LITELOK ONE MOTO 108 User manual

LITELOK ONE has been designed to be quick and easy
to use. DO NOT FORCE the key if the lock jams and ALWAYS
push the key in fully before turning 180º clockwise.
If you have trouble it might be because the key was not
fully inserted. Wiggle the key gently, side to side and turn
anticlockwise, remove and try again. If any issue persists
please contact the place of purchase.
KEEP ONE AS SPARE and take note of the key code to
enable you to order replacements if required at a later date.
Wipe all surfaces with a soft cloth and a small amount of soapy
water if required. Dry well and avoid introducing water into the
locking mechanism. Lubricate with a small amount through key
hole periodically. LITELOK is supplied with an aerospace-rated
anti-corrosion protection coating and has been designed to
resist dirt and corrosion but we recommend drying if it gets
wet. This coating should last a year and you can reapply with
a proprietary product.
Please contact us for recommendations.
USING YOUR LITELOK® KEYS
HOW TO OPERATE YOUR LITELOK®
YOU SHOULD HAVE RECEIVED
• Hardened steel lock casings
• Pick resistant disc detainer style lock mechanism
• Patented in-line lock clicks to lock without the key,
and allows multiple locks to be joined together
for extra length
• Patented BOAFLEXICORE® strap composite strap
employing high tensile steel in a polymer matrix
• Hard wearing outer sleeve & soft neoprene skin with
retro reflective print
• Each single Litelok® supplied with 2 keys &
2 WrapStraps
• Many options for carrying; rattle-free design makes
no noise when carried on the motorcycle
LITELOK®
Weight
Length
Locking
Circumf-
erence
Width
108 TWIN 108
LITELOK® ONE MOTO SPECIFICATION
7
3
4
6
5
2
OPENING YOUR LITELOK®
LOCKING YOUR LITELOK®
PLEASE DO NOT USE
LITELOK® AS A WEAPON
YOU DO NOT NEED THE
KEY TO CLOSE YOUR LITELOK
DO NOT LEAVE KEY IN LOCK
HOLD LITELOK FIRMLY &
TURN THE TWO ENDS IN
WARNING: KEEP HANDS AWAY FROM
CLOSE LINE TO AVOID PINCHING
SNAP LITELOK SHUT
FULLY INSERT KEY (*)
ROTATE THE KEY A
HALF TURN (180º)
CLOCKWISE
OPEN THE LITELOK KEEPING
THE LOCK PART STRAIGHT
LITELOK WILL NATURALLY
SPRING OPEN READY TO USE
!WARNING!
DO NOT LEAVE
THE KEY IN THE
LOCK. IF YOU
ACCIDENTALLY
DROP THE
LOCK & IT LANDS
ON THE KEY,
IT CAN DAMAGE
THE LOCK/KEY
There is a slight knack to
opening Litelok which,
once you’ve got it, becomes
second nature.
We suggest that you practice
using Litelok a few times before
taking it out with your bike.
REVERSE SEQUENCE TO LOCK
INSTRUCTIONS
2 KEYS 2 WRAPSTRAPS
1 LITELOK®
CARING FOR YOUR LITELOK®
TWIN LITELOK® ONE MOTO
You will have two sets if you
have a TWIN LITELOK®
You can use the same key on
both locks and connect them
together in series (as shown)
or in parallel (e.g. front
wheel/back wheel) for extra
security.
2x 1.46kg
2x 107.5cm
2x 103.5cm
5cm
2x 3.21lb
2x 42.3in
2x 40.7in
1.9in
1.46kg
107.5cm
103.5cm
5cm
3.21lb
42.3in
40.7in
1.9in

To carry your LITELOK SAFELY, we recommend either putting
it in a bag, top box or attaching it with BOTH of the two high
visibility hook and loop wrapstraps provided on a rack.
This may not work for all motorcycles, in which case you
need to find another location which is SAFE and SECURE or
coil it to store in a bike box.
Failure to secure your LITELOK correctly may also result in
damage to your motorcycles paintwork. If you are unsure
whether your Litelok is secured safely DO NOT SET OFF ON
YOUR MOTORCYCLE. Take time to adjust or find another way
to carry your Litelok.
It is incredibly simple to cinch your LITELOK into a
compact shape, making it easy to carry in your rucksack,
top box, panniers or tank bag.
Use both hands to carefully coil your LITELOK, making
sure the female end is at the centre of the coil.
Due to the flexible nature of the material the LITELOK will
naturally want to uncoil itself.
Use both hook & loop wrapstraps to tie down the
LITELOK, to keep it in a coiled shape.
Litelok GOLD MOTO provides PORTABLE MOTOYCYCLE
SECURITY.
ALWAYS lock your motorcycle to a fixed object through the
back wheel and frame and keep the lock off the ground.
IDEALLY use a LITELOK on the front wheel too.
Alternatively you can remove it and securely lock it along
with the back wheel.
Check out our video guide at www.litelok.com
ALWAYS check your lock before leaving your motorcycle.
CARING FOR YOUR LITELOK
CARRYING YOUR LITELOK
COMMENT ENTRETENIR VOTRE LITELOK
Clean & lubricate your LITELOK regularly
Wipe all surfaces with a soft cloth and if necessary use
a small amount of soapy water to clean them before
drying. Take care not to introduce water into the locking
mechanism itself.
LITELOK has been designed to resist dirt and corrosion
but we recommend drying the product if it gets wet.
The locking mechanism can be lubricated with a small
amount of lubricant applied periodically through the
keyhole. LITELOK is supplied with an aerospace-rated
anti-corrosion protection coating applied in production
which may make your lock feel a little waxy on the metal
surfaces but this is normal.
The coating should last a year.
You can reapply with a proprietary product.
Contact us for our recommendations.
Zeal Innovation Ltd (Zeal) provides a warranty that
LITELOK (the product) is free from manufacturing
defects in material and workmanship. This warranty is
one year from the date of purchase unless otherwise
stipulated in local law.
The warranty is void if the product is tampered with in
any way. Upon return of the defective product to Zeal or
its authorized distributor for inspection, free and clear
of all liens and encumbrances and accompanied by
proof of purchase and a statement of the defect/s, Zeal
will replace the product.
This limited warranty may not be assigned or otherwise
transferred in any way and may not be extended,
altered or varied. To the fullest extent allowable by
the laws applying here to, this limited warranty is in
lieu of any other warranties, either express or implied,
including but not limited to any warranties of
merchantability or fitness for a particular purpose, all of
which are expressly excluded and disclaimed. Zeal
Innovation Ltd will not be liable for loss of profits, any
special, incidental, or consequential damages, which
purchaser may sustain, any damages for claims by any
third party or punitive damages, even in the event of
notice of the possibility of such damages.
Zeal reserves the right to change the specification and
design details of its products without notice in the
pursuit of excellence.
e&oe
WARRANTY INFORMATION
All Patents, Trademarks & Copyright are property of Zeal Innovation Ltd
t/a Litelok, Unit 10, Technium 1, Swansea Waterfront, Swansea SA1 8PH, UK
www.litelok.com | [email protected]
CINCHING YOUR LITELOK® ONE
HOW TO LITELOK® YOUR MOTORBIKE
