Lites PROFILE C6 COLOUR RGBACL Instruction Manual

Lites
PROFILE C6
COLOUR RGBACL
Owner's and service manual
Read this manual throu hout and carefully follow all the instructions contained. File
this manual for future perusals. It is essential to read and follow uidelines and other
information contained in this manual to ensure correct installation, service and full
operations of the Lites Profile. All operations must be accomplished, handled and
carried out by qualified personnel only.
NOT COMPLYNIG WITH GIVEN NOTICE WILL VOID WARRANTY AND WILL TOTALLY DISCHARGE THE
MANUFACTURER FROM ANY RESPONSABILITY
www.litessrl.com

Page 2 of 12
Unpacking
Unpack the carton and gently remove Lites Profile C6 from the box. nsure all parts and components of
the Lites Profile C6 received are undamaged.
In the event the Lites Profile C6 shows any damage, do not use it and contact immediately your
transporter as well as your seller.
Items in the carton consist of:
− Lites Profile C6 T luminaire
− Colour frame
− Blue Neutrik PowerCon connector
− This owner's and service manual
Safety information for the use of the Lites Profile C6 and its periodical maintenance
‒ Lites Profile C6 is for professional use only and N V R for domestic use.
‒ Users must scrupulously comply with manufacturer’s guideline that follows; any other use in contrast
with the provided information will void warranty and will discharge the manufacturer from any legal
responsibility
‒ Never use Lites Profile C6 on any flammable surfaces.
‒ Minimum distance from any flammable source is of 0.25m.
‒ Minimum throw distance from illuminated surface: 1m.
‒ Installation of the unit(s) must be secured with adequate clamps, safety cords, nuts and bolts to bear
twice the weight of the whole unit(s)
‒ Always power Lites Profile C6 to safety circuit breakers. Lites Profile C6 MUST NOT and CAN NOT be
operated via Phase Control Dimmer.
‒ Install Lites Profile C6 in ventilated ambient which temperature must not exceed + 35°C (+ 95° F)
‒ Caution: when in operation some outer body-parts of the Lites Profile C6 can reach temperatures of up
to + 60C° (+ 140° F)
‒ Lites Profile C6 must be fitted with protection shields (Lenses)
‒ Always disconnect power, (always check twice that power is off) before Servicing/Operating the unit.
‒ Lites Profile C6 is rated Class I
‒ Protection rating IP20
‒ arth connection is MANDATORY!
‒ L D core must never be touched in any way as it may impair its use.
‒ An essential and periodically throughout cleaning of the Lites Profile C6 is recommended. This practice
avoids that layers of dust and other impurity put at risk and reduce the correct operation of the unit.
Lenses must be cleaned; remove layers of dust that may impede and or reduce the passage of the
light through the lenses. The correct and periodically maintenance keeps also fans and vents clean, this
practice ensures the best conditions and performance of the Lites Profile C6. Never touch the yellow
L D core in any way nor use solvents as this can irremediably damage the L D. Protection shields
(lenses) if worn out, must be replaced with new ones
CE APPROVALS
The Lites Profile products to which this manual refers to, complies with uropean directive pursuant to:
2014/35/ U safety of electrical equipment supplied at low voltage (LVD)
2014/30/ U lectromagnetic compatibility ( MC)
2011/65/ U Restriction of the use of certain hazardous substances (RoHS)
WARRANTY
A 24-month warranty is granted on the Lites Profile C6 from its purchase’s date. Warranty covers
fabrication defects only, unit is not replaced but will be 100% fixed. Lites Profile C6 must be handled and
used by qualified people, as if not, it will void the warranty. Warranty is also voided if qualified personnel
and users do not and have not handled the Lites Profile C6 properly. Any improper and unauthorised use,
such modification(s) or misapplication of the unit will also void the warranty of the product(s). Silver
colour label showing technical data and serial number, if removed or if data are altered or tampered to
change specs or render details illegible, will also immediately void the warranty
.

Page 3 of 12
Technical specifications
Power Supply 100-240 V~ 50/60Hz
Maximum power consumption 175W
cos Ø 0,98
Stand-by power consumption 3W
Minimum ambient temperature -10°C
Maximum ambient temperature 35°C
L D Colour RGBACL: Red; green; blue; amber; cyan; lime
30 colored presets
L D CRI: Minimun CRI : 93> and 98>(depending on the selected white)
10 white presets from 2,300 ° K to 10,000 ° k
L D Life (see Manufacturers ’ specifications)
Colour frame dimensions: 163x159 mm
Aluminium die-caste body to maximize heat dissipation
Weight 7,5 Kg
IP Rating 20
Working position Any
Power connectors IN & OUT Neutrik PowerCon
Data connectors IN & OUT XRL5
Data protocols DMX 512; RDM ready
User interface 4-digit display and 4 buttons
Manual operation: Users must operate via buttons provided on the display
Fan control: Fan speed adjustment
Control of L D frequency: Selection of L D frequency refresh
4 Dimming curves control: Selection of four dimming curves control
accessories: Iris diaphragm; Gobo holder (size B Ø 86 mm, image Ø 66mm)
Compliant
Dimensions (see Picture):

Page 4 of 12
Lites Profile C6 installation
Lites Profile C6 is delivered with a robust yoke that hosts 3 x 12 mm mounting holes. The use of an
adequate G-clamp to sustain at least twice the weight of the Lites Profile C6 (Lites Profile C6 weighs 7,5
kg) and/or M10 screw is mandatory. The use of safety chain(s) to sustain twice the weight of the Lites
Profile C6 is also mandatory; the safety chain adds more protections and safety to users and third
parties. ye-lid for the safety chain is provided on the Lites Profile C6. The unit can be installed in any
position (See Fig)
Connection to mains
WARNING! Installation(s) must be accomplished, handled and carried out by qualified
personnel only and must comply & meet with all norms in force in the installation's country
Lites Profile C6 is supplied with a free Blue Neutrik PowerCon plug that must be wired using a 3x1.5mm²
lead Additional specifications include:
‒ Operating Voltage: 300/500V
‒ Test Voltage: 2KV
‒ Operating Temperature: -10°C / +35°C (- 14° F / +90° F)
Connect blue wire to N terminal, brown wire to L terminal and Yellow/Green wire to earth terminal.
nsure to connect to safety circuit breakers at all times. When connected to 230VAC, daisy chain must
not exceed the quantity of 10 units and 5 units when connected to 110VAC. Maximum daisy chain cable
length: 20m.
WARNING: NEVER CONNECT LITES PROFILE C6 ENGINE TO ANGLE PHASE DIMMER PACK NOR
TO NON- DIM MODE
POWER
IN
POWER
OUT

Page 5 of 12
Si nal control connection
Lites Profile C6 can be operated via either DMX512A and or RDM ready Protocols. For Daisy chain DMX
line use a-2 lead wire plus shield.
Red L D dot is on when DMX Input is available. DMX off line when L D dot is off
RDM – Remote Device Mana ement
RDM Controller allows for remote standard operations
RDM default options include:
Discovery mode: RDM is active when controller detects this mode; the device reports the presence of the
Lites Profile C6 by giving a flash of light (Controller sets the device to a listing to read: settings, DMX
address, personality settings, i.e. DMX mode including all the above mentioned DMX values)
ON/OFF ”Identify”: This mode is to identify the manufacturer’s device (Lites srl) -Flash of light is to
confirm selection -
Model information (HPL D-BUCK)
Software version information (HPL D-BUCK v.x.xx)
Mode to reveal temperatures of the L D and of the driver
Mode to reveal hour-meters of the L D and of the device
Focus
Loosen knob 5 than adjust optics to focus
light projected
DMX XLR 5 Pin Assignment
Pin Description
1 GND
2 DMX-
3 DMX+
4 Not connected
5 Not connected
5

Page 6 of 12
Shutter blades
There are 4 shutter blades, to shape patterns
Installations of the accessories
Gel frame
Lites Profile C6 is delivered with a standard 163x159mm
colour frame. The L D source used on Lites Profile C6 allows
the use of colour filters that cannot be used with high
wattage tungsten lamps. nsure that accessories when
installed on the Lites Profile C6 are securely fitted in the
gates and that are engaged and secured by the spring lock
provided. (See figure)
Gobo holder
Standard gobo holder (not included) can be used to house
gobos 'size B' (Ø 86 mm, Ø 66 mm). nsure gobo holder is
securely engaged in its gate so to avoid injuries to third
parties in case this accessory comes out of its place
Iris diaphra m
Diameter of the projected image maybe changed in sizes
with the use of an iris diaphragm (not included). To set Iris
into its housing loosen the two M4 screws and move the
bulkhead (see fig.). nsure that iris is secured into its gate to
avoid injuries to third parties in the event it comes out of its
place.
Power Lites Profile C6 ON
WARNING! Before powerin Lites Profile C6 ensure
that all installation(s) procedure(s) have(s) been
properly set learnt and accomplished.
When Lites Profile C6 is powered the setup display will show
the software release version. The UP, DOWN, NT R and SC
buttons allow the operations of Lites Profile C6 menu. UP and
DOWN buttons allow to browse through menu options, the
NT R button is to confirm selection. The SC button is to
return to the previous menu or to quit previous setting(s).
A
DETTAGLIO A
1
4
2
3

Page 7 of 12
Menu items
Displayed
Messa e
Allowed or
displayed
values
Function
Addr 001..512 Set Up DMX Address
Auto
(Automatic
mode)
co01
co02
co03
co04
co05
co06
co07
co08
co09
co10
co11
co12
co13
co14
co15
co16
co17
co18
co19
co20
co21
co22
co23
co24
co25
co26
co27
co28
co29
co30
co31
co32
co33
co34
co35
co36
co37
co38
co39
co40
Preset 1 red
Preset 2 light red
Preset 3 orange
Preset 4 medium amber
Preset 5 amber
Preset 6 straw tint
Preset 7 pale yellow
Preset 8 spring yellow
Preset 9 yellow
Preset 10 lemon yellow
Preset 11 lime
Preset 12 lime green
Preset 13 green
Preset 14 moss green
Preset 15 light cyan
Preset 16 cyan
Preset 17 peacock blue
Preset 18 summer blue
Preset 19 bright blue
Preset 20 light steel blue
Preset 21 light blue
Preset 22 slate blue
Preset 23 blue
Preset 24 deep lavender
Preset 25 lavender
Preset 26 magenta
Preset 27 rose pink
Preset 28 dark pink
Preset 29 bright pink
Preset 30 Rainbow
Preset 31 white 2300°k
Preset 32 white 2700°k
Preset 33 white 3200°k
Preset 34 white 4000°k
Preset 35 white 5600°k
Preset 36 white 6500°k
Preset 37 white 7000°k
Preset 38 white 8000°k
Preset 39 white 9000°k
Preset 40 white 10000°k
It’s possible to select 30 colored presets
and 10 fixed white presets, without the
aid of the DMX 512 signal. By selecting
the value indicated from co01 to ……
co40 you choose the combined color.
When you turn off the projector the
selected preset will be saved. In each
preset you can change the output color
level.
Select the preset that needs to be to be
changed. If you press once the nter
button, the display will show r (red) with
the set value, then if you keep pressing
nter, G (green), b (blue), A (amber), c
(cyan), L (lime), S (strobe), n (Rainbow),
d (dimmer) will be displayed one by one.
Use the Up and Down button to adjust
the level of the 6 colors + the 3 functions
n (raiwbow), S (strobe), d (dimmer),
pressing them one by one from 0 to 255,
to determine the output color.
Always confirm with nter to save the
settings.
Pr01
Pr02
Pr03
Pr04
Program 1: auto
Program 2: auto
Program 3: auto
Program 4: auto
Automatic mode without DMX 512 Protocol
signal.Program selections run between Pr01
through Pr 04. Both programs can be modified.
To change program select nter then view
(Scn0…Scn6; max scenes of each program).
Clicking on enter once more it shows P.00.0
(time) followed by F.00.0 (speed) and ultimately
the last view shows 1c.01… though c40 (colour
to be assigned to each scene) The use of
UP/Down keys allow for setting values. When
selections are completed press enter to confirm.
MASL
Master Mode
The Master Mode uses the same settings as the Auto Menu. The only
exception is that when all fixtures are connected to DMX 001 in daisy-
chain, they perform the same presets and or the same presets selected
on the Master fixture. The slave projectors must be set in 9ch mode.

Page 8 of 12
ModE
12 ch (D)
RGBACL 12 ch (default)
Dmx mode (view next page)
2 ch
2 ch
16 ch
RGBACL 16 ch (16 bit)
6 ch
RGBACL 6 ch
RGB
RGB 6 ch
HSI
Stubio HSI 6 ch
9ch
9 ch
drUt
..°C
Shows driver operating temperature
LEdt
..°C
Shows leds operating temperature
PUM
0..100%
Shows current led power (0
-
100%)
SMoo
FAST
M D
SLOW
DMX data Speed adjustment
GAMM
qUAd
SCUr
qUAd2
LIn
Dimming curves available
FrEq
1K
2K
3K
4K
5K
6K
7K
8K
9K
10K
L D operation frequence
booS
Off
on
When OFF, L D max flux : 90%
When ON, L D max flux : 100%
FAn
Aut
M DH
M DL
LOW
4 fan operating modes i.e atuomatic, medium fast, me
dium slow, slow
speed.
Fan speed adjujstments (fan-sound) reflect on self-correct output L D
brightness and other factors as room-temperature, number of engaged
channels
PoS AA
VV
Display orientation selection:
AA = normal
VV = inverted
StbY Off
on
Standby display activity:
off = display always switched on = display switched off after few
seconds of buttons inactivity (only the right side dot will be lighted to
indicate DMX availability)
dEF
SUr
ON Will restore the default factory values
SoFt
Shows Software version
DMX Operatin Modes (Mode)
Selecting 1 of the 7 available modes it enables the number of channels required, and its relevant modes,
needed to operate LIT S PROFIL C6

Page 9 of 12
mode 12 ch RGBACL (default)
Ch Function Dmx levels
1 red 0..255 From 0 to max 255
2 green 0..255 From 0 to max 255
3 blue 0..255 From 0 to max 255
4 amber 0..255 From 0 to max 255
5 cyan 0..255 From 0 to max 255
6 lime 0..255 From 0 to max 255
7 strobe
0…15 Strobo disingaged
16…255 Strobo from slow (16) to fast (255)
8 Rainbow
0..15 Rainbow disingaged
16..255 Rainbow from slow (16) to fast (255)
9 dimmer 0..255 From 0 to max 255
10
(priority on
channel 11)
White selection
0…15 Deserted whites
16…17 2300°k cri 93
18…38 from 2300°k to 2700°k
39…40 2700°k cri 97
41…61 from 2700°k to 3200°k
62…63 3200°k cri 98
64…84 from 3200°k to 4000°k
85…86 4000°k cri 95
87…107 from 4000°k to 5600°k
108…109 5600°k cri 98
110…130 from 5600°k to 6500°k
131…132 6500°k cri 95
133…153 from 6500°k to 7000°k
154…155 7000°k cri 93
156…176 from 7000°k to 8000°k
177…178 8000°k cri 96
179…199 from 8000°k to 9000°k
200…201 9000°k cri 93
202…222 from 9000°k to 10000°k
223…225 10000°k cri 95
3200°k halogen lamp operation 226…255 halogen lamp dimming simulation
11
Color selection
0…15 No color
16..23 red
24…31 light red
32…39 orange
40…47 medium amber
48…55 amber
56…63 straw tint
64…71 pale yellow
72…79 spring yellow
80…87 yellow
88…95 lemon yellow
96…103 lime
104…111 lime green
112…119 green
120…127 moss green
128…135 light cyan
136…143 cyan
144…152 peacock blue
153…159 summer blue
160…167 bright blue
168…175 light steel blue
176…183 light blue
184…191 slate blue
192…199 blue
200…207 deep lavender
208…215 lavender
216…223 magenta
224…231 rose pink
232…239 dark pink
240…247 bright pink
248…255 FULL RGBACL
12 Fan speed
0..25 Auto speed or set from menu
26..255 Fan speed from slow to fast

Page 10 of 12
mode 2 ch
1 Color selection
0…15
No color
16…20
red
21…25
light red
26…30
orange
31…35
medium amber
36…40
amber
41…45
straw tint
46…50
pale yellow
51…55
spring yellow
56…60
yellow
61…65
lemon yellow
66…70
lime
71…75
lime green
76…80
green
81…85
moss green
86…90
light cyan
91…95
cyan
96…100
peacock bl
ue
101…105
summer blue
106…110
bright blue
111…115
light steel blue
116…120
light blue
121…125
slate blue
126…130
blue
131…135
deep lavender
136…140
lavender
141…145
magenta
146…150
rose pink
151…155
dark pink
156…160
br
ight pink
161…165
Full RGBACL
White selection
166…170
white 2300°k
171…175
white 2700°k
176…180
white 3200°k
181…185
white 4000°k
186…190
white 5600°k
191…195
white 6500°k
196…200
white 7000°k
201…205
white 8000°k
206…21
0
white 9000°k
211…215
white 10000°k
Rainbow 216…225
Rainbow from slow (191) to fast(229)
Sequence rainbow R-G-B-A-C-L
3200 ° k halogen lamp
operation
226…255
halogen lamp dimming simulation
2
dimmer
0..255
From 0 to max 255

Page 11 of 12
mode 16 ch RGBACL 16 bit
Ch
Function
dmx levels
1
red
0..255
From 0 to max 255
2
Red fine
0..255
Red fine tune adjustment
3
green
0..255
From 0 to max 255
4
Green fine
0..255
Green fine tune adjustment
5
blue
0..255
From 0 to max 255
6
Blue fi
ne
0..255
Blue fine tune adjustment
7
amber
0..255
From 0 to max 255
8
amber fine
0..255
amber fine tune adjustment
9
cyan
0..255
From 0 to max 255
10
cyan fine
0..255
cyan fine tune adjustment
11
lime
0..255
From 0 to max 255
12
lime
fine
0..255
lime fine tune adjustment
13 strobe
0…15
Strobe disingaged
16…255
Strobo from slow (16) to fast (255)
14
dimmer
0..255
From 0 to max 255
15
Dimmer fine
0..255
Adjustment of global fine light intensity
16
Fan speed
0..25
Auto
speed or set from menu
26..255
Fan speed from slow to fast
mode 6. ch RGBACL
Ch
Function
dmx levels
1
red
0..255
From 0 to max 255
2
green
0..255
From 0 to max 255
3
blue
0..255
From 0 to max 255
4
amber
0..255
From 0 to max 255
5
cyan
0..255
From 0 to max 255
6
lime
0..255
From 0 to max 255
mode 6.RGB 6 ch
mode 9 ch
Ch
Function
dmx levels
1
red
0…255
From 0 to max 255
2
green
0…255
From 0 to max 255
3
blue
0…255
From
0 to max 255
4
amber
0…255
From 0 to max 255
5
cyan
0…255
From 0 to max 255
6
lime
0…255
From 0 to max 255
7
strobe
0…15
Strobo disingaged
16…255
Strobo from slow (16) to fast (255)
8 Rainbow
0…15
Rainbow disingaged
16...255
Rainbow
from slow (16) to fast (255)
9
dimmer
0…255
From 0 to max 255
1
Red
0..255
From 0 to max 255
2
Green
0..255
From 0 to max 255
3
Blue
0..255
From 0 to max 255
4
Dimmer
0..255
From 0 to max 255
5 strobe
0…15
Strobe disingaged
16…255
Strobo from slow (16) to fast (255)
6 Fan speed
0..24
Auto speed or set from menu
25..255
Fan speed from slow to fast

Page 12 of 12
mode 6.HSI STUDIO 6 ch
1 Hue 0..255
Hue selection, following levels
R, R+L, R+G+L, G+L,G, G+C,G+B+C, B+C, B B+A, R+B+A, R+A, R
2 Saturation 0..255
Color saturation with set color in the Hue channel
3 Dimmer 0..255
From 0 to max 255
4
strobo 0…15
Strobe disingaged
16…255
Strobo from slow (16) to fast (255)
5
(priority on
channel 1)
Selection
whites
0…15
Whites off
16…18
2300°k cri 93
19…41
from 2300°k to 2700°k
42…44
2700°k cri 97
45…67
from 2700°k to 3200°k
68…70
3200°k cri 98
71…93
from 3200°k to 4000°k
94…96
4000°k cri 95
97…119
from 4000°k to 5600°k
120…122
5600°k cri 98
123…145
from 5600°k to 6500°k
146…148
6500°k cri 95
149…171
from 6500°k to 7000°k
172…174
7000°k cri 93
175…197
from 7000°k to 8000°k
198…200
8000°k cri 96
201…223
from 8000°k to 9000°k
224…226
9000°k cri 93
227…249
from 9000°k to 10000°k
250…255
10000°k cri 95
6
Fan speed
0..24 Auto speed or set from menu
25..255 Fan speed from slow to fast
Error messa es
In case of malfunction, the following messages can be shown:
Led sensor error: the sensor on the led is faulty.
Overtemperature L D: the temperature on the L D exceeds the allowed limit, check if the fan is working.
Micro overtemperature: the temperature on the driver board exceeds the allowed limits, check if the fan is working.
Micro sensor error: the sensor on the driver board is faulty.
If these malfunctions occur, the L D turns off.
Avoid using the LIT S PROFIL C6 and promptly contact any authorized service centre.
Periodical maintenance
To ensure the correct LIT S PROFIL C6 operation, we suggest the following periodical maintenance operations:
Remove dust or any kind of other dirt from the fans and loop-holes, this operation ensures the correct air flow
Remove dust from lenses using a clean cloth. This will ensure the maximum light efficiency
Replace damaged protection screen and lenses when necessary.
Do not touch nor clean the LEDs nor the sourranded area with solvent
Device disposal information
At the end of its life, LIT S PROFIL C6 must be disposed to an appropriate electrical and electronic
equipment waste collection centre. co-friendly disposal, helps to avoid possible negative impact on the
environment and human health and promotes the reuse and/or recycling of the materials making up the
product. Illegal disposal involves administrative sanctions provided by laws enacted.
Note
Manufacture declines any sort of personal/corporate responsibility/liability for damages caused by people that are
not scrupulously following indications given in this manual as for the inadequacy or for misuse of the product they
do, as well as if the product has been handled by unqualified personnel. Not complying with security
norms/periodical maintenance and all information contained and as expressed in the owner's/service manual will
also totally free personal/corporate responsibility/liability. Text, wordings, drawings, specifications, modifications
and other changes of this manual may apply anytime without notice. The specifications are not binding.
Lites Profile C6 color 06/12/2020 rev.00
