Living Spaces 305-S360-733 User manual

Size of Mattress
This bed is designed to use a Extension mattress 54" to 54.5" Wide x 75" Long with the total thickness
not exceeding 8" for lower bunk. Do not use mattress without the proper slat system and proper
attachments described in the instructions. NOTE: there must be at least 5 inches from the top surface of
the mattress to top edge of guardrail.
1. Follow the information on the warning appearing on the upper bunk end structure and on the
carton. Do not remove warning label from bed.
2. Always use the recommended size mattress or mattress support, or both, to help prevent the
likelihood of entrapment or falls.
3. Surface of mattress must be at least 5 inches below the upper edge of the guardrails.
4. Do not allow children under 6 years of age to use the upper bunk.
5. Prohibit more than one person on upper bunk.
6. Periodically check and ensure that the guardrail, ladder,and other components are in their proper
position, free from damage, and that all connectors are tight.
7. Do not allow horseplay on or under the bed and prohibit jumping on the bed.
8. Alway use the ladder for entering and leaving the upper bunk.
9. Do not use any substitute parts. Contact manufacturer or dealer for replacement parts.
10. Use of a night light may provide added safety precaution for a child using the upper bunk.
11. If the bunk bed will be placed next to a wall, the guardrail that runs the full length of the bed
should be placed against the wall to prevent entrapment between the bed and the wall.
12. Always use guardrails on both long sides of the upper bunk.
13. The use of water or sleep flotation mattress is prohibited.
14. Keep these instructions for future reference.
15. Strangulation Hazard-Never attach or hang items to any part of the bunk bed that are not
designed for use with the bed: for example, but not limited to, hooks, belts, and jump ropes.
SAFETY WARNING !
Replacement Parts
Replacement parts, including additional guardrails, may be obtained from place of purchase or Original
distribution
Replacement Parts
Keep all instruction sheets for future reference to assemble bed for moving and/or different set up.
ASSEMBLY INSTRUCTIONS
Page 1 of 4
DESCRIPTION: 4/6 EXTENSION

DESCRIPTION: BUNK BED 4/6 EXTENSION & 3/3 BUNK BED
Page 2 of 4
ASSEMBLY INSTRUCTIONS
ITEM NO: 305-S360-733
HARDWARE LIST (For 305-S360-733 Bunk Bed 4/6 Extension)
Qty.
No. Descriptions Size
Drawing
Bolt 1/4" x 57 x 2 1/4" 8 PCS
14
D-nut 1/4" x 15 x 9/16"
1 PC
2
M4
4
8 PCS
Allen Key
8 PCS
Flat washer 3/8" x 22mm
15
TOOLS REQUIRED (NOT PROVIDED)
PHILLIPS SCREWDRIVER
PART LIST
2 PCS
Qty.
Descriptions
Drawing
Bunk Bed 4/ 6 Extension
(305-S360-733)
SLATR-33
305-S360-731 3/3 Bunk Bed Ladder W/Guard Rail
305-S360-730 3/3 Bunk Bed Ends
305-S360-731 3/3 Bunk Bed Ladder W/Guard Rail
305-S360-732 Bunk Bed Rails
305-S360-733 Bunk Bed 4/ 6 Extension
MADE IN VIET NAM
SLATR-46
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small Hardware which may have come
loose inside the carton during shipment.Identify and count all Hardware and compare with the Hardware List Below.

Page 3 of 4
DESCRIPTION: BUNK BED 4/6 EXTENSION & 3/3 BUNK BED
ASSEMBLY INSTRUCTIONS
ITEM NO: 305-S360-733
MADE IN VIET NAM

13
Page 4 of 4
2
1
4
STEP 4
STEP 3
DESCRIPTION: BUNK BED 4/6 EXTENSION & 3/3 BUNK BED
ASSEMBLY INSTRUCTIONS
ITEM NO: 305-S360-733
MADE IN VIET NAM
