Lippert Components ground control 3.0 User manual

Rev: 08.04.2016 Page 1 Ground Control® 3.0 Owner's Manual
Ground Control 3.0 (5th Wheel)
4 Point and 6 point
OWNER'S MANUAL

Rev: 08.04.2016 Page 2 Ground Control® 3.0 Owner's Manual
System and Safety Information
Failure to act in accordance with the following may result in death or serious
personal injury. The use of the Ground Control 3.0 leveling system to support the
trailer for any reason other than which it is intended is prohibited by Lippert’s
limited warranty. The Lippert leveling system is designed as a “leveling” system
only and should not be used to provide service for any reason under the trailer
such as changing tires or servicing the leveling system. Any attempts to change
tires or perform other service while trailer is supported by the Ground Control
3.0 leveling system could result in death, serious injury or damage to the 5th
wheel.
TABLE OF CONTENTS
System and Safety Information 2
Prior To Operation 3
Touch Pad Diagram 3
Operation 4
Basic Jack Operation 4
Unhitching From A Tow Vehicle 4
Auto Level 5
Auto Level Sequence 5
Hitch Recognition 6
Troubleshooting 6
Manual Override 6
Troubleshooting - Touch Pad 8
Special Jack Error Codes 9
System Settings 9
Zero Point Calibration 9
Preventive Maintenance 10
Ground Control 3.0 OEM Assembly 11
Ground Control 3.0 Components 12 - 15
Moving parts can pinch, crush or cut. Keep clear and use caution.

Rev: 08.04.2016 Page 3 Ground Control® 3.0 Owner's Manual
Prior To Operation
Touch Pad Diagram
The leveling system should only be operated under the following conditions:
1. The trailer is parked on a reasonably level surface.
2. Be sure all persons, pets, and property are clear of the trailer while the leveling system is in operation.
3. Make sure battery(ies) are fully charged and test at 12+VDC under load.
Fig. 1
Callout Description
A Up Arrow - Scrolls up through the menu on LCD.
B Down Arrow - Scrolls down through the menu on LCD.
C Enter - Activates modes and procedures indicated on LCD.
DRetract - Places leveling system into retract mode.
- Press and hold down for 1 second to initiate Auto Retract.
E LCD Display - Displays procedures and results.
F Auto Level - Places leveling system into auto level mode.
G Front Jack Button - Activates front jacks in manual mode.
H Left Jack Button - Activates left jacks in manual mode.
I Right Jack Button - Activates right jacks in manual mode.
J Rear Jack Button - Activates rear jacks in manual mode.
K Power Button - Turns leveling system on and off.
AE
FH
G
B
C
D
J
I
K

Rev: 08.04.2016 Page 4 Ground Control® 3.0 Owner's Manual
Basic Jack Operation
Operation
Unhitching From A Tow Vehicle
Landing gear jacks can be operated any time the system is “ON”. By pushing the “FRONT” button (Fig. 1G), both
front or landing gear jacks can be extended. By pushing either the "FRONT" and “LEFT” (Fig. 1H) or "FRONT" and
“RIGHT” (Fig. 1I) buttons, the individual front jacks can be extended. If the touch pad is put in the retract mode,
indicated by the orange illuminated LED next to the “RETRACT” button (Fig. 1D), the front jacks can be retracted
together by pushing the “FRONT” button (Fig. 1G) or individually by pressing “LEFT” (Fig. 1H) or “RIGHT” (Fig. 1I)
buttons, while simultaneously pressing the “FRONT” button (Fig. 1G).
Middle jacks, if equipped, can not be extended or retracted in standard mode or manual mode. Middle jacks can
only be operated in the special jack code error mode. In order to operate the middle jacks press "LEFT" (FIG. 1H) and
"RIGHT" (FIG. 1I) buttons simultaneously.
The rear jacks can only be extended when the touch pad is in the manual mode. Once system is in manual mode,
pressing the “REAR” button (Fig. 1J) will extend both rear jacks at the same time. To extend individual rear jacks,
press the “LEFT” (Fig. 1H) or “RIGHT” (Fig. 1I) buttons while simultaneously pressing the “REAR” button (Fig. 1J),
depending on which jack needs to be operated. If the touch pad is put in the retract mode, indicated by the orange
illuminated LED next to the “RETRACT” button (Fig. 1D), the rear jacks can be retracted together by pushing the
“REAR” button (Fig. 1J) or individually by pressing either the “LEFT” (Fig. 1H) or “RIGHT” (Fig. 1I) buttons, while
simultaneously pressing the “REAR” button (Fig. 1J).
NOTE: If the rear jacks will not operate individually using the method described above, but they operate
properly when Auto Level is performed, the Twist Prevention Protection system has locked out the
operation to prevent damage to the frame of the trailer.
NOTE: Prior to unhitching from the tow vehicle, ensure the trailer is parked on a level surface and be sure to
chock the tires of the trailer.
1. Extend the inner legs of both landing gear to within 4-5 inches of the ground by pulling on the quick
release pins.
2. Push “ON/OFF” (Fig. 1K). LCD Screen will light up and display “READY JACKS: UP” (Fig. 2A).
3. Push the “UP” arrow (Fig. 1A) to scroll to “Drop Front Jacks” option on LCD screen.
4. Red indicator lights (Fig. 2B) may come on, indicating the current disposition of the trailer. In this case,
the front and right sides of the trailer are low.
5. Push “ENTER” (Fig. 1C). Both front landing gear jacks will go to ground and stop.
6. Push the “FRONT” button (Fig. 1G) extending the front landing gear to a sufficient height, which raises
the front of the trailer off of the tow vehicle’s 5th wheel hitch plate.
7. Pull tow vehicle away and park at a safe distance.
Be sure to park the trailer on solid, level ground. Clear all jack landing locations
of debris and obstructions. Locations should also be free of depressions. When
parking the trailer on extremely soft surfaces, utilize load distribution pads
under each jack. People and pets should be clear of the trailer while operating
leveling system. Never lift the trailer completely off the ground. Lifting the
trailer so the wheels are not touching the ground will create an unstable and
unsafe condition.

Rev: 08.04.2016 Page 5 Ground Control® 3.0 Owner's Manual
Auto Level
1. After unhitching from tow vehicle and parking the tow vehicle at a safe distance away from the trailer,
press the “ON/OFF” button (Fig. 1K) and then press “AUTO LEVEL” (Fig. 1F).
NOTE: Once the automatic leveling cycle has been started, it is important that there is no movement in the
trailer until the trailer has completed the leveling process. Failure to remain still during the leveling
cycle could have an effect on the performance of the leveling system.
NOTE: In order for hitch recognition feature to function, the auto level sequence MUST be started with the
front of the trailer above level.
Auto Level Sequence
1. When Auto Level Sequence begins, the front of the trailer will lower to a point near level.
2. Rear leveling jacks will be grounded.
3. A side to side leveling sequence will occur.
NOTE: At this point on the 6-point system, the two middle jacks will be grounded to stabilize the trailer.
These two jacks do not level the trailer.
4. Each jack will perform a final grounding touch.
5. LCD will read “AUTO LEVEL SUCCESS” (Fig. 3).
6. LCD will then read “READY Jacks: Down” (Fig. 4A), and the green LED at the center of the four jack
buttons will be illuminated (Fig. 4B).
Fig. 2
A
B
Fig. 3 Fig. 4
A
B

Rev: 08.04.2016 Page 6 Ground Control® 3.0 Owner's Manual
Hitch Recognition
1. Turn on the touch pad.
2. Push the “UP” arrow (Fig. 5A) to scroll to
“Auto Reconnect” option on LCD screen.
3. Push "ENTER" (Fig. 5B). All leveling jacks will
retract first, then the landing gear will extend
to raise the trailer to the height where the
auto level sequence was started.
NOTE: If the auto level sequence was started with
the front of the trailer in a below-level
condition, the Hitch Recognition will
not function and the LCD will display
“Feature Disabled.” In order for the Hitch
Recognition feature to function, the auto
level sequence MUST be started with the
front of the trailer above level.
Fig. 5
NOTE: If the AUTO LEVEL sequence does not perform as described, place the system in manual mode and
test that the jacks operate correctly by pushing their coordinating buttons on the touch pad; i.e.
"FRONT" button operates only the front jacks.
Troubleshooting
Manual Override
If manual override is necessary on any jack in the system, there are two options: a port on the top of the jack motor,
and a port on the bottom of the jack motor.
Top of Jack Motor Override:
Tools needed: ⁄” drive ratchet and extension (no socket)
NOTE: Use of a 12V-18V cordless screw gun or pneumatic screw gun is acceptable to manually override the
jacks. Do not use an impact screw gun to perform the override procedure, as this may damage the
motor.
1. Find the port on the top of the jack motor (Fig. 6A).
2. Remove the rubber plug (Fig. 7A).
3. Insert the ⁄” drive into the port (Fig. 8).
4. Turn override until the jack extends or retracts to desired position.
Ensure the trailer is supported at both the front and rear with jack stands before
performing any troubleshooting or service to the trailer. Failure to do so may
result in death or personal injury.
A
B

Rev: 08.04.2016 Page 7 Ground Control® 3.0 Owner's Manual
Fig. 6 Fig. 7 Fig. 8
Bottom of Jack Motor Override:
Tools needed: ⁄” drive ratchet and extension, ⁄” socket
1. Find the port on the bottom of the jack motor (Fig. 9A).
2. Remove the rubber plug (Fig. 10A).
3. Insert the ⁄” socket into the port (Fig. 11).
4. Turn override until the jack extends or retracts to desired position.
A
Fig. 9
A
A
Fig. 11Fig. 10
A

Rev: 08.04.2016 Page 8 Ground Control® 3.0 Owner's Manual
Troubleshooting - Touch Pad
NOTE: To clear an error code from the touch pad, repair or otherwise correct the issue, then press “ENTER.” If
the error is still present, the message will be displayed again.
LCD Message What's Happening? What Should Be Done?
****ERROR****
Excess Angle
Controller not properly secured. Check and secure controller placement.
Excessive angle reached during
auto operation. Relocate the trailer.
****ERROR****
Excessive Angle
Controller not properly secured. Check and secure controller placement.
Excessive angle reached during
manual operation. Relocate the trailer.
****ERROR****
Feature Disabled
Front of trailer below level when
starting Auto Level process (only
when trying to initiate Hitch
Recognition).
Manually retract jacks and set landing gear to hitch
height.
Touch pad power not cycled
between consecutive leveling
operations.
Turn touch pad off and then back on to reset the
system.
Zero point not set. Set zero point.
****ERROR****
Low Voltage
Battery voltage dropped below
10.8V.
Check wiring - repair or replace.
Test battery voltage under load - charge or replace.
****ERROR****
Out Of Stroke
Jack has reached maximum stroke
length and is unable to lift. Check disposition of jacks. Relocate the trailer.
Unexpected high amp current stall.
Check jacks manually or perform manual override
procedure. Repair or replace as needed.
Check for bent or damaged jacks. Repair or replace
as needed.
****ERROR****
External Sensor
Bad connection or wiring from the
controller to the rear sensor. Replace or repair connection to rear remote sensor.
****ERROR****
Jack Time Out
Time limit exceeded for the
requested auto operation. Check disposition of jacks.
****ERROR****
Auto Level Fail
Unable to auto level due to uneven
ground. Check disposition of jacks. Relocate the trailer.
Unable to auto level due to zero
point being set incorrectly. Reset zero point.
****ERROR****
Comm Error
Communication between controller
and touch pad has been lost.
Check harness for proper connections or damage.
Replace if necessary.
****ERROR****
Bad Calibration
Sensor calibration values are out of
range. Replace controller
****ERROR****
Internal Sensor Internal sensor problem. Replace controller.
**PANIC STOP**
Function Aborted
The user pressed a button on the
touch pad during an automatic
operation.
Restart automatic operation and then refrain from
pressing any buttons on the touch pad.
****ERROR****
Hall Effect Short
Short circuit detected in one of the
hall effect circuits. Test for short and repair or replace.

Rev: 08.04.2016 Page 9 Ground Control® 3.0 Owner's Manual
Special Jack Error Codes
To clear one of the error codes listed below:
1. Correct or otherwise repair the issue (see the table below).
NOTE: In order to clear the special jack error code the jacks need to be "homed". In order to "home" jacks,
each jack MUST be able to retract a minimum of 6 inches.
2. Extend all jacks to reach the 6 inches of minimum retract needed.
A. Press "FRONT" (Fig. 1G) to extend the landing gear (if required).
B. Press "REAR" (Fig. 1J) to extend the rear jacks (if required).
C. Press "LEFT" and "RIGHT" (Figs. 1H and I) simultaneously to extend the middle jacks (if equipped
and required).
3. Press and hold the retract button until all of the jacks begin to retract. The jacks will retract until they
reach the hard current limit.
4. The jacks are now “homed” and the special jack error code will be cleared.
NOTE: If the jacks do not retract, an error should display on the touch pad screen. This is typically caused by
wiring interruption.
LCD Message What's Happening? What Should Be Done?
***ERROR***
LF Jack
RF Jack
LM Jack
RM Jack
LR Jack
RR Jack
Error at a specific jack (left front,
right front, left mid, right mid, left
rear, right rear). Hall signal issue
(open, short, malfunction or loss
of communication).
Check harness connections
at controller and at jack.
Check harness for damage.
Repair or replace as necessary.
System Settings
Zero Point Calibration
The “Zero Point” is the programmed point that the trailer will return to each time the Auto Level feature is used.
NOTE: Prior to starting this procedure, double check all connections on the controller, jacks, and touch pad.
1. Manually run the jacks to level the trailer. This is best achieved by placing a level in the center of
the trailer and leveling it both front to back and then side to side. (See “Basic Jack Operation” for
instructions on how to manually operate the system).
2. Once the trailer is level, turn off the touch pad.
3. With the touch pad off, press and release the “FRONT” button (Fig. 1G) five (5) times and then press
and release the “REAR” button (Fig. 1J) five (5) times.
4. The touch pad will flash and beep and the display will read “ZERO POINT CALIBRATION ENTER to set,
Power to Exit” (Fig. 12).
5. To set the current position as the zero point, press the “ENTER” button (Fig. 1C).
6. LCD display will read “Zero point stability check” (Fig. 13).
7. LCD display will read “Zero point set successfully” once process is complete (Fig. 14).
8. The system will set this point as its level state and the touch pad will turn off.
Fig. 12 Fig. 13 Fig. 14

Rev: 08.04.2016 Page 10 Ground Control® 3.0 Owner's Manual
Preventive Maintenance
1. For optimum performance, the system requires full battery current and voltage. The battery MUST be
maintained at full capacity.
2. Check the terminals and other connections at the battery, the controller, and the jacks for corrosion,
and loose or damaged connections.
3. Remove dirt and road debris from jacks as needed.
4. If jacks are down for extended periods, it is recommended to spray exposed leveling jack rods with a
silicone lubricant every three months for protection. If the trailer is located in a salty environment, it is
recommended to spray the rods every four to six weeks.

Rev: 08.04.2016 Page 11 Ground Control® 3.0 Owner's Manual
GROUND CONTROL 3.0 OEM ASSEMBLY
LEVELING AND STABILIZATION
LCD Touch
Pad Harness
Landing Gear
Harnesses
Rear and Middle
Jack Harnesses
Rear Sensor
Jack Mounting Nut
Jack Mounting Bolt
Snapper Pin
Rear Sensor
Mounting Plate
Hall Effect
Jacks; Rear Left
And Middle
Hall Effect
Jacks; Rear
Right And
Middle
Jack Mounting
Bracket
Bolt On
Pull Pin
Landing
Gear
Power and
Ground
Harness
LCD Touch Pad
Controller
(4 Point or 6 Point)
Carriage Bolt
Top Lock Nut
Rear Sensor
Harness

Rev: 08.04.2016 Page 12 Ground Control® 3.0 Owner's Manual
GROUND CONTROL 3.0 COMPONENTS
LEVELING AND STABILIZATION
Callout Part # Description
A 305340 Hall Effect Landing Gear; Front Stroke 19.8125"
B 305339 Hall Effect Jack; Rear Left 12.5" Stroke
C 344792 Hall Effect Jack; Rear Right 12.5" Stroke
D 342610 Hall Effect Jack; Rear Short 10.5" Stroke
E 343758 Hall Effect Jack Motor
F 119113 Bolt On Pull Pin
G134989 Weld On Jack Mounting Bracket
A
BC
D
EF
G

Rev: 08.04.2016 Page 13 Ground Control® 3.0 Owner's Manual
GROUND CONTROL 3.0 COMPONENTS
LEVELING AND STABILIZATION
Callout Part # Description
H178210 Jack Mounting Nut; ½" - 20
I118076 Jack Mounting Bolt; ½" - 20 x 1 ½" Flange
J 119073 Top Lock Nut
K 125878 Carriage Bolt
L225598 Snapper Pin; ⁄ x 3"
M 231775 Rear Sensor Mounting Plate
H
I
J
K
LM

Rev: 08.04.2016 Page 14 Ground Control® 3.0 Owner's Manual
GROUND CONTROL 3.0 COMPONENTS
LEVELING AND STABILIZATION
Callout Part # Description
N232201 Rear Sensor
O 232937 LCD Touch Pad Harness
P243688 Rear Sensor Harness
Q267401 Linc Remote Charger
R234802 LCD Touch Pad
S 329164 Linc Remote
T 304136 4-Point Hall Effect Canbus Wireless Ground Control Controller
U 346005 6-Point Hall Effect Ground Control Controller
O
PQ
RS
TU
N

Rev: 08.04.2016 Page 15 Ground Control® 3.0 Owner's Manual
GROUND CONTROL 3.0 COMPONENTS
LEVELING AND STABILIZATION
Callout Part # Description
V
305115 Hall Effect Right Rear Sensor Harness
306298 Hall Effect Left Rear Sensor Harness
307489 Hall Effect Right Front Sensor Harness
307490 Hall Effect Left Front Sensor Harness
347012 Hall Effect Right Mid Harness
347013 Hall Effect Left Mid Harness
W 306176 Power and Ground Supply Harness
V
W

The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”).
LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an
authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty.
The information contained in this manual is subject to change without notice and at the sole discretion of LCI.
Revised editions are available for free download from www.lci1.com.
Please recycle all obsolete materials.
For all concerns or questions, please contact
Lippert Components, Inc.
Ph: [phone] | Web: lci1.com | Email: [email protected]
Rev: 08.04.2016 Page 16 Ground Control® 3.0 Owner's Manual
