Lionel Pennsylvania S-2 User manual

71-8068-250 6/99
®
featuring and
Pennsylvania
S-2 Steam Turbine Tender
O ner’s Manual
I
N
S
T
R
U
C
T
I
O
N
S
H
E
E
T

2
2
Table of contents
Transformer operations
Running your Lionel S-2 & Pennsy tender ith a Lionel transformer 3
Using your S-2 & Pennsy tender’s tender mounted ElectroCoupler™ 4
Your S-2 & Pennsy tender’s RailSounds system—the basics 5
Experiencing the range of your S-2 & Pennsy tender’s Railsounds system 6
Notes on Railsounds 6
TrainMaster Command operations
Your S-2 & Pennsy tender in the TrainMaster Command environment 7
Cab-1 commands for your S-2 & Pennsy tender 8
Railsounds in the Command environment 9
CAB-1 numeric keypad commands for your S-2 & Pennsy tender 9
Tuning your S-2 & Pennsy tender’s performance 10
Assigning your S-2 & Pennsy tender a ne ID# 10
Maintaining and servicing your S-2 & Pennsy tender
Replacing your Pennsy tender ’s rear light 11
Lionel Service 12
Congratulations!
Congratulations on your purchase of
Lionel’s Pennsylvania Tender. You
now have the option of running your
Century Club S-2 Stea Turbine engine
with either the original 1946 Lionel
Lines version of the tender which ca e
with your engine, or this Pennsylvania
style tender which was introduced
with the 1948 671Turbine. While the
size of this tender is true to the 1948
version, uch else is new, starting with
all new die cast tooling for the tender
body and fra e in order to provide the
finest surface finish. We have added
separate etal ladder and handrail
details. We have used the latest ver-
sions of our six wheel trucks and added
a die cast water scoop. Your tender has
directional lighting as well as two
green arkers that glow when the
engine is in reverse. And of course, you
have Lionel’s uncouple anywhere
ElectroCoupler on the back of the ten-
der as well as newly ixed Railsounds
recordings and TowerCo announce-
ent when used in conjunction with
your Co and Equipped S-2 Turbine
Engine. The gold printed indicia on the
back of the tender shows that this is a
genuine Century Club product. Enjoy
odel railroading at its finest with
Lionel Trains.
• Die-cast Electrocoupler™
(rear of tender)
• RailsoundsTM steam sound
system—digital samples from
a real steam locomotive
• Brilliant reverse and mar er
lights
• CrewTal ™and TowerCom™
(in command mode)

2
2
• Your S-2 and Tender are designed to operate on 8-18 volts alternat-
ing current. Virtually all Lionel and Lionel-co patible alternating-
current transfor ers are suitable; we reco end the TrainMaster
Co and odel railroad control syste .
• DO NOT POWER W TH D RECT CURRENT (DC). Da age to sensitive
electronic co ponents ay occur.
• When you first power up your track, the S-2 will wait between 3
and 8 seconds as it “listens” for digital language fro the
TrainMaster Co and Base (available separately). When it’s
deter ined that it’s on a conventional (nonCo and) railroad,
the S-2’s headlight will illu inate and Railsounds will fire up. At
this point, the S-2 is in neutral. (This occurs when placing the S-2
on your railroad for the first ti e. Thereafter, it starts in forward
after every three-second power interrupt.)
Note!
3
3Move ‘em out!
• Get your S-2 and tender moving. Press the DIR button on your
CAB-1 re ote or Lionel transfor er. This sequences the Liontech
Co and reverse unit (LCRU2) to the next operating state.
• Adjust track voltage until your S-2 oves at your desired speed.
For ore infor ation on engine operation see the owners anual
that ca e with your S-2 Stea Turbine ( part no. 71-8057-250). 3
3
Transformer operations
Place your S-2 and Pennsylvania Tender on Lionel
or Lionel-compatible O gauge track.
• With track power OFF, connect the loco otive tether between the
engine and tender. The six-pin tender plug connects with the six-
pin receptacle on the loco otive. Connect the drawbar between
loco otive and tender.
1
1
Running your Engine & Tender ith a Lionel transformer
• The engine tether receptical is “keyed” to allow the harness to be
plugged in only one way.
Note!
Po er up your S-2 and tender ith your transformer.

4
4
Using your tender’s Electrocoupler in the non-Command environment
To use your tender’s Electrocoupler
in the non-Co and environ ent,
you ust first couple a piece of rolling
stock equipped with Lionel agnetic
couplers directly to your tender’s rear
ElectroCoupler. The agnetic coupler
on the rolling stock will then react to the
agnetic field generated by a Lionel
re ote-control track section (available
separately). Place your rolling stock’s
coupler “trigger disc” over the central
coil of a re ote-control track section
and press uncouple on the controller.
The agnetic field pulls the disc down-
ward, and the coupler opens.
Your tender’s Electrocoupler will NOT open manually
or by using a remote-control track section
Magnetic coupler on the rolling stock cou-
pled to the rear of your S-2 tender
Note!
Re ote-control track section
Your Lionel tender is equipped with
a rear Electrocoupler that responds
to the COUPLER R (rear) button on your
CAB-1 re ote when operated in the
Train aster Co and environ ent.
Si ply press R button on your CAB-1
re ote, and the coupler opens.
Your tender’s
Electrocoupler is NOT
designed to be opened
manually.
Note!
Using your tender’s Electrocoupler in the TrainMaster Command environment

Although Railsounds is
powered by track voltage, the
battery is required for uninter-
rupted operation and shut-
down sequences. Use only
alkaline batteries.
Note!
Your Railsounds system—the basics
Lionel Railsounds is the ost realis-
tic odel railroad sound syste in
the world. Your Pennsylvania Tender
features digital sa ples fro real-life
stea loco otives for the ultimate in
realis .
Begin by installing a 9-volt alkaline bat-
tery in the tender. This ensures interrup-
tion free operation of Railsounds. The
battery is located within the tender and
to access it you will need to re ove the
tender body fro the fra e. Begin by
turning the tender over and re oving
one screw fro each corner of the fra e.
Turn the tender over and re ove the
tender body fro the fra e asse bly.
Snap the battery clip onto the battery
and place it into the rear of the tender
where the built in retainer will hold it in
place. Place the tender body back over
the fra e asse bly, aking sure that
none of the wires are pinched between
the fra e and the body. Turn the tender
back over and secure together with the
four previously re oved screws.
When you first apply track power, the
tenders Railsounds syste produces
sounds of the loco otive at rest. As the
tender oves, turbine “woosh” begins,
increasing with the loco otive’s speed.
To silence the turbine “woosh” (whis-
tle/bell are unaffected), slide the
Railsounds switch, located on the bot-
to of the tender, to the OFF position
be ore powering up the locomotive. The
whistle is activated by using the lever or
button on your transfor er or CAB-1.
The volu e control knob to raise or
lower the level of sound is located on the
botto of the tender.
Installing a 9-volt alkaline battery in your
S-2's tender.
Transformer operations
Discontinue loco otive
power or 10 seconds before
changing the Railsounds
ON/OFF switch position.
Note!
If Railsounds “drops out”
during track power inter-
rupts (direction change),
replace the battery.
Note!
5
5

6
6
With Railsounds, you experience the
sounds of real railroading like
never before. Si ply put, it’s the ost
sophisticated, authentic odel railroad
sound syste in the world. And re e -
ber—inside your Lionel S-2 are the
sounds of real-life stea engines. No
other electric train can offer you authentic
S-2 sounds. That’s the power of Lionel.
• Turbine “Woosh”. Your S-2 ’s track
speed deter ines the speed of the
“Woosh”.
• MultiWhistleTM. Different whistles every
ti e—a Railsounds exclusive.
• Authentic bell. Press BELL on your
CAB-1 or transfor er to begin the effect,
again to discontinue. Even the final “hit”
is uted like the real thing.
• Reverse unit reset sound. Power down
your track, wait for 3.5 seconds, and listen
for the air-release sound—that’s the S-2
telling you its Liontech Co and reverse
unit has just reset to orward operation.
• Shutdown sequence. No other odel
railroad sound syste shuts down like
Railsounds. Turn off track power, and
after the air-release reset sound, you have
two seconds to restart your S-2 . If you’re
done with operations, Railsounds will
co ence with an authentic S-2 shut-
down sequence about two seconds after
the air-release reset occurs.
Experiencing the range of your S-2’s Railsounds system
Notes on Railsounds
• Use the volu e control dial, located
on the botto of the tender, to adjust
sound output .
• Listen for incidental engine sounds
during Railsounds operation. They’re
auto atic and, of course, authentic.
• The 9-volt alkaline battery you
installed ensures continuous sounds,
even during short track-power inter-
rupts.
• Longer track-power interruptions
(including loco otive derail ents)
cause Railsounds to shut down after
about 7 seconds.
• For even more authentic Railsounds
effects, operate your S-2 in the
TrainMaster Co and environ ent.
See page 7 for details.
A stea turbine loco otive, unlike a conventional stea engine, akes a con-
tinuous “whoosh” sound when it’s operating, rather than a ryth ic chuffing.
Note!
Transformer operations

7
7
TrainMaster Command operations
Your S-2 in the TrainMaster Command environment
Lionel TrainMaster Co and is the
fun and sophisticated odel rail-
road control syste fro Lionel. Your
S-2 features the Liontech Co and
reverse unit, which acts as both a con-
ventional reverse unit as well as the key
to unlocking any extra features when
you operate in Co and ode.
TrainMaster Co and gives you the
power to operate ultiple Co and-
equipped loco otives on the same track,
at the same time. It’s the ost fun you
can have with electric trains, and it’s
incredibly easy too! Just follow the
directions below and you’ll be on your
way.
TO OPERATE N COMMAND, YOU NEED A
COMMAND BASE AND A CAB-1 REMOTE.
Find the both at your authorized
Lionel retailer.
Place your S-2 on Lionel or Lionel-compatible
O gauge track.
• Make sure track power is OFF before placing it on track.
• Make sure your Lionel Command Base is ON and its co uni-
cations wire is connected to the COMMON post on your Lionel
transfor er or the U on any of your installed PowerMasters.
• Once positioned on the track, increase track voltage to FULL (on
PowerMaster, slide the CMD/CONV switch to CMD).
2
2Address your S-2 ith CAB-1.
• Press ENG and 1 on the nu eric keypad of your CAB-1 re ote.
This co and is sent by CAB-1 to the Co and Base, which then
translates your co and into digital code. That code is sent
around your railroad’s outside rails in the for of a digital “halo.”
All Co and-equipped Lionels listen to this digital co unica-
tion, but they do not respond until they hear their own ID nu ber.
• The digital language of TrainMaster Co and—and not track
power—controls the actions of Co and-equipped Lionels. Track
power is si ply like gasoline in the tank of your car—it gives you
the power to go places, but it doesn’t tell you where to go or how
fast to get there.
• All Command-equipped Lionels come factory-programmed with
an D# of “1.” To change your S-2’s ID#, see page 10 .
3
3Move ‘em out!
• Throttle up or press any co and button on CAB-1. Your S-2 will
respond to your every co and. Read on. The fun is just beginning!
1
1

8
8
Press AUX2 to turn
your S-2's headlight
on and off.
Press HALT to shut
down all PowerMaster
electrical output on
your railroad. Stops all
Co and-equipped
Lionels in operation.
Turn the THROTTLE
to the right to acceler-
ate, left to decelerate.
SPEED-DEPENDENT
TURBINE “WOOSH”
CAB-1 commands for your S-2
S-2 RAILSOUNDS EFFECTS
IN BOLD ITALIC
TrainMaster Command operations
Rear coupler releases.
COUPLER RELEASE
SOUNDS.
Press WSTL/HRN to
activate the S-2’s whistle,
release to discontinue.
MULTI-WHISTLE STEAM WHISTLE
SOUND.
Press DIR—the loco otive
decelerates to a co plete
stop; turn the throttle up,
and the loco otive oves
in the opposite direction.
THERE IS NO NEUTRAL. STEAM
AIR-RELEASE SOUND.
Press BELL once to activate
the bell, again to discontin-
ue. TRADITIONAL BELL SOUND.
Press and hold BOOST for
extra power. Release BOOST
and return to the S-2’s previ-
ous speed.
Press and hold BRAKE to
slow down or stop. Re-lease
BRAKE and return to the pre-
vious speed.
SQUEALING BRAKE SOUNDS.
Running your S-2 in the TrainMaster Command environment
Your Co and-equipped S-2
co es factory-progra ed with
an ID# of “1.” To get your S-2 in
action, set PowerMasters to CMD or
set all power supplies on full. Press
ENG and “1” on CAB-1. Turn the
throttle or press any co and button;
Railsounds starts up. Your S-2 is
ready for Co and operations.
address Locomotive
#1
Po erMasters set to CMD or traditional
po er supplies ON FULL
Press ENG
Press 1 (the ID#)
Example

9
9
When you press AUX1 on CAB-1,
you turn the nu eric key-
pad into 10 co and but-
tons. The keypad “stays open”
and gives you access to extra
co and features until you
press any top-row button
(SW, ACC, RTE, TR, or ENG). The
CAB-1 keypad overlay included
with your S-2 is designed to
help you learn the auxiliary
features specific to this classic
loco otive.
S-2 RAILSOUNDS EFFECTS IN BOLD
CAB-1 numeric keypad commands for your S-2
STEAM ENGINE
RESET
VOLUME
SMOKE
➠
BLOW
OFF
SHUT
DOWN
OFF ON
STEAM
RELEASE
PRESS
& HOLD
SMOKE
BOOST
➠
START-UP
CREW
TALK
TOWER
COM
0Stops and resets the S-2 to
FORWARD. WHISTLE BLOWS. HEADLIGHT
FLICKERS.
1Raises the volu e of Railsounds.
SOUND VOLUME INCREASES.
2CrewTalk™ is the sound of unintelligi-
ble walkie-talkie co unication.
3Starts up Railsounds. STARTUP SEQUENCE
COMMENCES. STEAM BLOWOFF SOUND.
4Lowers the volu e of Rail- sounds.
SOUND VOLUME DECREASES.
5Activates the Railsounds stea
shutdown sequence. Just like the
real thing, your S-2 must be idle or shut-
down to occur. STEAM SHUTDOWN COMMENCES.
Re e ber, the whistle and bell will
not sound until you restart Railsounds.
6STEAM RELEASE SOUND.
7TowerCo ™is an audible announce-
ent that includes that engine’s road
nu ber and/or na e. There is a our sec-
ond delay in this unction.
8Turns off the s oke generator.
9Turns on the s oke generator.
Press and hold 9 (10 seconds axi-
u ) to initiate S oke Boost™—it super-
heats the s oke generator and enhances
s oke output when you start running
your S-2.
Railsounds in the Command environment
Your S-2’s Railsounds syste gives
you even more in the TrainMaster
Co and environ ent.
• Bonus sounds like squealing brakes
with the CAB-1 BRAKE co and.
• ncidental sounds you control with
CAB-1 nu eric keypad co ands, like
stea letoff and stea release effects.

10
10
Tuning your S-2’s performance
SOUND QUALITY
To achieve your preferred Rail-
sounds aster volu e level, use the
volu e control dial located on the
botto of the tender. Turn the dial left
or right to adjust the volu e to your
liking.
For quick re ote-control of volu e
below the aster setting—like ut-
ing—use the CAB-1 nu eric keypad’s
volu e control. Pressing AUX1 and
then 4 on the nu eric keypad lowers
overall Railsounds output.
TrainMaster Command operations
As your fleet of Co and-equipped
Lionels grows, give your S-2 loco-
otive its own ID#. Choose fro any
between 1 and 99. Turn the Co and
Base ONand place the loco otive on
track. Power up, then slide the loco o-
tive’s reverse unit control switch to PRO-
GRAM.
Using CAB-1, press ENG, the loco o-
tive ID#, then press the SET button locat-
ed under CAB-1’s re ovable panel. See
the loco otive’s headlight flash; that’s
your signal that the progra ing has
been accepted. Slide the control switch to
RUN.
Assign a ne I D# to your
Command-equipped locomo-
tive
Command Base ON
Place the locomotive on trac
PowerMasters set to CMD or
traditional power supplies ON FULL
Set the locomotive reverse unit control
switch to PROGRAM
Turn trac power on (PowerMasters):
Press BOOST
Program the locomotive with a new ID#:
Press ENG
Press a number you choose
(the ID#)
Press SET
Set reverse unit control switch to
FORWARD/RUN (see pg.4 for location)
Your locomotive remembers its ID# forever;
We reco end that you choose an
easy to re e ber ID# for your
engine. So e possibilities are part of
the engine road nu ber, your age,
any two digit nu ber that is not used
by another engine. If you like write
the nu ber on a s all piece of tape
and put this on the botto of the
fra e to aid in re e bering.
Assigning your locomotive a ne ID#
Example

11
11
Reprogramming LCRU circuit boards to restore features
STEP 1: Move switch on loco otive fro
run to progra .
STEP 2: Turn on Co and Base.
STEP 3: Place loco otive on track, then
turn on power to track.
STEP 4: Press “ENG” then input loco o-
tive’s ID#. Press “SET”
STEP 5: Press “ENG”, then the ID#,
“AUX1”, then press a number closest to
your loco otive type. (see list for engine
types)
STEP 6: Turn off power to track, wait ten
seconds.
STEP 7: Re ove loco otive fro track,
ove switch fro progra to run.
STEP 8: Place loco otive back on track,
turn power on to track.
STEP 9: Press “ENG” and ID#, then oper-
ate as nor al.
PROGRAM CODE FOR OTHER ENGINES
0 = STEAM WITH SIGNAL SOUNDS
1 = DIESEL WITH SIGNAL SOUNDS
2 = DIESEL WITH CAB LIGHT AND SIGNAL
SOUNDS
4 = STEAM WITH SMOKE
5 = DIESEL WITH STROBE LIGHT
6 = DIESEL WITH CAB LIGHT
36 = ALCO PA’S - NEW IN 1997
70 = J1E HUDSON & S.F. WARHORSE (BOTH
LOCO&TENDER MUST BE ON TRACK)
Due to the inevitable derail ents, sta-
tic, and the nature of electricity, it is
possible that your LCRU could so eday
lose its setup progra .The sy pto s of
this condition would be unresponsiveness
in co and ode. This can be easily
re edied by “reprogra ing” your
LCRU using the following steps
S2 Turbine
Your S2 ‘s tender is illu inated by a 14-
volt la p located inside the rear of the
tender. During the course of nor al opera-
tion, this la p ay require replace ent.
To replace an expired la p, turn the
Tender over and re ove the four ounting
screws. Carefully lift the chassis asse bly
out of the tender shell. Pull the la p and
connector asse bly out of its location in the
rear of the tender shell.
Re ove the expired la p fro the con-
nector and replace it with Lionel part no.
610-8049-300. Make sure that the la p
leads are fully seated in the connector and
reposition the la p asse bly in the tender
shell. Place the chassis asse bly back into
the tender shell, aking sure that the wires
do not get caught between the chassis and
body shell.
Secure the chassis to the body shell by
reinserting the four ounting screws.
Replacing your S2 tender’s rear lamp
Lionel part no.
610-8049-300

Limited Warranty/Lionel Service
© 1999 LIONEL LLC, CHESTERFIELD MI 48051-2493
UNITED STATES OF AMERICA
This Lionel product including all echanical and electrical co ponents, oving parts,
otors and structural co ponents, except for light
bulbs, is warranted to the original consu er-pur-
chaser, for 5 years against original defects in ate-
rials or work anship when purchased through an
authorized Lionel erchant.
This warranty does NOT cover nor al wear
and tear, light bulbs, defects appearing in the
course of co ercial use, or da age resulting
fro abuse or isuse of the product by the pur-
chaser. Transfer of this product by the original
consu er-purchaser to another person voids this
warranty. Modification of this product voids this
warranty.
Any warranted product which is defective in
original aterials or work anship and is deliv-
ered by the original consu er-purchaser to Lionel
L.L.C. or an authorized Lionel L.L.C. service cen-
ter, together
with proof of original purchase, will at the option
of Lionel L.L.C. be repaired or replaced, without
charge for parts or labor. In the event the defective
product cannot be repaired, and a replace ent is
not available, a refund of the original purchase
price will be granted. Any products on which
warranty service is sought ust be sent freight or
postage prepaid, as transportation and shipping
charges are not covered by the warranty.
IN NO EVENT SHALL LIONEL L.L.C. BE LIABLE
FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES.
So e states do not allow the exclusion or li ita-
tion of incidental or consequential da ages, so
the above exclusion ay not apply to you.
This li ited warranty gives you specific legal
rights, and you ay have other rights which vary
fro state to state.
INSTRUCTIONS FOR OBTAINING SERVICE
If service for this Lionel L.L.C. product is required,
bring the ite , along with your dated sales receipt
and co pleted warranty infor ation to the near-
est Authorized Lionel Service Center. Your near-
est Lionel Service Center can be found by calling
1-800-4-Lionel, or by contacting our Website @
www.Lionel.co
If you prefer to send it back to Lionel L.L.C. for
factory repair, you ust first call 810-949-4100 or
FAX [phone] or write to Custo er Service,
P.O. Box 748 New Balti ore, MI 48047-0748 stat-
ing what the ite is, when it was purchased and
what see s to be the proble . You will be sent a
return authorization letter and label to assure
your erchandise will be properly handled upon
receipt.
Once you have received your return authorization
and label, ake sure that the ite is packed to
prevent da age during shipping and handling.
We suggest that you use the products original
packaging. This ship ent ust be prepaid and
we reco end that it be insured.
Please ake sure you have followed all of the
above instructions carefully before returning any
erchandise for service.
You ay choose to have your product repaired by
one of our Authorized Lionel Service Centers after
its warranty has expired. A reasonable service fee
will be charged.
WARRANTY INFORMATION
Please co plete the infor ation below and keep
it, along with your dated sales receipt. You ust
present this and your dated sales receipt when
requesting warranty service.
NAME___________________________________
ADDRESS________________________________
PLACE OF PURCHASE____________________
DATE OF PURCHASE _____________________
PRODUCT NUMBER _____________________
PRODUCT DESCRIPTION
_________________________________________
12
12
