Living Spaces 305-S360-539 User manual

Page 1 of 4
ASSEMBLY INSTRUCTIONS
MADE IN VIET NAM
HARDWARE LIST (For 305-S360-533 4/6 Panel Footboard W/Slats)
Qty.
No. Descriptions Size
Drawing
13 8 PCSScrew M4 x 32mm
TOOLS REQUIRED (NOT PROVIDED)
PHILLIPS SCREWDRIVER
PART LIST
1 PC
Qty.
Descriptions
Drawing
4/6 Metal Rod Headboard
(305-S360-539 )
1 SET
2 PCS
Footboard ...1 PC Slats ...4 PCS Slat Support ...4 PCS
4/6 Panel Footboard W/Slats
(305-S360-533)
3/3-4/6 Bed Rails
(305-S360-401)
DESCRIPTION: 4/6 METAL ROD BED
ITEM NO: 305-S360-539 / 533 / 401
305-S360-539 4/6 Metal Rod Headboard
305-S360-533 4/6 Panel Footboard W/Slats
305-S360-401 3/3-4/6 Bed Rails
305-S360-533 4/6 Panel Footboard W/Slats
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small Hardware which may have come
loose inside the carton during shipment.Identify and count all Hardware and compare with the Hardware List Below.

Page 2 of 4
Metal Hook
13
Step 1
Step 2
Step 3
MADE IN VIET NAM
ASSEMBLY INSTRUCTIONS
DESCRIPTION: 4/6 METAL ROD BED
ITEM NO: 305-S360-539 / 533 / 401
LEVELER

Page 3 of 4
ASSEMBLY INSTRUCTIONS
MADE IN VIET NAM
HARDWARE LIST (For SLATR-46)
Qty.
No. Descriptions Size
Drawing
13 26 PCSScrew M4 x 32mm
TOOLS REQUIRED (NOT PROVIDED)
PHILLIPS SCREWDRIVER
PART LIST
1 PC
Qty.
Descriptions
Drawing
4/6 Metal Rod Headboard
(305-S360-539 )
1 PC
2 PCS
4/6 Panel Footboard W/Slats
(305-S360-533)
3/3-4/6 Bed Rails
(305-S360-401)
DESCRIPTION: 4/6 METAL ROD BED &TRUNDLE & 4/6 SLAT ROLL
ITEM NO: 305-S360-539 / 533 / 401 / 801
1 SET
SLATR-46
Trundle (305-S360-801 ) 1 PC
Metal Hook
Step 2
13
Step 1
305-S360-801Trundle

Page 4 of 4
ASSEMBLY INSTRUCTIONS
DESCRIPTION: 4/6 METAL ROD BED
STORAGE RAIL & 4/6 SLAT ROLL
ITEM NO: 305-S360-539 / 533 / 643
ITEM NO: SLATR-46
MADE IN VIET NAM
HARDWARE LIST (For SLATR-33)
Qty.
No. Descriptions Size
Drawing
13 26 PCS Screw M4 x 32mm
TOOLS REQUIRED (NOT PROVIDED)
PHILLIPS SCREWDRIVER
PART LIST
1 PC
Qty.
Descriptions
Drawing
4/6 Metal Rod Headboard
(305-S360-539 )
4/6 Panel Footboard W/Slats
(305-S360-533)
1 SET
SLATR-46
1 PC
Side Storage Rail (305-S360-643)
Side Rail (305-S360-643) 1 PC
1 PC
SLATR 46
B
A
13
STEP 1
