Lippert 2021123289 Installation instructions

1
lippert.com 432-LIPPERT (432-547-7378) Rev: 08.30.22
Picnic Popup Gazebo
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006457
Table of Contents
Introduction ............................................ 2
Quick Facts: ........................................... 2
Safety ................................................... 2
Operation ............................................... 3
Picnic Popup Gazebo Set up .......................... 3
Picnic Popup Gazebo Take Down ..................... 4
Maintenance ............................................ 4
Picnic Popup
Gazebo
Installation and
Owner’s Manual
(For Aftermarket Applications)
Picnic Popup GazeboPicnic Popup Gazebo
Kit #Kit # DescriptionDescription
2021123289 Picnic Popup Gazebo
2021123290 Optional Wind Panels

2
lippert.com 432-LIPPERT (432-547-7378) Rev: 08.30.22
Picnic Popup Gazebo
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006457
Introduction
Take shelter from bugs and take in the breeze while
entertaining your guests in the spacious Picnic popup
gazebo from Lippert.
Additional information about this product can be obtained
from lippert.com/support or by using the LippertNOW app.
Replacement kits can be ordered from https://store.lippert.
com/ or by using the LippertNOW app.
The LippertNOW app is available for free on Apple App
Store®for iPhone®and iPad®and also on Google Play™for
Android™users.
App Store®and iPad®are registered trademarks of Apple Inc.
Google Play™and Android™are trademarks of Google Inc.
Quick Facts:
• Breathable mesh screen walls to enjoy fresh, bug-free air
• Comfortably accommodates four to six people in 107 sq.
ft. of space
• Designed with a hub system that allows for easy set up
and tear down within seconds
• Includes five tie downs and 12 heavy-duty stakes for
secure fastening. One carry bag also included (Fig.1).
• Water-resistant material keeps moisture out
• Provides protection against harsh sun exposure
• Made from flame-retardant material
• Item dimensions: 92-½” x 143-¾” x 143-¾”
• Item weight: 35.5 lbs.
• Breezy, bug-free entertaining
Safety
Read and fully understand all instructions before installing
or operating this product.
Adhere to all safety labels.
INJURY OR DEATH MAY RESULT FORM FIRE IF
SHELTER IS EXPOSED TO OPEN FLAME. SHELTER
IS NOT FIREPROOF. DO NOT USE OPEN FLAME
PRODUCTS INSIDE SHELTER. SHELTER FABRIC IS
TREATED WITH FIRE RETARDANT. APPLICATION
OF ANY FOREIGN SUBSTANCE MAY RENDER THE
FLAME RETARDANT PROPERTIES INEFFECTIVE.
THE “CAUTION” SYMBOL ABOVE IS A SIGN THAT
A SAFETY RISK IS INVOLVED AND MAY CAUSE
PERSONAL INJURY AND/OR PRODUCT OR
PROPERTY DAMAGE IF NOT SAFELY ADHERED TO
AND WITHIN THE PARAMETERS SET FORTH
IN THIS MANUAL.
THE “WARNING” SYMBOL ABOVE IS A SIGN THAT
A PROCEDURE HAS A SAFETY RISK INVOLVED
AND MAY CAUSE DEATH OR SERIOUS PERSONAL
INJURY IF NOT PERFORMED SAFELY AND WITHIN
THE PARAMETERS SET FORTH IN THIS MANUAL.
MOVING PARTS CAN PINCH, CRUSH OR CUT. KEEP
CLEAR AND USE CAUTION.
Fig.1

3
lippert.com 432-LIPPERT (432-547-7378) Rev: 08.30.22
Picnic Popup Gazebo
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006457
Operation
Picnic Popup Gazebo Set up
1. Find a clear and level site for your shelter. Remove from case
and undo ties (Fig.2). Stand the shelter up on the center hub.
DO NOT USE OPEN FLAME HEATERS IN YOUR
SCREEN TENT. TENT FABRIC WILL MELT WHEN
IN CONTACT WITH HOT SURFACES. USE EXTERNAL
GUY LINES AND STAKES DURING INCLEMENT
WEATHER AND WIND CONDITIONS. FABRIC IS
NOT WATERPROOF.
3. Enter through the door and push the roof center hub
up until erect. Assemble and install the door poles on
each side of the door. Insert each end of the pole into the
webbing loop (Fig.4).
Fig.2
Fig.4
4. Stake out the Picnic Popup Gazebo and use the guy
lines. Attach optional sun shade panels with hook and loop
fasteners (Fig.5,6).
Fig.5
Fig.6Fig.3
B
A
C
2. Open the shelter with the roof facing up, with the poles
(Fig.3A) on the inside. Pull out the hub at the center of the
side panels (Fig.3B) while holding the roof line with the
opposite hand and stepping on the shelter skirt base to
help pull the side panel out (Fig.3C). Repeat this step for
each side panel.

4
lippert.com 432-LIPPERT (432-547-7378) Rev: 08.30.22
Picnic Popup Gazebo
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006457
Manual information may be distributed as a complete
document only, unless Lippert provides explicit consent
to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lippert.com. Manual information is
considered factual until made obsolete by a revised
version.
Please recycle all obsolete materials and contact
Lippert with concerns or questions.
Maintenance
• Picnic Popup Gazebo is NOT machine washable. Picnic
Popup Gazebo is NOT machine dryable.
• To clean the product, hand wash using mild dish washing
soap and soft bristle brush. Allow the fabric to completely
air dry.
• Wipe down all parts - steel, plastic, and fiberglass before
putting away for the next season’s use. Salt from ocean
air can cause damage.
• DO NOT store Picnic Popup Gazebo while wet. Storing
wet can cause mildew.
• Salt, mildew and other causes and subsequent effects
are NOT covered under the limited warranty.
1. To store the Picnic Popup Gazebo, remove all stakes
and guidelines.
2. If applicable remove optional sun shade.
3. Remove and dissemble door poles.
4. Push in on the side panel hub (Fig.3B) from the outside
to collapse side panel. Repeat this step for all side panels.
Push down on the roof until collapsed.
Picnic Popup Gazebo Take Down
BE CAUTIOUS TO NOT USE EXCESSIVE FORCE TO
THE POLE STRUCTURES.
5. Grab one corner of the Picnic Popup Gazebo base
and fold over in half. Fold remaining corners over until the
Gazebo is the same shape as in step 1.
6. Carefully lift and insert disassembled Gazebo into the
carry bag, as well as the stakes, guy lines and poles.
Completed Picnic Popup Gazebo with Front Opening Panels Closed
