PRODUCT DATA
BUSINESS SERIES
24-Port 10/100/1000 +
2-Port MiniGBIC Gigabit
Switch with WebView
Model: SRW2024 v1.1
Secure, reliable, intelligent, managed
gigabit switching for your growing
business
Growing businesses require cost effective, networking solutions that can scale
with ever changing business needs.The Linksys SRW2024 Switch with WebView
brings gigabit speeds to your users and servers, while adding a whole new level of
intelligence and security to the network infrastructure.The 24 10/100/1000 Mbps ports
enable you to take advantage of the Gigabit Ethernet interfaces shipping on the current
generation of servers, workstations and storage devices in addition to supporting your
existing 10/100 Mbps clients.The optional gigabit optical interfaces allow you to expand
the network as your business grows.
Network security is a top priority in any size business. Unauthorized access to the network
and mission critical data is a constant concern.The SRW2024 is able to secure the network
through 802.1X port authentication. 802.1X requires clients to authenticate themselves
before the port will pass data.
Businesses are recognizing the benefits of doing Voice over IP (VoIP) and are quickly
migrating their voice services to IP based platforms, requiring their local area networks to
support both voice and data applications. In unmanaged IP networks, bursty data sessions can
disrupt voice packet delivery, causing poor voice quality.With the enhanced QoS and traffic
management features in the SRW2024, voice data can be prioritized, ensuring clear and reliable
voice communications.
Enabling the SRW2024 advanced features further secures the integrity of your network.The
WebView interface provides an intuitive, secure management interface enabling you to better
utilize the comprehensive feature-set of the switch, resulting in a better optimized, more secure
network.
Brings gigabit speeds to
your network, addressing
the needs of power users
and high bandwidth
applications
Increases network security,
secure user control via
802.1X port authentication
Enables the network to
be optimized for your
networked applications,
including voice, video and
data storage
Provides intelligent traffic
management with rate
limiting, policing, shaping,
and multicast support
SRW2024

PRODUCT DATA
BUSINESS SERIES
Features
24 10/100/1000 Gigabit
Ethernet ports
2 MiniGBIC slots for fiber
Gigabit Ethernet expansion
Non-blocking,
store-and-forward switching
mechanism
Simplified QoS management
enabled by advanced
queuing techniques using
802.1p, Diffserv or ToS traffic
prioritization specifications
Configuration and
monitoring from a standard
web browser with WebView
management
Secure remote management
of the switch via SSH and
SSL secure channel network
protocols
802.1Q based VLANs enable
segmentation of networks
for improved performance
and security
Private VLAN Edge for
simplified network isolation
for guests connections or
autonomous networks
Automatic configuration
of VLANs across multiple
switches through
GVRP/GARP
Automatic port
configuration through auto
MDI/MDIX and 802.1ab
(LLDP)
User/Network port
level security via 802.1X
authentication and
MAC-based filtering
•
•
•
•
•
•
•
•
•
•
•
24-Port 10/100/1000 + 2-Port MiniGBIC
Gigabit Switch with WebView
Specifications
Model SRW2024 - 24-Port 10/100/1000 Gigabit Switch with WebView
Standards IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1p, 802.1q
Ports 24 10/100/1000 RJ-45 ports and 2 shared MiniGBIC slots
Cabling Type Cat5e or better
LEDs System, Link/Activity, Gigabit
Performance
Switching Capacity 48 Gbps, non-blocking
MAC table size 8K
Number of VLANs 256 VLANs
Management
Web User Interface Built-in Web UI for easy browser-based configuration (HTTP/HTTPS)
SNMP SNMP version v1, v2c, v3 with support for traps
SNMP MIBs RFC1213 MIB-2, RFC2863 Interface MIB, RFC2665 Ether-like MIB,
RFC1493 Bridge MIB, RFC2674 Extended Bridge MIB (P-bridge, Q-bridge),
RFC2819 RMON MIB (groups 1,2,3,9 only), RFC 2618 RADIUS Client MIB
RMON Embedded Remote Monitoring (RMON) software agent
supports four RMON groups (history, statistics, alarms, and events)
for enhanced traffic management, monitoring, and analysis
Firmware Upgrade Web Browser upgrade (HTTP)
TFTP upgrade
Port Mirroring Traffic on a port can be mirrored to another port for analysis
with a network analyzer or RMON probe
Other Management RFC854 Telnet (Menu-driven configuration)
Secure Shell (SSH) and Telnet Management
RADIUS
TACACS+
Telnet client
SSL security for Web UI
Switch audit log
DHCP client
BootP
SNTP
Xmodem upgrade
Cable diagnostics
PING
Traceroute
Syslog
Security Features
IEEE 802.1X 802.1X - RADIUS Authentication. MD5 Encryption
Access Control MAC based ACL
Availability
Link Aggregation Link Aggregation using IEEE 802.3ad LACP
Up to 8 ports in up to 8 trunks
Storm Control Broadcast, Multicast, and Unknown Unicast
Spanning Tree IEEE 802.1d Spanning Tree, IEEE 802.1s Multiple Spanning Tree,
IEEE 802.1w Rapid Spanning Tree, Fast Linkover
IGMP Snooping IGMP (v1/v2) snooping provides for fast client joins and leaves of
multicast streams and limits bandwidth-intensive video traffic to
only the requestors.
QoS
Priority levels 4 Hardware queues
Scheduling Priority Queueing and Weighted Round Robin (WRR)
Class of Service Port-based
802.1p VLAN priority based
IP ToS/ IP Precedence based CoS
IPv6 Traffic Class based CoS
Diffserv

PRODUCT DATA
BUSINESS SERIES
Linksys
A Division of Cisco Systems, Inc.
121 Theory
Irvine, CA 92617 USA
E-mail: [email protected]
[email protected]
Web: http://www.linksys.com
Linksys products are available in more
than 50 countries, supported by
12 Linksys Regional Offices throughout
the world.For a complete list of local
Linksys Sales and Technical Support
contacts, visit our Worldwide Web Site
at www.linksys.com.
Increased the bandwidth
(up to 8x) and added link
redundancy with Link
Aggregation Control
Protocol (LACP)
Enhanced rate limiting
capabilities and storm
control, including multicast,
broadcast and flood control
Port mirroring for
non-invasive monitoring of
switch traffic
Jumbo frame support (10KB)
SNMP v1, v2c, v3 and RMON
support
Fully rack-mountable using
the included rack-mounting
hardware
•
•
•
•
•
•
Check the product package and contents for specific features supported.Specifications are subject to change without notice. Linksys is a registered trademark or
trademark of Cisco Systems, Inc.and/or its affiliates in the U.S. and certain other countries. Copyright © 2006 Cisco Systems, Inc. All rights reserved. Other brands and
product names are trademarks or registered trademarks of their respective holders.
Model: SRW2024
Layer 2
VLAN Port-based and 802.1q based VLANs
Private VLAN Edge (PVE)
Management VLAN
HOL Blocking Head of line blocking prevention
Jumbo frame Supports frames up to 10K byte frames
Dynamic VLAN GVRP - Dynamic VLAN Registration
Standards 802.3i 10BASE-T Ethernet, 802.3u 100BASE-TX Fast Ethernet,
802.3ab 1000BASE-T Gigabit Ethernet, 802.3z Gigabit Ethernet,
802.3x Flow Control
Environmental
Dimensions 16.93" x 1.75" x 13.78"
W x H x D (430 x 45 x 350 mm)
Unit Weight 7.3 lb (3.311 kg)
Power 100-240V 0.5A
Certification FCC Part15 Class A, CE Class A, UL, cUL, CE mark, CB
Operating Temperature 32 to 104ºF (0 to 40ºC)
Storage Temperature -40 to 158ºF (-40 to 70ºC)
Operating Humidity 20 to 95% relative humidity, noncondensing
Storage Humidity 5 to 90% noncondensing
Package Contents
SRW2024 - 24-Port 10/100/1000 Gigabit Switch with WebView
AC Power Cord
Rack Mounting Kit with Brackets and Hardware
CD with User Guide in PDF Format
Registration Card
Console Cable
Minimum Requirements
Web-Based Utility: Web Browser - Microsoft Internet Explorer (Version 5.5 or Above)
Cat5 Ethernet Network Cables
Operating System: Windows 2000, XP or Above
Warranty
5 Years
•
•
•
•
•
•
•
•
•
•
