Living Spaces Oliver User manual

Oliver C/E King Assembly Instructions
Hardware included in side rails carton to attach bed feet and center support system.
A
D
F
G
I
J
R
T
Φ6*20MM
Φ6 MM
H=8 CM
Metal Slats
Φ8 MM
Center support legs
H=14 CM
Φ8*60MM
Φ6*25MM
8PCS
16PCS
2PCS
4PCS
1PC
8PCS
2PCS
8PCS
Step#1
Retrieve bed feet from carton packed in side rails carton.
Attach bed feet (F) to the footboard using Wrench (I), Bolt (R) .
Step#2
Attach side rails to headboard using Wrench (I), Bolt (B) and Washer (E)(factory installed).
Attach side rails to footboard using Wrench (I), Bolt (B) and Washer (E)(factory installed).
CONGRATULATIONS ON YOUR NEW BED PURCHASE
~Warning：do not move bed after final assembly as it may result in damages to floor and/or bed.~
1
2
*Bolt B and Washer E are
factory installed*

Oliver C/E King Assembly Instructions
Hardware included in side rails carton to attach bed feet and center support system.
A
D
F
G
I
J
R
T
Φ6*20MM
Φ6 MM
H=8CM
Metal Slats
Φ8 MM
Center support legs
H=14 CM
Φ8*60MM
Φ6*25MM
8PCS
16PCS
2PCS
4PCS
1PC
8PCS
2PCS
8PCS
Step#3
Attach steel center support legs (J) to the Metal slat (G) using Wrench (I), Bolt (T) and
Washer (D).
Step#4
Move/place bed into final position in bedroom.
Step#5
Attach steel slat support system to full length steel side support cleats(flat side facing up).
Verify the metal slats are installed properly into support cleats and center support legs are
perpendicular to the floor for full support.
CONGRATULATIONS ON YOUR NEW BED PURCHASE
~Warning：do not move bed after final assembly as it may result in damages to floor and/or bed.~
3
5
