Little Giant 6EC-CIM User manual

STOCK No. 53DH04
MODEL 6EC-CIA-SFS
STOCK No. 53DH05
MODEL 6EC-CIM
STOCK No. 53DH06
MODEL 10EC-CIA-SFS
Installation Guide

BEFORE GETTING STARTED
READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO INSTALL, OPERATE, OR SERVICE YOUR PRODUCT. KNOW THE PRODUCT’S APPLICATION,
LIMITATIONS, AND POTENTIAL HAZARDS. PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE TO COMPLY WITH THESE
INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE!
Refer to product data plate(s) for additional operating instructions and specifications.
This is the safety alert symbol. When you see thiss
!
symbol on your pump or in this manual, look for one of the following signal words and be alert to the
potential for personal injury or property damage if ignored:
s
!
DANGER warns about hazards that will cause serious personal injury, death or major property damage if ignored.
s
!
WARNING warns about hazards that can cause serious personal injury, death or major property damage if ignored.
s
!
CAUTION warns about hazards that will or can cause minor personal injury or major property damage if ignored.
s
!
NOTICE indicates special instructions which are important but not related to hazards. Carefully read and follow all safety instructions in
this manual and on pump.
s
!
DANGER DO NOT USE TO PUMP FLAMMABLE OR EXPLOSIVE FLUIDS SUCH AS GASOLINE, FUEL OIL, KEROSENE, ETC. DO NOT USE IN
EXPLOSIVE ATMOSPHERES OR HAZARDOUS LOCATIONS AS CLASSIFIED BY THE NEC, ANSI/NFPA70. FAILURE TO FOLLOW THIS WARNING CAN RESULT IN
PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. DO NOT HANDLE A PUMP OR PUMP MOTOR WITH WET HANDS OR WHEN STANDING ON A WET OR
DAMP SURFACE, OR IN WATER. FAILURE TO FOLLOW THIS WARNING CAN RESULT IN FATAL ELECTRICAL SHOCK. PUMP SHOULD ONLY BE USED WITH
LIQUIDS COMPATIBLE WITH PUMP COMPONENT MATERIALS.
s
!
WARNING Make certain that the unit is disconnected from the power source before attempting to service or remove any
component. If the power disconnect is out of sight, lock it in the open position and tag it to prevent unexpected application of power.
s
!
WARNING This equipment should be installed and serviced by technically qualified personnel. Comply with national and local
electrical and plumbing codes when installing this unit. Failure to install it in compliance with national and local electrical and plumbing codes and within
Franklin Electric’s recommendations may result in electrical shock or fire hazard, unsatisfactory performance, or equipment failure. Installation information
is available through pump manufacturers and distributors, or directly from Franklin Electric at our toll-free number 1-800-701-7894.
This equipment must not be used by children or persons with reduced physical, sensory or mental abilities, or lacking in experience and expertise,
unless supervised or instructed. Children may not use the equipment, nor may they play with the equipment or in the immediate vicinity.
s
!
CAUTION In any installations where property damage and/or personal injury might result from an inoperative or leaking pump due
to power outages, discharge line blockage, or any other reason, a backup system(s) and/or alarm should be used.
• Keep work area clean, well-lit, and uncluttered.
• Keep safety labels clean and in good condition.
• Do not run pump dry. For optimal cooling and to prolong the motor life,
the liquid level being pumped should normally be above the top of the
pump housing.
• Wear safety glasses while installing or performing maintenance on pump.
• Make sure all ELECTRICAL POWER IS OFF before connecting any electrical
wires. Wire sump pump system for correct voltages. Follow all pump
wiring instructions provided in the “Wiring” section of this manual
s CAUTION
!
WARNING WARNING

3
TABLE OF CONTENTS
Before Getting Started.................................................................................2
Introduction .........................................................................................4
Safety Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation ..........................................................................................5
Typical Installation ....................................................................................6
Wiring ..............................................................................................7
Specifications ........................................................................................7
Sump System Operation Testing.........................................................................8
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Pump Performance Curves ............................................................................10
Troubleshooting .....................................................................................10
Replacement Parts....................................................................................11
Limited Warranty .................................................................................... 15

4
INTRODUCTION
This is a submersible sump/euent pump for use in basins or lift
stations and is suitable for pumping clear water or euent gray
water with up to 1/2" spherical semi-solids. Do not use the pump in
applications where sewage or any other debris (gravel, sand, floating
debris, etc.) or corrosives are present.
This instruction sheet provides you with the information required to
safely own and operate your product. Retain these instructions for
future reference. The product you have purchased is of the highest
quality workmanship and material, and has been engineered to give
you long and reliable service. This product has been carefully tested,
inspected, and packaged to ensure safe delivery and operation. Please
examine your item(s) carefully to ensure that no damage occurred
during shipment. If damage has occurred, please contact the place of
purchase. They will assist you in replacement or repair, if required.
SAFETY GUIDELINES
s
!
DANGER When a pump is in a basin, etc.,
do not touch the motor, pipes or water until unit is unplugged or
shut-o. If shut-o box is not accessible, call the electric company
to shut o service to the house, or call your local fire department
for instructions. Failure to follow this warning can result in fatal
electrical shock
s
!
WARNING RISK OF ELECTRIC SHOCK
This product is supplied with a grounding conductor and grounding-
type attachment plug. To reduce risk of electric shock, be certain
that it is connected only to a properly grounded grounding-type
receptacle. The third prong is to ground the pump to help to prevent
possible electric shock hazard. Do not remove the third prong from
the plug. Do not use an extension cord.
As a safety measure, each electrical outlet should be checked with an
Underwriters Laboratory Listed circuit analyzer. This will indicate if the
power, neutral and ground wires are properly connected. If they are
not, call a qualified licensed electrician.
s
!
WARNING The pump motor is equipped
with an automatic resetting thermal protector and may restart
unexpectedly. Protector tripping is an indication of motor
overloading/overheating, which can be caused by application issues
such as an obstructed pump impeller, switch stuck in ON position,
pump running dry, pump air-locked, pump short cycling, excessively
high or low voltage supply, or possibly a pump, motor, bearings or
seal that have reached the end of their useful life.
s
!
WARNING During normal operation the pump
is immersed in water. Also, water may be present in the surrounding
area of the pump. Caution must be used to prevent bodily injury
when working near the pump:
a. Electrical power should be disconnected prior to touching,
servicing or repairing the pump.
b. To minimize possible fatal electrical shock hazard, extreme
care should be used when changing fuses. Do not stand in
water while changing fuses or insert your finger into the
fuse socket.
s
!
WARNING Do not run the pump in a dry basin.
If the pump is run in a dry basin, the surface temperature of the pump
will rise to a high level. This high level could cause skin burns if the
pump is touched and will cause serious damage to your pump. For
optimal cooling and to prolong the motor life, the liquid level being
pumped should normally be above the top of the pump housing.
s
!
WARNING Do not oil the motor. The pump
housing is sealed. A high-grade dielectric oil devoid of water has been
put into the motor housing at the factory. Use of other oil could cause
serious electric shock and/or permanent damage to the pump.
s
!
WARNING This pump’s motor housing contains
a dielectric oil for motor heat transfer and lifetime lubrication of the
bearings. This oil is non-toxic to aquatic life. However, suocation
can occur if oil is left on the water surface. If oil escapes the motor
housing, it can be removed from the surface quickly by placing
newspapers on the water surface to soak up the oil.
s
!
CAUTION
THIS PUMP HAS BEEN EVALUATED FOR USE WITH WATER ONLY.
WARNING WARNING

5
INSTALLATION
s
!
WARNING Check local electrical and
building codes before installation. The installation must be in
accordance with their regulations as well as the most recent
National Electrical Code (NEC).
1. Pump must be installed in a suitable gas-tight basin that is at
least 18" in diameter and 24" deep, and vented in accordance
with local plumbing codes.
2. Clean any debris from sump pit and set pump in center of pit
(Figure 2). A solid bottom will prevent clogging of the pump
from sand and dirt.
3. The pump must be placed on a hard, level surface. Never place
the pump directly on clay, earth or gravel surfaces. These
surfaces contain small stones, gravel, sand etc. that may clog or
damage the pump and cause pump failure.
4. Do not attempt to restrict the intake side of these pumps.
Restricting the intake may cause damage to the seal and may
starve the pump. If you require reduced flow rates, place a valve
on the discharge side of the pump. Or, if flexible vinyl tubing is
used, a clamp can be used on the tubing to restrict the flow.
5. Connect discharge piping. Use pipe joint compound at all
connections. Sump pumps can be piped to discharge into the
house drainage system, to a dry well, splash block or to a storm
drain, depending on local plumbing codes. The discharge pipe
should be as short as possible and contain as few elbows as
possible. The discharge pipe should be the same diameter as
the discharge size to reduce pipe friction losses. Smaller pipe
will restrict capacity and reduce pump performance. The sump/
euent pump comes with 1-1/2" female pipe thread discharge.
a. Support pump and piping when assembling and when
installed. Failure to do so may cause piping to break, pump
to fail, motor bearing failures, etc.
b. Always install a union in the discharge line, just above
the sump pit, to allow for easy removal of the pump for
cleaning or repair.
6. A check valve must be used in the discharge line to prevent back
flow of liquid into the basin. The check valve should be a free
flow valve that will easily pass solids.
a. s
!
CAUTION For best performance of
check valve when handling solids, install in a horizontal
position or at an angle of no more than 45°. Do not install
check valve in a vertical position, as solids may settle in
valve and prevent opening on start-up.
b. When a check valve is used, drill a relief hole (1/8" or 3/16"
diameter) in the discharge pipe. This hole should be located
below the floor line between the pump discharge and
the check valve. Unless such a relief hole is provided,
the pump could “air lock” and will not pump water
even though it will run.
7. Tape pump and switch cords to discharge line with electrician’s
tape. This will protect the cord from damage.
8. Test operation of the sump system following the instructions
outlined in the “Sump System Operation Testing” section of this
manual. Do not attempt to operate the pump without water;
this will damage the seals and bearings and could result in
permanent damage to the pump.
9. Place cover over sump. This cover will help prevent debris from
entering the pit and will guard against accidental injury.
s
!
WARNING Always disconnect the electrical
power before touching the pump or discharge when water is present
in the sump. Failure to do so can result in hazardous electrical shock.

6
Separate protected and grounded
service outlet minimum 4' from floor.
Pump Power Cord
Discharge pipe no smaller than pump outlet.
Pump Power Grommet
Sump Cover
2" or 3" Vent Pipe
3/16" dia. Bleed Hole in Discharge Pipe
Gas-tight Basin, 18" dia. x 24" deep min.
Union
Check Valve
Gate Valve
Pump Place pump on hard level surface.
Never place directly on clay, earth or gravel surface.
SFS Models
• 7" - 10" on level
SFS Models
• 2" - 5" o level
TYPICAL INSTALLATION

7
WIRING
s
!
WARNING Check local electrical and
building codes before installation. The installation must be in
accordance with their regulations as well as the most recent
National Electrical Code (NEC).
Check the pump label for proper voltage required. Do not connect to
voltage other than that shown.
A ground fault circuit interrupter (GFCI) is required.
The pump should be connected or wired to its own circuit with
no other outlets or equipment in the circuit line. The fuses and
circuit breaker should be of ample capacity in the electrical circuit.
See table below:
s
!
WARNING The flexible jacketed cord assembly
mounted to the pump must not be modified in any way, with the
exception of shortening the cord to fit into a control panel. Any splice
between the pump and the control panel must be made within a
junction box and mounted outside of the basin, and comply with
the National Electrical Code. Do not use the power cord for lifting
the pump.
SPECIFICATIONS
Gallons Per Minute, at Height
Liters Per Minute, at Height Shut-Off
5'
1.5 m 10' 3 m 15' 4.5 m 20' 6.1 m 30' 9.1 m
6EC 53 50 42 34 -28'
201 189 159 129 8.5 m
10EC 67 57 47 42 24 36'
254 216 178 159 91 11 m
WARNING WARNING
MANUAL
WHITE
WHITE BLUE
RED WHITE BLACK
GREEN
SWITCH
WHITE
WHITE
WHITE
RED
BLUE
BLACK
GREEN
CAP
CAP
6EC/10EC SERIES
AUTOMATIC
MANUAL
MANUAL
WHITE
WHITE BLUE
RED WHITE BLACK
GREEN
SWITCH
WHITE
WHITE
WHITE
RED
BLUE
BLACK
GREEN
CAP
CAP
6EC/10EC SERIES
AUTOMATIC
AUTOMATIC
Pump HP Voltage Breaker Amps
6EC 1/3 115 V 15
10EC 1/2 115 V 15

8
SUMP SYSTEM OPERATION TESTING
TESTING AUTOMATIC PUMP OPERATION
1. The 6EC-CIA-SFS and 10EC-CIA-SFS automatic pumps are
equipped with an integral float-operated mechanical switch.
Automatic operation is achieved through the pump cord.
2. When these pumps are installed in a basin with a sealed cover,
switch operation cannot be observed. The sump cover usually
will have a spare hole that is plugged with a rubber plug. This
plug can be removed and switch operation can be observed.
3. Plug the power cord into a grounded receptacle with
voltage consistent with the pump voltage, as indicated
on the pump nameplate.
4. Be sure the gate valve in the discharge line is open.
5. Run water into the sump basin until the primary
pump is activated.
a. Do not attempt to run the pump without water; this could
result in permanent damage to the pump.
6. Confirm that primary pump and its control switch are
functioning as intended.
7. Confirm that ON-OFF levels are within specification and
confirm that no potential obstructions exist that could
inhibit switch operation.
8. Confirm that there are no leaks in the primary pump discharge
plumbing and main home drain pipe plumbing.
a. It is normal for a stream of water to spray from the air
bleed hole in the primary pump’s plumbing. Confirm that
this spray is captured within the sump basin.
9. Allow the pump to operate through several on/o cycles.
TESTING MANUAL PUMP OPERATION
1. The 6EC-CIM manual pumps do not include an automatic
liquid level control. The pump cord for these pumps can be
plugged directly into a properly grounded receptacle with
voltage consistent with pump nameplate for continuous
pump operation.
a. s
!
CAUTION This type of operation
should be used only for emergency use or when a large
volume of water is to be pumped. The pump must be
continuously monitored during operation and disconnected
from power before the pump runs dry.
b. Pump must not be allowed to run dry. If pump is run dry,
it may damage pump and void the warranty.
2. For automatic operation of a manual pump, a separate float
switch or other liquid level control must be used.
a. s
!
CAUTION Refer to float switch or
other liquid level control manufacturer’s instructions
when installing. Failure to install it in compliance with
national and local electrical and plumbing codes and within
manufacturer’s recommendations may result in electrical
shock or fire hazard, unsatisfactory performance, or
equipment failure.
b. After installing separate float switch or other liquid level
control, test operation following the steps shown in the
“Testing Automatic Pump Operation” section.
If the pump does not operate properly, consult the Troubleshooting
table. If the trouble still cannot be found, consult your pump dealer or
take the pump to a Little Giant authorized service center.
Do not let the unit run dry (without liquid). It is designed to be cooled
by pumping fluid. You may damage the seal and the motor may fail if
the pump is allowed to run dry.
If the unit is going to be idle for a period of time, follow the cleaning
instructions outlined in the next section. Do not let the unit freeze.
This may cause cracking or distortion that may destroy the unit.

9
MAINTENANCE
s
!
CAUTION When working on the pump or switch,
always unplug the pump power cord in addition to removing the fuse
or shutting o the circuit breaker before working on the pump.
This unit is permanently lubricated. Oiling is not required.
Do not, in any case, open the sealed portion of the unit
or remove housing screws.
s
!
NOTICE Inspect and test the sump system
condition and operation every 3 months (more frequently
in heavy use applications).
1. LET PUMP COOL FOR A MINIMUM OF 2 HOURS BEFORE
ATTEMPTING TO SERVICE.
a. Submersible pumps contain oil that becomes pressurized
and hot under normal operating conditions.
2. Check the power cords and electrical outlet for
damage or corrosion.
a. The power cord on these units cannot be replaced.
In case of damage the whole unit must be replaced.
3. Remove all debris (gravel, sand, floating debris, etc.)
from the sump basin.
4. Review sump system components for any build-up (minerals,
etc.) that would inhibit functionality of the components.
a. If significant, remove build-up or replace
aected components.
5. Confirm that all flexible coupling hose clamps are fully engaged
with plumbing and fully tightened.
6. Test operation of the sump system following the instructions
outlined in the “Sump System Operation Testing” section
of this manual.
7. While the pump is running, make sure a stream of water is
escaping from the air bleed hole.
a. If not, clear the hole of any deposits or debris.
CLEANING IMPELLER AND VOLUTE
Periodic cleaning of the pump parts will prolong the life and
eciency of the pump. Refer to the assembly and disassembly
of the pumping head.
1. Remove the 5 screws that hold the base to the volute,
then separate the base from the volute.
2. s
!
WARNING Do not remove the motor
housing cover. Warranty is void if the motor housing cover,
impeller or seals have been removed.
a. Any repair on the motor must be done by an authorized
Little Giant service center.
3. Remove the base and clean the impeller and the volute passage.
Do not use strong solvents on the impeller.
a. s
!
CAUTION Do not remove the impeller.
Removal of the impeller requires special tools and is to be
done only by an authorized service center.
4. Be sure the impeller turns freely after cleaning.
5. Attach the base to the volute and secure it with the 5 screws.
CONSULT INSTRUCTION SHEET ILLUSTRATIONS FOR PROPER ASSEMBLY
AND DISASSEMBLY OF YOUR LITTLE GIANT PUMP.
WARNING WARNING

10
TROUBLESHOOTING
Problem Probable Causes Corrective Action
Pump does not turn on
Pump not plugged in. Plug in pump.
Circuit breaker shut-off or fuse removed. Turn on circuit breaker or replace fuse.
Accumulation of trash on float. Clean float.
Float obstruction. Check float path and provide clearance.
Defective switch. Have pump serviced by authorized service center.
Defective motor. Have pump serviced by authorized service center.
Pump will not shut off
Float or float rod obstruction. Check float and float rod path and provide clearance.
Pump is air locked. Shut power off for approximately 1 minute, then restart. Repeat several times to clear air from pump.
Liquid inflow matches pump capacity. Larger pump required.
Defective switch. Disconnect switch, check ohmmeter, open-infinitive resistance, closed-zero.
Pump runs but does not
discharge liquid
Check valve installed backwards. Check flow-indicating arrow on check valve body to ensure it is installed properly.
Check valve stuck or plugged. Remove check valve and inspect for proper operation.
Lift too high for pump. Check rating table.
Inlet to impeller plugged. Pull pump and clean.
Pump is air locked. Pull pump and clean.
Pump does not deliver
rated capacity
Lift too high for pump. Check rated pump performance.
Low voltage, speed too slow. Check for proper supply voltage to make certain it corresponds to nameplate voltage.
Impeller or discharge pipe is clogged. Pull pump and clean. Check pipe for scale or corrosion.
Impeller wear due to abrasives. Replace worn impeller.
Pump cycles continually
No check valve in long discharge pipe
allowing liquid to drain back into sump. Install a check valve in discharge line.
Check valve leaking. Inspect check valve for correct operation.
Basin too small for inflow. Install larger basin.
6EC 10EC
0
3
6
9
0 30 60 90 120 150 180 210
0
5
10
15
20
25
30
0 10 20 30 40 50 60
HEAD - METERS
FLOW - LITERS/MINUTE
HEAD - FEET
FLOW - GALLONS/MINUTE
0
2
4
6
8
10
12
0 50 100 150 200 250
0
5
10
15
20
25
30
35
40
0 10 20 30 40 50 60 70
HEAD - METERS
FLOW - LITERS/MINUTE
HEAD - FEET
FLOW - GALLONS/MINUTE
PUMP PERFORMANCE CURVES

11
Part No. Description Item No.
110970101 Cover Assembly, 115 V, Automatic, with Switch, 20' Cord 1
110970103 Cover Assembly, 115 V, Manual, 20' Cord 1
110970201 Capacitor Kit, 115 V, with Bracket, Seal Ring 2
110970301 Float Assembly with Stem Strap 3
110970401 Volute Base, Plastic, with Gasket for 6E 4
110970403 Volute Base, Plastic, with Gasket for 10EC 4
REPLACEMENT PARTS

12
NOTES

13
NOTES

14

SEWAGE & EFFLUENT 2 YEAR WARRANTY STATEMENT
LIMITED WARRANTY
THIS WARRANTY SETS FORTH THE COMPANY’S SOLE OBLIGATION AND PURCHASER’S EXCLUSIVE REMEDY FOR DEFECTIVE PRODUCT.
Franklin Electric Company, Inc. and its subsidiaries (hereafter “the Company”) warrants that the products accompanied by this warranty are free from defects in materials or
workmanship of the Company that exist at the time of sale by the Company and which occur or exist within the applicable warranty period. Any distributor, sub-distributor,
recipient, end-user and/or consumer agrees that by accepting the receipt of the products, the distributor, sub-distributor, recipient, end user and/or consumer expressly agrees to be
bound by the terms of the warranty set forth herein.
I. Applicable Warranty Period
The products accompanied by this warranty shall be covered by this Limited Warranty for a period of 24 months from the date of original purchase by the consumer. In the absence
of suitable proof of purchase date, the warranty period of this product will begin to run on the product's date of manufacture.
II. Instructions Applicable to this Limited Warranty
1. Consumers wishing to submit a warranty claim must return the products accompanied by this warranty to the point of purchase for warranty consideration.
2. Upon discovery of a defect, any personal injury, property damage or any other type of resulting damage, if applicable, shall be reasonably mitigated to the
extent possible.
3. At its discretion, the Company may inspect products either at its facilities or in the field, and after determination of a warranty claim, will, at its option, repair or replace
defective parts. Repaired or replaced parts will be returned freight prepaid by the Company.
4. This warranty policy does not cover any labor or shipping charges. The Company shall not be liable for any costs or charges attributable to any product testing,
maintenance, installation, repair or removal, or for any tools, supplies, or equipment needed to install, repair, or remove any product.
III. Limitations Applicable to this Limited Warranty
THIS WARRANTY DOES NOT APPLY TO ANY OF THE FOLLOWING:
1. Brushes, impeller or cam on models with brush-type motors and/or flex-vane impellers.
2. Any product that is not installed, applied, maintained, and used in accordance with the Company's published instructions, applicable codes, applicable ordinances and/or
with generally accepted industry standards.
3. Any product that has been subject to misuse, misapplication, neglect, alteration, accident, abuse, tampering, acts of God (including lightning), acts of terrorism, acts of
war, fire, improper storage or installation, improper use, improper maintenance or repair, damage or casualty, or to an excess of the recommended maximums as set
forth in the product instructions.
4. Any product that is operated with any accessory, equipment, component, or part not specifically approved by the Company.
5. Use of replacement parts not sold by the Company, the unauthorized addition of non-Company products to other Company products, and the unauthorized alteration of
Company products.
6. Products damaged by normal wear and tear, normal maintenance services and the parts used in connection with such service, or any other conditions beyond the
control of the Company.
7. Any product that has been used for purposes other than those for which it was designed and manufactured.
8. Any use of the product where installation instructions and/or instructions for use were not followed.
9. Products connected to voltage other than indicated on nameplate.
10. Products where the pump was exposed to any of the following: sand, gravel, cement, grease, plaster, mud, tar, hydrocarbons, hydrocarbon derivatives (oil, gasoline,
solvents, etc.) or other abrasive or corrosive substances.
11. Products in which the pump has been used for pumping of liquids above 140 °F.
12. Products in which the pump was allowed to operate dry (fluid supply cut o).
13. Products in which the sealed motor housing has been opened or the product has been otherwise dismantled by customer.
14. Products in which the cord has been cut to a length of less than three feet.
The Company reserves the right at any time, and from time to time, to make changes in the design and/or improvements upon its product without thereby imposing any obligation
upon itself to make corresponding changes or improvements in or upon its products already manufactured and/or previously sold. The Company further reserves the right to
substitute parts or components of substantially equal quality in any warranty service required by operation of this Limited Warranty.
This written Limited Warranty is the entire warranty authorized and oered by the Company. There are no warranties or representations beyond those expressed in this document.

THIS WARRANTY AND REMEDY IS IN LIEU OF ALL OTHER WARRANTIES AND REMEDIES INCLUDING WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A
PARTICULAR PURPOSE, WHICH ARE HEREBY SPECIFICALLY DISCLAIMED AND EXPRESSLY EXCLUDED. CORRECTION OF NON-CONFORMITIES, IN THE MANNER AND FOR THE PERIOD OF TIME AS
SET FORTH ABOVE, SHALL CONSTITUTE FULFILLMENT OF ALL LIABILITY OF THE COMPANY TO THE PURCHASER WHETHER BASED ON CONTRACT, NEGLIGENCE, OR OTHERWISE.
THE COMPANY SHALL NOT BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES SUCH AS, BUT NOT LIMITED TO:
DAMAGE TO OR LOSS OF OTHER PROPERTY OR EQUIPMENT, LOSS OF USE OF EQUIPMENT, FACILITIES OR SERVICE, LOSS OF PROFIT OR SALES, COST OF PURCHASES OR REPLACEMENT
GOODS, CLAIMS OF CUSTOMERS OF THE PURCHASER, FAILURE TO WARN AND/OR INSTRUCT, LOSS OF OTHER PRODUCTS, OR COSTS OF ENVIRONMENTAL REMEDIATION, OR DIMINUTION IN
PROPERTY VALUE. THE REMEDIES OF THE PURCHASER SET FORTH HEREIN ARE EXCLUSIVE, AND THE LIABILITY OF THE COMPANY SHALL NOT, EXCEPT AS EXPRESSLY PROVIDED HEREIN,
EXCEED THE PRICE OF THE PRODUCTS UPON WHICH SUCH LIABILITY IS BASED. DAMAGES AS SET FORTH IN THIS PARAGRAPH SHALL BE REASONABLY MITIGATED TO THE EXTENT POSSIBLE.
THIS PARAGRAPH SHALL ALSO APPLY TO ALL DAMAGES RESULTING FROM CONDITIONS SET FORTH IN SECTION III ABOVE AND (1) DEFECTS IN PRODUCT PROTOTYPES OR REPLACEMENT
PART PROTOTYPES THAT HAVE NOT BEEN PUT INTO PRODUCTION, CIRCULATED AND SOLD BY THE COMPANY, AND/OR (2) DEFECTS THAT WERE NOT FOUND AT THE TIME OF SALE DUE TO
SCIENTIFIC AND TECHNOLOGICAL REASONS.
This Limited Warranty gives you specific legal rights. You may have other rights, which vary according to the applicable laws and regulations. Where any term of this warranty is
prohibited by such laws, it shall be null and void, but the remainder of this warranty shall remain in full force and eect.
DISCLAIMER: Any oral statements about the product made by the seller, the Company, the representatives or any other parties, do not constitute warranties, shall not be relied upon
by the user, and are not part of the contract for sale. Seller’s and the Company’s only obligation, and buyer’s only remedy, shall be the replacement and/or repair by the Company
of the product as described above. Before using, the user shall determine the suitability of the product for his intended use, and user assumes all risk and liability whatsoever in
connection therewith.
For replacement parts, contact:
Grainger Parts
1657 Shermer Road
North Brook, IL 60062-5362
Phone: [phone] | Fax: [phone]
Franklin Electric Co., Inc.
Form 998766
Rev. 000
02/17
