Multay DT06-A User manual

Thank you for buying our product
Centurian Dining Table
DT06-A
Assembly Instruction
Step By Step Assembly Instructions
PRE-ASSEMBLY PREPARATION
1. Please check the pack contents before attempting to assemble this product.
A full checklist of components is given in this leaflet. If any components are missing,
please contact the retailer from whom you bought this product.
2. This product is VERY HEAVY, It should be assembled as near as possible to the
point of use. TAKE CARE WHEN LIFTING to avoid personal
injury and ( or ) damage to the product.
3. This product takes approximately 60 minutes to assemble with 4 people.
4. The fitting pack contains SMALL ITEMS which should be :
“KEPT AWAY FROM YOUNG CHILDREN“
5. Read this leaflet in full before commencing assembly.
6. You will require a 12 and 13 mm spanner (not supplied).
Page 1

HARDWARE IDENTIFICATION
ITEM DESCRIPTION Qty
A
B
Table Top
Pedestal
2
3
1
CBase Support
Page 2
Centurian Dining Table
DT06-A
Assembly Instruction
EDeck screw M6 x 75mm & Ring Washer
FDeck screw M6 x 50mm & Ring Washer
6
24
4
GNut & Special Washer
(C ) Base Support
(A) Table Top
(B) Pedestal
(B) Pedestal
(D) Top Support
2
DTop Support

Step 1
Place protective cardboard or blankets on the floor (make sure there is no debris)
and place the top of the table upside down as per the diagram below (Fig.1)
There are 3 x table leg marked clearly with white stickers ( 1, 2 and 3 ). Underneath the
table, there are corresponding marks ( 1, 2 and 3 ).
Fit the pedestal table leg ( 1 ) to underside of table marked ( 1 )
and do the same with pedestal leg ( 2 ) to underside of table ( 2 )
and do the same with pedestal leg ( 3 ) to underside of table ( 3 ).
Important Notice : Ensure the bolts are inserted as below
Centurian Dining Table
DT06-A
Assembly Instruction
Step 2
Fig.1 (Shows the table upside down on the floor ready for assembling)
Page 3
1. Attach the Pedestal leg into the Table Top with the positions of the locating tenons top support,
Tighten the Deck screws firmly using spanner (make sure with the washer)
2. Attach the Base support into the Pedestal leg (It’s required
“1, 2 or 3” marked on underside of table must be matched with “1, 2 or 3” marked
on each Pedestal leg and Base support.
one person to hold
the base support while the other attach the Middle Pedestal leg, locate special washer and nut onto
the threaded bolt and tighten the nut using spanner (not provided).
3. Do the same way for the other Pedestal leg
Note :
(B) Pedestal
(A) Table Top
(D) Top Support

Step 3
Page 4
Fig.3
Centurian Dining Table
DT06-A
Assembly Instruction
Spanner
(A) Table Top
(B) Pedestal
(C ) Base Support
Fig.2
Special
washer
Spanner
Nut
Deck screw
with washer
(D) Top Support
(B) Middle Pedestal

Page 5
Centurian Dining Table
DT06-A
Assembly Instruction
Fig.4 Shows the completed assembled leg table
DONE !
