Litele LC SERIES User manual

LC SERIES
USER MANUAL FOR CCD
BARCODE READER

LC SERIES
USER MANUAL FOR CCD
BARCODE READER

Perface:
Thanksforpurchasing ourLiteleLC-seriesCCD
(Charge-CoupledDevice)BarcodeScanner.LC-Series
CCDbarcodescannerapplyall theadvancedtechnolo-
giesthataCCDcouldhave.Itssuperiorscanengine
providesquickscanning withreliablesuccessfulfirst
readrate.Thescannerisprogrammableand idealfor
PointOfSale(POS)and documenttracking
applications.
Withthebuilt-indecoder,LiteleLC-SeriesCCDcan
recognize and decodemostofthestandardbarcode,
suchasEAN-8/JAN-8,EAN-13/JAN-13,UPCA/E,full
ASCII Code39,Code39,Interleaved2of5,Code93,
EAN-128,Matrix2of5and ChinesePostCode,etc.
Thescannercanbeusedwithcomputersthathave
standardkeyboard,RS/232orUSBinterface,aswell as
otherdevicesthathavestandardcommunication
interface.
Withthepurchasing,you getnotonlytheproduct,
butalsotheinstantprofessionaltechnicalsupport
offeredby ourproductservice centerand dealers.
Ver.2.4
Themanualisapplied to LiteleLC-seriesCCD
barcodescanner, with hardwareversion 2.4.
P/N: 82010-24E

Features:
vBuilt-indecoder allowsautomaticrecogni-
tionand decoding ofmostpopularbarcodes.
vScanning speedup to 100 scans/sec.
vObviousreadLEDindicatorand nice tone
beeper.
vMultiplecommunicationinterfacesto
choose:USB,RS-232, AT/XT, PS/2 Keyboard
Emulation.
vSuperioropticalperformance witha mini-
mumresolutionof0.127mm (5 mils).
vUpto 80mm widthscanning window.
vScanning by touching/approaching the
labels(Themaximumreading distance for
LC-80 Serialis20mm, forLC-90 Serialis
180mm).
vWith“Y”WedgeKeyboardCable, youcan
usescanner and keyboardthesametime.
vDurabletrigger buttonwithdifferentmode
to choose:
* Tridgger Mode
* Auto ScanMode

Warning
Incorrectoperationmaydamageordeductthelife-
timeoftheScanner.Pleasereadthismanualcare-
fullybeforeyouconnectthescannertothecomputer.
Pleasemakesurethecomputerpowerisoff beforeyou
connectordisconnecttheCCDScannerwiththecom-
puter(Exception:USBinterface).
Otherdevices(exceptkeyboard)arenotallowedto
connectwith“Y”wedgecablewhenyou areusing LC
-SeriesCCDbarcodeKBscanner.
LC-seriesCCDRS-232 typescannersshouldnotbe
usedwithcomputerswithoutthespecialexternalDC
powersupply.
Pleasepoweroff and disconnectit immediatelyin
casethescannerisbrokenand theinnerpartswere
exposed.
Pleasepoweroff and disconnectit immediatelyto
avoidburnorfireincaseyou found high
temperature,smokeorstimulating smell happenedto
thescanner.
Don’t disassemblethescannerby yourself,Please
contactourservice centerwhenit needtobe
opened.

CATALOG
Components.........................................1
Apperance & Parts name.......................1
Installation............................................2
Usage..................................................2
ParameterSetting FlowChat.................5
Common Q&A.....................................4
System Setting......................................6
Scanning Mode Selection........................7
Output Device.........................................8
RS-232C serial communication
parmeters setting....................................8
Beeper Tone Selection ...........................11
Keyboard parameters setting .................12
Keyboard emulation parameters
Setting.................................................12
Inter-Message Delay .............................14
Inter-Character Delay .............................15
CODE 39 Parameters Setting ................15
CODEBAR Parameters Setting...............16
UPC/EAN Parameters Setting ................16
ISSN/ISBN Conversion............ ...............14
Reading Code Selection .........................19
Header and Trailer..................................22
Code Length Selection............................23
Bar code Identifier Code Selection...........25
Appendix..............................................28

Component
Thefollowing componentswill befound intheprod-
uctpackage
ForLC-80KB,including:
Scanner,UserManual
ForLC-80RS,including:
Scanner,UserManual(PowerAdapter)
ForLC-80USB,including:
Scanner,UserManual
ForLC-90KB,including:
Scanner,UserManual
ForLC-90RS,including:
Scanner,UserManual(PowerAdapter)
ForLC-90USB,including:
Scanner,UserManual
Appearance withpartsname:
TOPView
Indicator
Shell
Back View
Button
Cable
RubberShield
Scan Window

Installation:
Installation ofLC-80/90KBScanner
1.MakesurethePowerofthecomputerisoff;
2.Unplug thekeyboard;
3.Connectthescannercable(“Y”-WedgeCable)
withthecomputer;
4.Connectthekeyboardtothescannercable(“Y”
-WedgeCable);
5.Turnon thecomputer;thescannerwill startto
work.
Installation ofLC-80/90USBScanner
1.ConnectthescannerUSBcablewiththecom-
puterUSBPort;
2.Thescannerwill starttoworkrightawayifthe
computerison.
Pleasenote:theUSBKEYBOARDportshouldsetas
EnabledinBOISSetting.
Installation ofLC-80/90RSScanner
1.Makesurethepowerofthedevice isoff;
2.ConnectthescannercablewiththeSerialPort;
3.(Plug inand connectthepowercabletothe
scanner)-- Thisstepneededonlywhenconnect
withcomputer
4.Turnon thedevice;thescannerwill startto
work.

Usage:
Thisproductisusedtoscanning one-dimensional
Barcode.
Whenyou scanning,thescanning windowshouldbe
facedtothebarcode.Theredlightwill showup from
thewindowwhenyou pushthebutton,adjustthedis-
tance betweenbarcodeand thescanning window
(Maximum20mmforLC80,180mmforLC90).Please
ensurethebarcodeisall coveredwiththeredlight.
Thescannerwill indicatethesuccessfulreading by a
shortbeepand thesametimearedflashing fromthe
indicator.
Notes:
tThebarcodesymbolshall beputinthecenterof
redlight.
tOnlyonebarcodecanbereadeachtime,i.e.only
onebarcodecanbefullyputwithintheredlight.
tStrong lightenvironmentwill reduce thebarcode
readability.
tSmutchedbarcodesymbolwill reduce thebarcode
readability.
tThecablecannotbepulledwithastrong strength.
tThebarcodecanbereadonlywhenthebarcode
symbolhasacertainheight.

Setting:
LC-SeriesBarcode scannerisprogrammable.
Scanning aseriesofprogramming barcode labels
can configurethe scanners.ThisallowsEncoding
Optionsand InterfaceProtocolstobe tailored toa
specificapplication.The configuration isstored in
non-volatilememoryand will notbe lostbyremov-
ing powerfromthe scanner.
During the programming mode,the scannerwill
acknowledge agood and validreading with
speciaficmusic(certaintone ofbeeps).Long sharp
beepswill provided foreitheran invalidorbad
reading.
PleasefollowedtheConfigurationFlowChatto
setup yourCCD BarcodeScanner

ParametersSetting FlowChat
Start
Scan Barcode “Start
of Configuration”
ScanBarcodeSettings
(i.e.:“RESET TOORIGINAL”,
“BEEPING TONE—LOW”… )
Scanbarcode“End ofConfigration”
End
Finish
Setting?
Yes
No?

Common Q & A
Problem
Description Diagnosis Solution
The scanner
does not
respose when
the
device/computer
power on
The interface of
host is damaged. Replace the host interface.
The connecting
cable is damaged. Check the cable, repaired if damaged.
The scanner
is damaged. Send to the service center for repair.
The power supply of
the serial interface
scanner is not connected
well or is damaged.
Connect the power
supply again or
replace the power
supply.
Can not
recoganize
/decode
barcode
Check if the barcode
format is in the readable
range of this barcode and
the mode is set as "on"
Set according to the
setting manual.
The scanner is too close
to the barcode symbol. Move further.
The length of the barcode
symbol exceeds the
range of red light.
Scale down the
barcode symbol.
Hard to
recoganize
/decode
barcode
The surface of the
barcode symbol is
damaged or smutched.
Manually input with
keyboard.
The glass of the scanning
window is dirty. Clean the scanning window glass.
The light of the
environment is too strong. Change the working environment
No show up on
the screen after.
scanning and
beeping
The interface mode or
communication
parameter is not correct.
Set according to the
setting manual.
The cable is working
well. Replace/repair the cable line.

StartofConfiguration
6
System Parameters
RESET
The reading of the “RESET” La-
bel turns all the parameters back
to default values.
ABORT
The reading of the “ABORT”
label discards all the parameters
read prior to the “EXIT(Start of
Configuration)”.
START
Start setting (Start of
Configuration)
EXIT
SET
Ignore all code system
Show Version
Show the hardware version.
Ignore
Exit setting (End of
Configuration)
Confirminput

End ofConfiguration 7
Scanning Mode Selection
Trigger
Thescannerbecomesinactiveas
soon asthedataistransmitted.It
mustbetriggeredtobecomeactive
again.
TurboTrigger
Thescannerswitchispressedand
doublereading forthesamebar
codeisnotpermitted.Thescanner
will beinactiveaftertheswitchis
released.
Auto Scan
Inautoscanmode,thescanneris
still activeafterthedatais
transmitted,butthesuccessive
transmission ofthesamebarcode
isnotallowed.
Alt
Thisscannerwill lightup when
press thescannertriggerswitch
once.And,thescannerwill turnoff
fornextpressing.
Testing
Forfactorytesting useonly

StartofConfiguration
8
OUTPUTDEVICE
RS232-C
K
e
y
B
o
a
r
d
USB
RS-232CSERIALCOMMUNICATION
PARAMETERSSETTING
BAUD RATE
19200
4800
2400
9600

End ofConfiguration 9
1200
600
DATABIT
7
8
STOPBIT
1
2
PARITY
EVEN
ODD

StartofConfiguration
10
MARK
NONE
SPACE
SERIALPORTMESSAGETERMINATOR
NONE
CR/LF
CR
LF
HTAB

End ofConfiguration 11
STX/ETX
EOT
GOODREADBEEPERTONE
Medium
Low
High
Disable

StartofConfiguration
12
SOUNDDURATION
Long
Medium
Short
Very Short
MESSAGETERMINATIOR(FORKEYBOARD)
None
CR/LF
TAB
