PLA-CP310-BL [EUM-B] 1
User Manual
PLA-CP310-BL
BLE to ORBIT.AC Control Panel

PLA-CP310-BL [EUM-B] 2
INDEX
1. INTRODUCTION ...............................................................................................................................................3
1-1 FEATURES ............................................................................................................................................................ 3
1-2 SPECIFICATIONS..................................................................................................................................................... 3
1-3 DIMENSIONS ........................................................................................................................................................ 3
1-4 I/O INTRODUCTION ............................................................................................................................................... 4
1-5 WIRING DIAGRAM................................................................................................................................................. 5
1-6 INSTALLATION ....................................................................................................................................................... 6
2 OPERATION ......................................................................................................................................................8
2-1 INITIALIZATION...................................................................................................................................................... 8
2-2 CONNECTING BY BLE ............................................................................................................................................. 8
2-3 KEY CONFIGURATION ............................................................................................................................................. 9
LIMITED WARRANTY .........................................................................................................................................12

PLA-CP310-BL [EUM-B] 3
1. Introduction
1-1 Features
1. Remote control ORBIT devices by Android devices through BLE connection.
2. 10 customizable keys.
3. Control up to 15 zones. 16 lighting scenes can be memorized in each zone.
1-2 Specifications
AC INPUT: ORBIT.AC (AC 100-240V)
Protocol: ORBIT, BLE.
Wireless Connection: Bluetooth Low Energy (BLE).
Distance of Transmission (BLE): 10M (no barrier).
Dimension: 87 * 87 * 33.9mm
1-3 Dimensions

PLA-CP310-BL [EUM-B] 4
1-4 I/O Introduction
1. Power Indicator
2. Signal Receiving Indicator
3. Signal Sending Indicator
4. BLE Indicator
5. Reset Button
6. 10 customizable keys.
7. ORBIT.AC Terminal

PLA-CP310-BL [EUM-B] 5
1-5 Wiring Diagram

PLA-CP310-BL [EUM-B] 6
1-6 Installation
Please insert slotted screw driver to the bottom of the panel to remove the cover.
Please put the metal plate and metal pads (accessories) between the panel and the installation box.

PLA-CP310-BL [EUM-B] 7
Metal pad
Metal plate (recommended for cement wall) Metal plate (recommended for wooden wall)
Without metal pads, the panel could be deformed after installing on the wall.
Put the cover back to the panel.

PLA-CP310-BL [EUM-B] 8
2 Operation
2-1 Initialization
Hold “Reset” key for 10 seconds to initialize.
2-2 Connecting by BLE
1. Enable Bluetooth on Android mobile device.
2. Install “PLCMobile” on App Store or Google Play.
3. Run “PLCMobile”
4. Enter Bluetooth List, search BLE device by ID number. Click the device and enter the password to connect.

PLA-CP310-BL [EUM-B] 9
* The ID number and password are printed on the stickers on the panel.
If the password is lost, please contact Lite-Puter by email.
2-3 Key Configuration
1. Enter PLCMobile control view. Click “Info” button.
All devices on ORBIT bus will be listed by ID number.

PLA-CP310-BL [EUM-B] 10
2. In the list, please click the ORBIT ID number of the control panel to set the definition of each key.
BLE ID number is composed by 6 figures.
ORBIT ID Number is composed by 4 figures.
The last 4 figures of BLE ID number is the ORBIT ID number.
For example, if the BLE ID number is 00:15:83:00:B4:49.
The ORBIT ID number is 83:00:B4:49. BLE ID number is hex number. Therefore, the ID number in decimal is
131.0.180.73.
