reset.
–Stack — Indicates the device operates as a Stacked unit after the system is reset.
2. Define the relevant fields.
3. Click Apply. The system information is defined, and the device is updated.
Managing Stacks
The Stack Management Page allows network managers to either reset the entire stack or a specific
device. Device configuration changes that are not saved before the device is reset are not saved. If the
Stack Master is reset, the entire stack is reset. To open the Stack Management Page:
1. Click System > System Management > Stack Management. The Stack Management Page opens:
